H15 Direct Vent Gas Fireplace Installation Manual www.hampton-fire.com MODELS: H15-NG10 Natural Gas H15-LP10 Propane WARNING FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 2
HAMPTON ® Direct Vent Freestanding Gas Stove To the New Owner: Congratulations! You are the owner of a state-of-the-art Hampton Gas Stove by FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. The ® H15-10 is a hand crafted appliance and has been designed to provide you with all the warmth and charm of a wood fire- place at the flick of a switch.
dimensions Dimensions Aeration Adjustment ............31 Gas Pipe Pressure Testing ..........31 Unit Dimensions with horizontal vent ......4 885 S.I.T. Valve Description .........31 Unit Dimensions with vertical vent .........5 Conversion from Ng to LP ...........32 Log Set Installation ............33 Installation Optional Wall Thermostat ...........35 Back up battery............35 Important Message ............8 Remote/Receiver coding ..........35...
dimensions UNIT DIMENSIONS WITH HORIZONTAL VENT 20-11/16" (525mm) 19-1/8" (485mm) 14-1/4 (361mm) 19-3/8" 13-5/8" (492mm) (345mm) ALL PICTURES / DIAGRAMS SHOWN THROUGHOUT THIS MANUAL ARE FOR ILLUSTRATION PURPOSES ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENTS. Hampton® H15-10 Direct Vent Freestanding Gas Stove...
dimensions UNIT DIMENSIONS WITH VERTICAL VENT Hampton® H15-10 Direct Vent Freestanding Gas Stove...
Page 6
Taille de l'orifice Altitude 0-4500 ft/pi (0-1372m) Altitude Vertical Horizontal Pipe Pipe PROPANE GAS STOVE: Model H15-LP10 APPAREIL FONCTIONNANT AU PROPANE Modèle H15-LP10 Minimum supply pressure 11" WC/C.E. (2.74 kPa) Pression d'alimentation minimum Manifold pressure High 10" WC/C.E. (2.49 kPa) Pression manifold - lev e é...
Page 7
requirements MA Code - CO Detector (for the State of Massachusetts only) 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:...
IN THE HOUSE. TO RESTRICT ACCESS natural gas. TO A FIREPLACE OR STOVE, INSTALL AN ADJUSTABLE SAFETY GATE TO H15-LP10 is approved for use with BEFORE YOU START KEEP TODDLERS, YOUNG CHILDREN liquefied petroleum gases (propane). AND OTHER AT RISK INDIVIDUALS OUT Safe installation and operation of this appliance re- Electrical: 120V A.C.
installation 1) Provide adequate clearances for servicing, lint from carpeting, bedding material, etc. It b. Wall Thermostat is imperative that control compartments, and c. Remote Control proper operation and around the air openings circulating air passageways of the appliance into the combustion chamber. 9) Final check.
* 12' max. only if vertical height is achieved. Use the minimum clearances shown in the dia- Cross Corner grams below: Room Divider Island H15-NG10 & H15-LP10 Clearances Flat on Wall Flat on Wall Corner A Left Side Wall to Unit* 6" / 150 mm Flush with Wall/Alcove *B Back Wall to Unit 0"...
installation OPTIONAL FAN OPTIONAL FAN INSTALLATION INSTALLATION Tuck the fan assembly in behind the legs Remove left side access panel (when as shown. On either side of the unit there facing front) by removing one screw. will be slits located on the body of the Remove the rear access panel on the back of stove.
installation GLASS FRONT WALL THERMOSTAT REMOVAL / INSTALLATION INSTALLATION 1. Turn off stove and allow to return to room tem- 5. Lift both latches securing glass door and 1. Open the front panel and remove the cover perature. remove door. plate by removing two screws.
