Gige vision monochrome / color cmos poe camera (72 pages)
Summary of Contents for Omron STC-SBA503POE
Page 1
No.13S094-05 GigE Vision Color / Monochrome CMOS PoE Camera STC-SBA503POE (5M / Monochrome) Color STC-SCA503POE (5M / Product Specifications and User’s Guide STC-SCA503POE / STC-SBA503POE 1/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 3
ALC settings procedure ......................... 40 White balance (Only available for the color cameras) ............41 White balance control methods ..................... 41 STC-SCA503POE / STC-SBA503POE 3/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 4
AnalogControl ..........................53 TransportLayerControl ........................ 54 UserSetControl ..........................55 IPEngine ............................55 SpecialFeatures ........................... 56 10 Revision History ............58 STC-SCA503POE / STC-SBA503POE 4/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 5
This will cause of fire or malfunction. camera. This will cause of fire, electrification or malfunction. STC-SCA503POE / STC-SBA503POE 5/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 6
This will cause of electrification. [Disposal] Caution It is necessary to dispose as industrial waste. STC-SCA503POE / STC-SBA503POE 6/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility. “Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the camera malfunction is not included. STC-SCA503POE / STC-SBA503POE 7/59 Product Specifications and User’s Guide...
No.13S094-05 Introduction This document describes the specification of the following cameras: STC-SBA503POE / STC-SCA503POE Features Support PoE (Power over Ethernet Support) Maximum Frame Rate (Full Scanning): 14 fps @ 5M 8bits CMOS (Rolling Shutter / Global Reset) ...
Edge Preset Trigger / Pulse Width Trigger / Free run Communication UART communication through Ethernet port Interface IEEE802.3 (1000BASE-T) Protocol GigE Vision 1.2 GenICam 1.4 Default: Bold STC-SCA503POE / STC-SBA503POE 9/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 10
(*1) The horizontal and vertical can be set individually for binning and decimation functions. The combination of binning and decimation function is defined. The binning and decimation function cannot use simultaneously. (*3) STC-SCA503POE / STC-SBA503POE 10/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
No.13S094-05 IR Cut Filter (STC-SCA503POE) STC-SCA503POE / STC-SBA503POE 12/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Taking these steps will maintain the heat rating of the electronic components of the camera. Upper side of camera Measuring point STC-SCA503POE / STC-SBA503POE 13/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
100 MB Transferring Please use a 1GB supported NIC, Network Switcher and LAN cable. Check that the NIC and Network Switcher being used is “1GB transferring”. STC-SCA503POE / STC-SBA503POE 14/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
1) FrameTriggerWait (initial setting for I/O-1) 2) UserOutput 3) ExposureActive (initial setting for I/O-2) 4) TriggerAuxiliary 5) TriggerInternal 6) SensorReadOut 7) StrobeSignal STC-SCA503POE / STC-SBA503POE 15/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 16
The SensorReadOut signal is the FVAL signal, which is the image output period of the time. 7) StrobeSignal The StrobeSignal signal is the strobe control signal. STC-SCA503POE / STC-SBA503POE 16/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
No.13S094-05 Equivalent Circuit for the Input Pin of the I/O Connector STC-SCA503POE / STC-SBA503POE 17/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
No.13S094-05 Typical Input Circuit STC-SCA503POE / STC-SBA503POE 18/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Typical Output Circuit Note: Value of Vcc and Pull up register can be set within the spec of transistor. STC-SCA503POE / STC-SBA503POE 19/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
ExposureTimeRaw on GenICam Video output Output Signal FrameTriggerWait ExposureActive TriggerAuxiliary TriggerInternal SensorReadOut StrobeSignal StrobeSignalOnTime on GenICam StrobeSignalDelay on GenICam STC-SCA503POE / STC-SBA503POE 20/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
ExposureTimeRaw on GenICam Video output Output Signal FrameTriggerWait ExposureActive TriggerAuxiliary TriggerInternal SensorReadOut StrobeSignal StrobeSignalOnTime on GenICam StrobeSignalDelay on GenICam STC-SCA503POE / STC-SBA503POE 21/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Pixel21 of Pixel22 of Data Data Pixel (m, n) of Data: nth pixel of the mth line being transferred STC-SCA503POE / STC-SBA503POE 24/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Sensor time exposure Video out Note 1: The exposure time is set by active pulse duration of trigger signal. STC-SCA503POE / STC-SBA503POE 25/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Note 1: The trigger signal will be removed by the filtering if the pulse width of the input trigger signal is less than 60 CLK. Please input a trigger signal with more than 61 CLK pulse width. Note 2: The exposure will start 8H after the rising edge of the trigger signal. STC-SCA503POE / STC-SBA503POE 26/59 Product Specifications and User’s Guide...
Trigger Input (Positive) Exposure Time Image Out Note 1: The exposure time is set by the preset electronic shutter speed. STC-SCA503POE / STC-SBA503POE 27/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Note 1: The trigger signal will be removed by the filtering if the pulse width of the input trigger signal is less than 60 CLK. Please input a trigger signal with more than 61 CLK pulse width. Note 2: The exposure will start 8H after the rising edge of the trigger signal. STC-SCA503POE / STC-SBA503POE 28/59 Product Specifications and User’s Guide...
