  • Page 1 User Manual TREK-550 TREK-303 In-Vehicle Computing Box Smart Display User manual TREK-550 User manual...

  • Page 2: Declaration Of Conformity

    Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 3: Technical Support And Assistance

    Visit the Advantech web site at www.advantech.com/support for the latest information about the product. Contact the distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...

  • Page 4: Packing List

    TREK-550 series In-Vehicle Computing Box  USB/Audio Cable clip  Warranty card  Power cord: DC power inlet cable (180 cm - for TREK-550 only)  Video in/CAN cable  “Drivers, Utilities and User Manual" CD-ROM  End User License Agreement (XPE and WinCE model), please download driver and related document from www.advantech.com/support...

  • Page 5: Safety Instructions

    Replace only with same or equivalent type recommended by the manufacture. Discard used batteries according to the manufacturer’s instructions. 17. THE COMPUTER IS PROVIDED WITH CD DRIVES COMPLY WITH APPROPRIATE SAFETY STANDARDS INCLUDING IEC 60825. CLASS 1 LASER PRODUCT KLASSE 1 LASER PRODUKT TREK-550 User manual...
  • Page 6 E) Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (e.g. use of power strips)." TREK-550 User manual...
  • Page 7 Type, wie vom Hersteller empfohlen. Entsorgen Sie Batterien nach Anweisung des Herstellers. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. TREK-550 User manual...
  • Page 8 Maintenance: to properly maintain and clean the surfaces, use only approved products or clean with a dry applicator. CompactFlash: Turn off the power before inserting or removing CompactFlash storage cards. European Contact information: Advantech Europe GmbH Kolberger Straße 7 D-40599 Düsseldorf, Germany T el: 49-211-97477350 Fax: 49-211-97477300...

  • Page 9: Table Of Contents

    Rear side of the TREK-550 .......... 16 Figure 2.3 Side view of the TREK-550 .......... 16 Figure 2.4 B o tto m view of the TREK-550 ........17 Figure 2.5 To p view of the TREK-550 .......... 17 Installation Procedures..................17 2.2.1...
  • Page 10 RS-232 (COM9) / RS-485 (COM5) / J1708 (COM6) Connector………34 Table 5.6: RS232/485/J1708 connector……………………….…..34 DI / DO Connector…………………………………………………………………35 Table 5.7: DI/DO connector………………………………………….35 CAN/Video in Connector…………………… ……………………………………35 Table 5.8: CAN/Video in connector………………………………...35 LED Connector…………………… ………………………………………………36 Table 5.9: LED connector…………………………………………….36 Chapter SW demo utility set Up....37 Introduction…………………………………………………………………………38 TREK-550 User manual...
  • Page 11 6.3.2 Power Management utility program…………………………………………….43 6.3.3 Power Management Parameter settings………………………..…………….43 Figure 6.15 Power management test utility…………………………………43 6.3.4 TREK-550 power consumption……………………………………………………….43 GPIO Test…………………………………………………………………………………….…44 Figure 6.16 DI/O test …………………………………………………………………….44 Figure 6.17 Digital in……………………………………………………………………..…44 Figure 6.18 Digital out……………………………………………………………………45 Video in Test……………………………………………………………………………………...…45 Figure 6.19 Video test utility………………………………………….……………….…45 Dead reckoning……………………………………………………………………………….…..45...

  • Page 12: General Information

    Chapter General Information This chapter gives background information on the TREK-550 In-Vehicle Computing Box. Sections include:  Introduction  General Specifications  Dimensions TREK-550 User manual...

  • Page 13: Introduction

    (-30 to 70 degrees). TREK-550 also uses a special design to handle the critical issue of in-vehicle power. Special power protection (ISO7637-2/SAE J1455 Class A/ SAE J1113) and car power...

  • Page 14: General Specifications

    Video output: 1 x VGA output by DB-15 (independent display).  Video in: 2 x composite video input selection supported format (for rear view monitor) by RJ-45 connector  Mini PCI express bus expansion slot: Accepts full size mini PCI bus card. TREK-550 User manual...