1) Wear gloves and safety glasses for protec- bination with the Direct Vent Freestanding Gas the H15-NG10, and H15-LP10. The warranty will tion. Stoves, H15-NG10, and H15-LP10, have been be voided and serious fire, health or other safety...
installation EXTERIOR VENT TERMINAL LOCATIONS Minimum Clearance Requirements Canada Clearance above grade, veranda, porch, deck, or balcony 12"(30cm) 12"(30cm) Clearance to window or door that may be opened 12"(30cm) 9" (23cm) Clearance to permanently closed window Vertical clearance to ventilated soffit located above the terminal within a horizontal distance of 2 feet (61cm) 22"(56cm) 22"(56cm) from the center line of the terminal (check with the local code)
installation 4” X 6-5/8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not All Rigid Pipe components are available directly from FPI. 4” X 6- ” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Note: The listed manufacturers may have other lengths not shown on this chart, which would also be approved.
Page 16
installation Description Selkirk American Metal Security ICC Excel Olympia Simpson Metal-Fab™ Ventis DV* Direct Temp™ Products® Secure- Vent® Direct Direct Vent Pro ® Sure Seal Amerivent Direct Attic Insulation Shield 12” 46DVA-IS 4DAIS12 SV4RSA VDV-AIS04 N/A@ FPI Attic Insulation Shield 4DAIS12 TM-4AS - Cold Climates 36”...
installation RIGID PIPE VENTING SYSTEMS Horizontal or Vertical Terminations Alternate Vertical Horizontal Termination Max. Termination Caps Storm Collar Vinyl Siding Standoff (Optional) Flashing Horizontal Termination Ceiling Firestop Wall Thimble Pipe Length Adj.Pipe Length 11" - 14-5/8" 90 Elbow WARNING: Do not combine venting components from 24"...
Page 18
installation Horizontal Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option H + H1 With these options, maxi- 1' Min. 3' Max. mum total pipe length is 30 2' Min. 4' Max. feet with minimum of 6 feet total vertical and maximum 3' Min.
Page 19
installation Vertical Venting with Two (2) 90 Elbows One 90 elbow = Two 45 elbows. Option V V + V1 With these options, max. total pipe length is 30 feet with min. 1' Min. 4' Max. 2' Min. of 6 feet total vertical and max. 2' Min.
installation VENTING ARRANGEMENTS Horizontal Terminations for Vertical Terminations Systems for All Venting Systems Residential Manufactured and Mobile Homes The shaded areas in the diagram below show all The shaded area in the diagram below shows all allowable combinations of straight allowable combinations of vertical runs with hori- vertical and offset to vertical runs with vertical terminations.
installation VERTICAL TERMINATION WITH CO-LINEAR FLEX SYSTEM Masonry chimneys may take various contours which the flexible liner will accommodate. However, keep THE APPLIANCE MUST NOT BE CONNECTED TO A CHIMNEY FLUE the flexible liner as straight as possible, avoid unnecessary bending. SERVING A SEPARATE SOLID FUEL The Air Intake pipe must be attached to the inlet air collar of the termination cap.
installation DV STOVE HORIZONTAL VENT KIT DV 2 ft. Stove Vent Kit (Part # 946-116) and DV 4 ft. Stove Vent Kit (946-216) includes all the parts needed to install the H15-10 Direct Vent unit with up & out horizontal and vertical vent dimensions. For installations that require longer vertical and/or horizontal vents use the Dura-Vent system as shown in the "Dura-Vent Termina- tion Kit"...
Page 23
installation 10) Slide the decorative Thimble Cover over the pipe sections and secure with 4 screws (#8 x 1-1/2" drill point, black) to the wall. 11) Slide the 90 elbow (crimp end up), the 45 elbow and the 4 ft. pipe section (crimp end up) over the 4"...
installation RESIDENTIAL AND MANUFACTURED HOMES / MOBILE HOMES MINIMUM HORIZONTAL TERMINATION INSTALLATIONS Planning Your Venting Installation See the "Exterior Vent Terminal Locations" You will require the following components with your new Hampton Direct Vent Freestanding Gas Stove. ® section for requirements. Please review your product to make sure you have everything you need.