Sensor Exposure exposure time Video out Note 1: The exposure time is set by the preset electronic shutter speed. STC-SCA503POE / STC-SBA503POE 29/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Data Tx *Note1: When changing this CMOS reset type, please set the free-run mode (TriggerMode = Off) at first. If not, image may not come up. STC-SCA503POE / STC-SBA503POE 30/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Vertical offset for the output image (lines). Default: 0, Adjustable steps: 2 liens The ROI area settings are below: OffsetY Height ROI area OffsetX Width STC-SCA503POE / STC-SBA503POE 31/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 32
2,592 pixels Adjustment steps 8 pixels Height Range 32 to 1,944 lines Default 1,944 lines Adjustment steps 2 lines STC-SCA503POE / STC-SBA503POE 32/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
The image becomes the center portion of the "Binning" image. The Binning’s frame rate is about 23 fps *Note: Sensitivity may not increase on Vertical. 2592 STC-SCA503POE / STC-SBA503POE 33/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
At 12bits output: Black level (grayscale) = BlackLeve * 4 At 10bits output: Black level (grayscale) = BlackLevel At 8bits output: Black level (grayscale) = BlackLevel / 4 STC-SCA503POE / STC-SBA503POE 37/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
When 0 sets, Average: 100%, Peak: 0%. The ALC control with the brightness average. When 255 sets, Average: 0%, Peak: 100%. The ALC control with the brightness peak. When 128 sets, Average: 50%, Peak: 50%. STC-SCA503POE / STC-SBA503POE 38/59 Product Specifications and User’s Guide...
Selection: ON (Continuous) or OFF (Off). Default: OFF AGCRange Integer type Maximum gain. Range: 8 to 40, Default: 40 This is the maximum gain for AGC. STC-SCA503POE / STC-SBA503POE 39/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
8. Sets Max_ShutterTime, if the auto shutter is using. 9. Sets “Continuous” at GainAuto, if AGC is using. 10. Sets “Continuous” at ExposureAuto, if the auto shutter is using. STC-SCA503POE / STC-SBA503POE 40/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
B white balance gain for preset2. Default: 0 BalanceRatio_Gb_Preset2 Integer type Gr white balance gain for preset2. Default: 0 STC-SCA503POE / STC-SBA503POE 41/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Sets OFF at BalanceWhiteAuto automatically after set Balance_X_Once. Push to set white balance setting procedure 1. Sets the flat white target. 2. Sets Once at BalanceWhiteAuto. STC-SCA503POE / STC-SBA503POE 42/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
1. Sets the white balance gain for the preset1, 2 or 3. (X: 1 to 3) (BalanceRatio_R_PresetX, BalanceRatio_Gr_PresetX, BalanceRatio_B_PresetX, BalanceRatio_Gb_PresetX) 2. Sets PresetX (X: 1 to 3) at BalanceWhiteAuto. STC-SCA503POE / STC-SBA503POE 43/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
12bits process in the camera. The white balance calculation area settings are below: WB_WindowV1 White balance gain calculation area WB_WindowV2 WB_WindowH1 WB_WindowH2 STC-SCA503POE / STC-SBA503POE 44/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
It is necessary to use the virtual com port communication (eBUS SDK: PvSerialPort class) to write the gamma table to the camera. The gamma table cannot write the camera with GenICam parameter. Please refer the other document for the details of the gamma table writing. STC-SCA503POE / STC-SBA503POE 45/59 Product Specifications and User’s Guide...
“UserSet1” is selected UserSetSelector at UserSetSelector The camera settings saving procedure 1. Selects “UserSet1” at UserSetSelector. 2. Executes UserSetSave. STC-SCA503POE / STC-SBA503POE 46/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
The camera settings initialization procedure 1. Selects “Default” at UserSetSelector. 2. Executes UserSetLoad. 3. Selects “UserSet1” at UserSetSelector. 4. Executes UserSetSave. STC-SCA503POE / STC-SBA503POE 47/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Sets Software at TriggerSource for the software trigger signal input. Sets Hardware at TriggerSource for the hardware =Hardware on GenICam TriggerSource=Line0 on GenICam STC-SCA503POE / STC-SBA503POE 48/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Command type paramter control Command type parameter such as “TriggerSoftware” e.g. TriggerSoftware generating [C++] PvDevice.GetGenParameters()->ExecuteCommand( “TriggerSoftware” ); [C#] PvDevice.GenParameters.ExexuteCommand( “TriggerSoftware” ); STC-SCA503POE / STC-SBA503POE 50/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Horizontal offset from the origin to the region of interest (in pixels). OffsetY Vertical offset from the origin to the region of interest (in pixels). STC-SCA503POE / STC-SBA503POE 51/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Controls the invertion of the signal of the selected output line of LineSource0. LineInverter1 Controls the invertion of the signal of the selected output line of LineSource1. STC-SCA503POE / STC-SBA503POE 52/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
BlackLevel Controls the black level as an absolute physical value. This represents a DC offset applied to the video signal. STC-SCA503POE / STC-SBA503POE 53/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Controls the port to which the device must send message. GevMCDA Controls the destination IP address for the message channel. STC-SCA503POE / STC-SBA503POE 54/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Selects the feature User Set to load and make active by default when the device is UserSetDefaultSelector reset. IPEngine Name Description ProgrammableLogicController Category that contains the Programmable Logic Controller (PLC) features. STC-SCA503POE / STC-SBA503POE 55/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
The value for auto white balance is determined with the color information of the pixels, which is more than this threshold. ModeCode Mode code. HardwareVersion Hardware version. STC-SCA503POE / STC-SBA503POE 56/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 57
No.13S094-05 Name Description FPGAFirmwareVersion FPGA Firmware Version. FirmwareVersion Firmware Version. SerialNumber Serial number. CustomerCode Customer code. STC-SCA503POE / STC-SBA503POE 57/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
GigE Vision is trademark of AIA. GenICam is trademark of EMVA. Other company names and product names in this document are trademarks of their respective owners. STC-SCA503POE / STC-SBA503POE 58/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
Page 59
No.13S094-05 (888)687-6877 STC-SCA503POE / STC-SBA503POE 59/59 Product Specifications and User’s Guide For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