  • Page 15: Dimensions

    Digital I/O: Isolated 4 digital input and 4 digital output  CAN bus: Support CAN V2.0B up to 500 kb/s.  Audio: 2 audio codecs, one is for smart display, one is for TREK-550 line out and mic in phone jack.  Optional modules:  ...

  • Page 16: System Setup

    Chapter Syst System Setup This chapter details system setup on TREK-550. Sections include:  A Quick Tour of the computer box  Installation Procedures  Running the BIOS Setup Program TREK-550 User manual...

  • Page 17: A Quick Tour Of The Vehicle Mounted

    A Quick Tour of the TREK-550 Computing box. Before starting to set up the In-Vehicle Computing Box, take a moment to become familiar with the locations and purposes of the controls, drives, connectors and ports, which are illustrated in the figures below.

  • Page 18: Installation Procedures

    “ignition” mark. Note! Ignition on/off setting: The TREK-550 supports an ignition on/off function so that you can power on/off the TREK-550 via the ignition signal/voltage and connect the TREK-550 vehicle ignition switch. Table 2.2.1 Pin Definition of Power Cord...

  • Page 19: Power Connector

    Power button Input Connector : Molex 430451200 Mating connector: Molex 0430251200 Figure 2.7. Power connector photo Note! Fuse holder: The fuse holder on the power cable is water/dust proof; you may change the fuse (5 Amp) easily by yourself. TREK-550 User manual...

  • Page 20: Running The Bios Setup Program

    These files are a very useful supplement to the information in this manual. For more updated driver please refers to Advantech website, www.advantech.com/support The drivers for TREK-550 are listed as below, please just execute the drivers for installation Device Version Intel SCH INF Update 8.8.0.1011...

  • Page 21: Hardware & Peripheral Installation

    Chapter Hardware & Peripheral Installation This chapter details the installation of hardware for TREK-550. Sections include:  Overview of Hardware Installation and Upgrading  Installing the Storage Device and Memory  Installing Optional Accessories  Fuse TREK-550 User manual...

  • Page 22: Overview Of Hardware Installation & Upgrading

    TREK-550. The following are instructions for accessory installation. 3.3.1 Installing TREK-550 peripheral modules There are 6 screws on the bottom of TREK-550, if you want to install the peripherals in TREK-550, please use M2 type screw to open the system. Figure 3.1 Install peripheral in the system...

  • Page 23: Installing The Minipci Type Wwan, Sim Card & Coin Battery

    The WWAN module is on the Mini PCI slot can be easily installed, just unlock the 6 screws from the bottom cover, you may easily install it, so as SIM card. Figure 3.2 Mini PCI type WWAN module, SIM card and coin battery from bottom view 3.3.4 Installing CF card Figure 3.4 Installing CF card TREK-550 User manual...

  • Page 24: Gps Module Is Unable To Be Installed By Customer

    GPS module is not allowed customer to install. Paired with TREK-303 Specifications See Appendix A TREK-550 provides both VGA function and LCD to connect with TREK-303, it can be send out by different content, clone to VGA output. TREK-550 User manual...

  • Page 25: Chapter 4 Jumper Settings And Connectors

    In-Vehicle Computing Box hardware, including instructions on setting jumpers and connecting peripherals, and how to set switches and read indicators. Be sure to read all the safety pre- cautions before beginning the installation procedure. Sections include: Jumpers Setting TREK-550 User manual...

  • Page 26: Setting Jumpers And Switches

    A pair of needle-nose pliers may be helpful when working with jumpers. If there are any doubts about the best hardware configuration for the application, contact the local distributor or sales representative before making any changes. An arrow is used on the motherboard to indicate the first pin of each jumper. TREK-550 User manual...

  • Page 27: Locations Of The Jumpers And Connector

    4.1.1 Locations of the Jumpers and Connector CN14 CN15 CN11 CN13 CN10 CN12 Figure 4.1 Locations of jumpers and connectors on top side the motherboard. SODIMM1 CN16 TREK-550 User manual...

