- Page 1 INSTRUCTION MANUAL FOR: RCR11 AIR CONDITIONER MAI/Prime Parts 5736 N. Michigan Road Indianapolis, IN 46228 Tel: 317-257-6811 Fax: 317-257-1590 W W W . M C L E A N P A R T S . N E T 10-1008-62 rev 10...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Receiving the Air Conditioner ..............1 Handling and Testing the Air Conditioner ........... 1 Installation ....................2 Design Data, Model Drawing ..............3 Mounting Instructions .................. 4 Components List ..................4 Wire Diagrams .................... 5 Temperature Control ................... 6 Principles of Operation ................ -
Page 3: Installation
Operate the air conditioner for five (5) to ten (10) minutes. No excessive noise or vibration should be evident during this run period. The condenser blower (ambient air), the evaporator impeller (enclosure air), and the compressor should be running. Condenser air temperatures should be warmer than normal room temperatures within a few minutes. The compressor is provided with automatic reset thermal overload protection. -
Page 4: Design Data, Model Drawing
RCR11 Series H x W x D: 10.47” (266) x 19” (483) x 21.47” (545) 2000-4000 BTU/Hr. (586 - 1172 Watts) Full BTU/Hr @ Shipping Load Max Amb Amb Temp Weight ° ° Model Voltage Amps Phase Temp Lbs/Kgs RCR11-0216-GXXX 50/60 9.0/9.0 1800/2000... -
Page 5: Mounting Instructions
RCR11 Mounting Cutout Dimensions RCR11 Series Components List Part Number (115 Volt) Part Number (230 Volt) Part Description 2000 BTU 4000 BTU 2000 BTU 4000 BTU Blower, Condenser 28-1064-01M 38-2019-04 28-1064-02M 38-2020-04 Blower, Evaporator 10-1091-121 10-1091-121 10-1091-122 10-1091-122 Capacitor, Compressor, Start/Run 10-1032-13 10-1032-09 10-1032-14... -
Page 6: Wire Diagrams
RCR11 Wire Diagram 4000 BTU UNIT 317-257-6811 WWW.McLeanParts.net 317-257-1590 fax 10-1008-62 rev 10... -
Page 7: Temperature Control
TEMPERATURE CONTROL The electromechanical thermostat is factory preset to 75°F/23°C. To change the temperature setting, remove the nylon plug from the back face of the unit. Use a standard screwdriver to adjust thermostat. For cooler temperatures turn clockwise, for warmer temperatures turn counterclockwise. PRINCIPLES OF OPERATION If electrical power to the air conditioner is interrupted and reapplied immediately, (within 3 to 5 seconds), the compressor may not restart due to the high back pressure of the compressor. - Page 8 Inlet Air Filter Con’t It is recommended that power to the air conditioner be interrupted intentionally when abnormally high compressor operating temperature causes automatic shutdown of the unit. The above described shutdown is symptomatic of clogged or dirty filter, thus causing a reduction in cooling airflow across the surface of the compressor and condenser coil.
-
Page 9: Trouble Shooting
Before recharging, make sure there are no leaks and that the system has been properly evacuated into a deep vacuum. TROUBLE SHOOTING Basic Air Conditioning Trouble Shooting Check List Check manufacturer’s nameplate located on the unit for correct power supply. 2. - Page 10 Symptoms and Possible Causes: SYMPTOM POSSIBLE CAUSE Unit won’t cool * Blowers/impellers not running * Compressor not running * Compressor runs, but has bad valves * Loss of refrigerant Compressor tries to start but won’t run * Low line voltage at start. Should be +/-10% rated voltage * Compressor motor stuck * Bad relay * Bad overload switch...