installation DURA-VENT TERMINATION KIT Planning Your Dura-Vent tion.) Select the amount of vertical rise desired in the "Exterior Vent Terminal Locations" section and Installation for "vertical-to-horizontal" type installations. in your local building codes. There are two basic types of Dura-Vent Direct Warning: Always maintain required To determine the length of vent pipe required for Vent System installations: horizontal termination...
installation Note: These are the minimum pieces required. Other parts may be required for your particular installation. See above for a list of vent parts. If installing termination on a siding covered wall, a vinyl siding standoff or furring strips can be used in order to ensure that the termination is not recessed into siding.
installation c) Before connecting the vent pipe to the vent termination, slide the black decorative wall thimble cover over the vent pipe, then slide the Wall Penetration Heat Shield over the vent pipe. Dia. 3. d) Slide the appliance and vent assembly towards the wall carefully inserting the vent pipe into the riser vent terminal assembly.
Page 28
installation 7) Ensure vent is vertical and secure the base of the flashing to the roof with roofing rails, slide storm collar over the pipe section and seal with a mastic. 8) Install the vertical termination cap by twist locking it. Notes: a) For multistorey vertical installations, a Ceiling Fire stop is required at the...
installation CONVERTING CLASS-A METAL CHIMNEY TO DIRECT VENT SYSTEM Prior to installation and connection of the vent system to a factory-built or masonry chimney, the chimney must be inspected and thoroughly cleaned by a qualified service person, such as a certified chimney sweep or home inspection service.
This unit is approved in Canada for altitude to 4500 ft. Manifold Pressure (CAN/CGA-2.17-M91). For Natural Gas installations (High) 3.5"+/- 0.2"w.c. above 4500 ft. follow current CAN/CGA-B149.1. H15-LP10 System Data GAS CONNECTION Slope "X" Conversion Kit The gas connection is a 3/8" NPT 90 elbow.
installation AERATION GAS PIPE 885 S.I.T. VALVE ADJUSTMENT PRESSURE TESTING DESCRIPTION 1) 6 Stage flame adjustment The appliance must be isolated from the gas sup- The air shutter can be adjusted by moving the adjust- 2) Pilot adjustment ply piping system by closing its individual manual ing wire up or down.
installation CONVERSION FROM NG TO LP CONVERSION FROM NG TO LP THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! Unscrew the pilot orifice with the allen key 11. Remove NG stepper motor by remov- Each Kit contains one LPG and replace with the LP pilot orifice in the ing 2 screws in locations shown below.
installation LOG SET INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the 5) Carefully remove the logs from the unit and diagrams. If the logs are broken do not use the unit unwrap them. The logs are fragile, handle with until they are replaced.
Page 34
LOG SET INSTALLATION installation 8) Take the embers and place on the burner in the 9) Place the center cross log on the top of the rear log space between the 2 front logs, ensure not to cover and position as shown below. any burner ports.
installation OPTIONAL BACK UP BATTERY 5. Hold down the ON/OFF button on the hand held remote to code the remote to the receiver–after WALL THERMOSTAT 4 beeps are heard–handheld is paired with In the event of a power outage the unit may be receiver.
installation WIRING DIAGRAM WITHOUT THERMOSTAT This heater does not require a 120V A.C. supply for WARNING: CAUTION: Ensure that the wires operation. In case of a power failure, the remote Electrical Grounding do not touch a hot surface and are control/thermostat will continue to operate.
operating instructions FIRST FIRE switch located on the front of the valve tray cover. This remote control requires coding. See remote The burner will remain lit until the switch is moved coding instructions for details. to the OFF position. The first fire in your stove is part of the paint curing process.
operating instructions LIGHTING PROCEDURE IMPORTANT: The remote control system supplied with this appliance has Note: The first try for ignition will last approximately 60 seconds. If there is no several options for starting/operating the appliance using the power button flame ignition (rectification) the board will stop sparking for approximately and ON/OFF key on the hand held transmitter.
operating instructions COPY OF THE LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and Propane Installation Codes, CSA B149.1. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
operating instructions PROFLAME II REMOTE CONTROL OPERATING INSTRUCTIONS PROFLAME II REMOTE CONTROL OPERATING INSTRUCTIONS IMPORTANT:The Proflame Transmitter 2 is an integrated part of the TECHNICAL DATA Proflame 2 System, which consists of these elements: • Proflame 2 Transmitter, to be used in conjunction with: REMOTE CONTROL •...