  • Page 28: Daughter Board

    Table 4.1.2.1: Jumpers on motherboard Location Function Vehicle input voltage selection CMOS clear for external RTC Pin9 of COM3 function selection Table 4.1.2.2: Jumpers on daughter board Location Function CAN bus termination selection Pin9 of COM8 function selection DI/GPS Function selection TREK-550 User manual...

  • Page 29: Connectors

    Line-Out phone jack Mic-In phone jack Video-In and CAN bus connector CN11 WWAN module connector CN12 Bluetooth module connector CN13 Mini-PCIe Socket (USB interface, for WWAN module) Mini card (USB interface) CN14 GPS module connector CN15 SIM holder TREK-550 User manual...

  • Page 30: Jumper Settings

    Table 4.2.1: Clear CMOS / External RTC (JP1) Normal Operation (Default) Clear CMOS 4.2.2 Power Input Voltage Setting (JP1) TREK-550 must be configured properly according the vehicle power input ragnge. Table 4.4.2: Power Input Voltage Selection (JP1) Input (Default) 24V Input 4.2.3 Pin 9 of COM3 Function Selection (JP3) Pin 9 on COM3 port can be configured as RI, 5V or 12V output.

  • Page 31: Di/Gps Function Selection (Sw2)

    USB serial converter, and need driver support to work. In Advantech provided WES (Windows Embedded Standard), WinXPe and Win CE 6.0 OS, the four USB-to-Serial serial ports are fixed from COM8 to COM11).

  • Page 32: Chapter 5 Pin Assignments

    Chapter Pin Assignments This chapter explains pin assignments on the TREK-550. Sections include:  Front/side Connector  Power connector  Smart display connector  RS232 Connectors  DI/DO connectors TREK-550 User manual...

  • Page 33: 5.1 Front Side Connectors

    5.3 Power Connector (12/ 24V; 6 ~ 36V) Molex Manufacturer part no. 0430451200 Table 5.3: Power Connector Signal Signal Chassis Ground Ground Ground (Reserved) (Reserved) (Reserved) Power Input (6~36 VDC) Power Input (6~36 VDC) Acc Ignition Input Ground (Reserved) Power Button Input TREK-550 User manual...

  • Page 34: Smart Display Connector

    +12VDC output (+/- 5%, max 1A) +12VDC output (+/- 5%, max 1A) +12VDC output (+/- 5%, max 1A) Power Ground Power Ground Power Ground Power Ground RS232 TXD2 # RS232 RXD2 # RS232 RTS2 Power Button Input # Audio Ground Mono. Line-out TREK-550 User manual...

  • Page 35: Rs-232 Connector (Com3, Com8)

    +V12 (max. 250mA) RS-232 (COM9) / RS-485 (COM5) / J1708 (COM6) Connector Table 5.6: RS-232 / RS-485 / J1708 Connector Signal Signal RS-232 RTS RS-232 RXD# RS-232 TXD RS-232 CTS Ground RS-485 D- RS-485 D+ J1708 D- J1708 D+ TREK-550 User manual...

  • Page 36: Di / Do Connector

    *Note. Regarding the setting of Pin3/4, please refer paragraph 4.2.5 (DI/GPS Function Selection ). CAN / Video-In Connector Table 5.8: CAN / Video-In Connector Signal Signal CAN_H CAN_L CAN_SHIELD CAN_SHIELD Video In 2 Video Ground Video In 1 Video Ground TREK-550 User manual...

  • Page 37: Led Connector

    LED indicator Green Green Green (RF Blue (GPS (RF link) (power) (Storage data transfer) operation) access) TREK-550 User manual...

  • Page 38: Chapter 6 Sw Demo Utility Set Up

    Chapter Software demo utility setup This appendix explains the software demo utility for TREK-550. Sections include:  Introduction  How to set up demo utility TREK-550 User manual...

  • Page 39: Introduction

    Introduction T o make the hardware easier to access for programmers, Advantech has developed a demo utility in order to let customer test the functions on TREK-550. This document describes detailed information for each Advantech demo utility so that application developers can become more familiar with using them.

  • Page 40: Figure 6.3 J1939 Test

    Figure 6.3 J1939 test -1 Figure 6.4 J1939 test -2 6.1.2 Execute CAN demo utility Figure 6. 9 CAN test TREK-550 User manual...

  • Page 41: Rtc Test

    1. For RTC Time setting: You may set year, month, date, and time show as below. Figure 6.10 RTC test -1 Figure 6.11 RTC test -2 Figure 6. 12 RTC test -3 Figure 6. 13 RTC test -4 TREK-550 User manual...

  • Page 42: Figure 6.14 Rtc Test-5

    To avoid draining out the car battery, low-battery protection is involved to ensure the car battery is capable to start the vehicle. When the system is ON, VPM controller will monitor the car battery voltage. If the battery voltage is lower than a programmable TREK-550 User manual...

  • Page 43: Power Management Mechanism

    ON_DELAY LOW_HARD_DELAY is Pressed Count down Countdown to 0 to 0 Car_batt_Vol Count down < Batt_Threshold to 0 System is ON LOW_DELAY Car_batt_Vol > Batt_Threshold Ignition → ON Ignition → OFF OFF_EVENT_DELAY Count down to 0 HARD_OFF_DELAY TREK-550 User manual...

  • Page 44: Power Management Utility Program

    Execute IMCDemo.exe file, see the icon below. 6.3.3 Power Management Parameter settings The parameters for power management on TREK-550 could be read or modified by Demo utility (see the image below) or SDK/API. Figure 6.15 Power management test utility 6.3.4...

  • Page 45: Gpio Test

    Pin1~Pin3. Next pick Digital output to execute the same procedure. See figure 6. Figure 6.16 DI/O test a. Digital Output  isolated relay driver output b. Digital Input  isolated dry contact input Figure 6.17 Digital in TREK-550 User manual...

  • Page 46: Figure 6.18 Digital Out

    10 sec. Figure 6.16 Video test utility Dead reckoning Dead reckoning (DR) supplements GPS satellite position information with heading and distance data provided by additional sensors. When GPS satellites TREK-550 User manual...

  • Page 47: G- Sensor

    G-sensor (3-axis accelerometer) A 3-axis accelerometer is integrated in TREK-550. This could be used to characterize driver behavior such as hard accelerations, braking, and cornering. This also can tell users other significant information that can be used in accident reconstruction and etc.
  • Page 48 Appendix TREK-303 This This appendix explains the TREK-303 detailed information TREK-550 User manual...

  • Page 49: Appendix A Paired With Trek-303

    Paired with TREK-303 Specifications TREK-303 Specification Note! The Brightness control is adjusted by the auto light sensor in the front panel as default; it is also defined by button on the front panel by manual. The color LCD display TREK-550 User manual...
  • Page 50 +12VDC input (+/- 5%, max 1A) +12VDC input (+/- 5%, max 1A) Power Ground Power Ground Power Ground Power Ground RS232 RXD2 # RS232 TXD2 # Power Button Input # (connect RS232 RTS2 with system box) Audio Ground Mono. Line-in TREK-550 User manual...
  • Page 51 22 23 24 25 26 27 28 32 33 34 Black black Black Black Black Black Black Blue white Ground yellow Green Blue Purple Grey white Black Orange Brown Yellow green blue purple grey TREK-303 Hotkey Utility Execute IMC demo utility TREK-550 User manual...

  • Page 52: Figure A.1 Hotkey Utility

    0 ~100. 6. Key Status: When you press Hot key, the status will change from 0 to 1. 7. Key function Definition: You may set the parameter to connect the application program of the hot key. TREK-550 User manual...
  • Page 53 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permission of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2010 TREK-550 User manual...