Page 42
operating instructions Temperature indication Display Remote-Flame Control With the system in the "OFF" position, press the Thermostat Key and The profl ame has six (6) fl ame levels. With the system on, and the fl ame the Mode Key at the same time. Look at the LCD screen on the transmit- level at the maximum in the appliance, pressing the Down Arrow Key ter to verify that a C or F is visible to the right of the room temperature once will reduce the fl...
Page 43
operating instructions Smart Thermostat (Transmitter Operation) Remote dimmer control (Light)** The auxiliary function controls the AUX power outlet by the dimmable The Smart Thermostat function adjusts the fl ame height in accordance light control. To activate this function use the Mode Key (fi g. 1) to index to the difference to the AUX icon (fi...
Page 44
operating instructions KEY LOCK Continous Pilot/Intermittent Pilot (CPI/IPI) selection With the system in "OFF" position press the Mode Key (fi g. 1) to index This function will lock the keys to avoid unsupervised operation. to the CPI mode icon (fi g. 19 & 20). To activate this function, press the MODE and UP Keys at the same Pressing the Up Arrow Key will activate the Continous Pilot Ignition mode time (fi...
maintenance NORMAL OPERATING SOUNDS OF CLOTHING OR OTHER FLAM- 4) Make a periodic check of burner for proper posi- GAS APPLIANCES MABLE MATERIAL SHOULD NOT tion and condition. Visually check the flame of BE PLACED ON OR NEAR THE the burner periodically, making sure the flames It is possible that you will hear some sounds from are steady;...
maintenance GENERAL VENT GLASS REPLACEMENT FAN MAINTENANCE MAINTENANCE Your stove is supplied with high temperature, 5 If your fan requires maintenance or replacement, mm Neoceram ceramic glass that will withstand the access to the fan is through the rear access panel Conduct an inspection of the venting system semi- highest heat that your unit will produce.
maintenance SAFETY SCREEN REPLACEMENT 1. Turn off stove and allow to return to room temperature. 4. Slide the light assembly bracket out of the way. 2. Lift off cast top and place on a soft surface. 5. Loosen 4 screws in locations shown below to release safety screen frame. 6.
maintenance 9. Remove back bracket by removing 1 screw. VALVE ASSEMBLY REPLACEMENT If your valve requires maintenance or replacement, use the following instructions: Note: Always shut off gas and disconnect electrical supply before removing the valve. 1. Open the front panel and remove the cover plate by removing two screws.
parts list MAIN ASSEMBLY Part # Description Part # Description Part # Description 945F Flue Collar/Starter Collar 382-105 Safety Screen Mounting 380-007 Door frame Bracket (Each) * 938-317 Touch Up Paint - Seaside Sand 382-917 Fan Assembly 380-024 Fan Deflector - Right 382-515 Rear Panel Assembly 382-201...
parts list BURNER & LOG ASSEMBLY Part # Description 911-084 Valve - NG 885 SIT IPI 911-085 Valve - LP 885 SIT IPI 911-010 Stepper Motor - NG 911-011 Stepper Motor - LP 911-006 Pilot assembly IPI NG 2 Flame 911-007 Pilot assembly IPI LP 2 flame 910-100...
Page 51
notes Hampton® H15-10 Direct Vent Freestanding Gas Stove...
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below.
Page 53
warranty At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you).
Page 54
warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
Page 55
warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
Page 57
notes Hampton® H15-10 Direct Vent Freestanding Gas Stove...
Page 58
notes 58 | Hampton® H15-10 Direct Vent Freestanding Gas Stove...
