1.3M USB Camera
STC-S133UVC Color CMOS Cameras
STC-S133UVC-BL
STC-S133UVC-BLL
STC-S133UVC-BLCS
STC-S133UVC-DBL
STC-S133UVC-DBLL
STC-S133UVC-DBLCS (1.3M / CS mount / Dual Pass Filter / Board)
STC-S133UVC-ALL
STC-S133UVC-ALCS
STC-S133UVC-DALL
STC-S133UVC-DALCS (1.3M / CS mount / Dual Pass Filter / Cased)
Product Specifications and User's Guide
STC-S133UVC
Product Specifications and User's Guide
(1.3M / No lens mount / IR Cut Filter / Board)
(1.3M / M12 lens mount / IR Cut Filter / Board)
(1.3M / CS mount / IR Cut Filter / Board)
(1.3M / No lens mount / Dual Pass Filter / Board)
(1.3M / M12 lens mount / Dual Pass Filter / Board)
(1.3M / M12 lens mount / IR Cut Filter / Cased)
(1.3M / CS mount / IR Cut Filter / Cased)
(1.3M / M12 lens mount / Dual Pass Filter / Cased)
No.17S021-01
1/63
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Omron STC-S133UVC-BL
Summary of Contents for Omron STC-S133UVC-BL
- Page 1 No.17S021-01 1.3M USB Camera STC-S133UVC Color CMOS Cameras STC-S133UVC-BL (1.3M / No lens mount / IR Cut Filter / Board) STC-S133UVC-BLL (1.3M / M12 lens mount / IR Cut Filter / Board) STC-S133UVC-BLCS (1.3M / CS mount / IR Cut Filter / Board) STC-S133UVC-DBL (1.3M / No lens mount / Dual Pass Filter / Board)
-
Page 2: Table Of Contents
Electronic specifications ......................9 Spectral Sensitivity Characteristics ..................11 CMOS Sensor Spectral Sensitivity Characteristics ............... 11 IR Cut Filter Spectral Sensitivity Characteristics (STC-S133UVC-BL / STC-S133UVC-BLL / STC-S133UVC-BLCS / STC-S133UVC-ALL / STC-S133UVC-ALCS) .......... 12 Dual Pass Filter Spectral Sensitivity Characteristics (STC-S133UVC-DBL / STC-S133UVC-DBLL / STC-S133UVC-DBLCS / STC-S133UVC-DALL / STC-S133UVC-DALCS) ........................ - Page 3 No.17S021-01 STC-S133UVC-BLL / STC-S133UVC-DBLL ................19 STC-S133UVC-BLCS / STC-S133UVC-DBLCS ..............20 STC-S133UVC-ALL / STC-S133UVC-DALL ................21 STC-S133UVC-ALCS / STC-S133UVC-DALCS ..............22 Communication control software users guide ..........23 Requirement software ......................23 Connecting configuration ...................... 23 Communication settings......................23 Basic operating procedure ....................24 The descriptions for the buttons ..................
- Page 4 No.17S021-01 OSD operation by camera control software ................. 51 OSD menu ............................52 SETUP MENU ................................52 SHUTTER/AGC ................................53 WHITE BAL .................................. 54 PICT ADJUST ................................56 DEFOG..................................57 WDR/ATR ..................................58 Day/Night ..................................59 DNR....................................59 PRIVACY ..................................60 LANGUAGE .................................
- Page 5 No.17S021-01 Precautions for safe use Please read carefully this “Precautions for safe use” before use the camera. Then the camera uses correctly with agreeing with below notes. In this “Precautions for safe use”, notes divides into “Warning” and “Caution” to use the camera safety and prevent to harm and damage.
- Page 6 No.17S021-01 Caution Do not grounding DC power (+) of all devices It is necessary to wiring and mounting that is that are connect to the camera. specified in the specifications for this camera. The camera housing is connecting to 0 V line of This will cause of fire or malfunction.
-
Page 7: Product Precautions
No.17S021-01 Product Precautions Do not give shock to the camera. Do not haul or damage the camera cable. Do not wrap the camera with any material while using the camera. This will cause the internal camera temperature to increase. ... -
Page 8: Introduction
No.17S021-01 Introduction This document describes the specifications of the following cameras STC-S133UVC-BL / STC-S133UVC-BLL / STC-S133UVC-BLCS (IR Cut Filter, Board models) STC-S133UVC-DBL / STC-S133UVC-DBLL / STC-S133UVC-DBLCS (Dual Pass Filter, Board models) STC-S133UVC-ALL / STC-S133UVC-ALCS (IR Cut Filter, Cased models) STC-S133UVC-DALL / STC-S133UVC-DALCS... -
Page 9: Specifications
No.17S021-01 Specifications Electronic specifications Model Number STC-S133UVC-BL / STC-S133UVC-BLL / STC-S133UVC-BLCS / STC-S133UVC-DBL / STC-S133UVC-DBLL / STC-S133UVC-DBLCS STC-S133UVC-ALL / STC-S133UVC-ALCS / STC-S133UVC-DALL / STC-S133UVC-DALCS Image sensor 1/3.2" 1.27M Progressive CMOS (SONY ISX017) Video signal format USB3.0 1,280 (H) x 720 (V) 60 / 50 / 30 / 25 fps, 1,280 (H) x 960 (V) 30 / 25 fps (Default: 1,280 (H) x 720 (V) 60 fps) USB2.0... - Page 10 No.17S021-01 Precautions (*1) The sensitivity is measuring the luminance when white level achieved 100 % in below conditions. Camera Setting Environment Parameter Setting Parameter Setting Gain Up 0 dB Light Source Light Box (White) Color temperature 5,100K White Balance Optimum Lens Electrical Shutter 1/30 seconds...
-
Page 11: Spectral Sensitivity Characteristics
No.17S021-01 Spectral Sensitivity Characteristics CMOS Sensor Spectral Sensitivity Characteristics STC-S133UVC 11/63 Product Specifications and User’s Guide... -
Page 12: Ir Cut Filter Spectral Sensitivity Characteristics (Stc-S133Uvc-Bl / Stc-S133Uvc-Bll / Stc-S133Uvc-Blcs / Stc-S133Uvc-All / Stc-S133Uvc-Alcs)
No.17S021-01 IR Cut Filter Spectral Sensitivity Characteristics (STC-S133UVC-BL / STC-S133UVC-BLL / STC-S133UVC-BLCS / STC-S133UVC-ALL / STC-S133UVC-ALCS) Dual Pass Filter Spectral Sensitivity Characteristics (STC-S133UVC-DBL / STC-S133UVC-DBLL / STC-S133UVC-DBLCS / STC-S133UVC-DALL / STC-S133UVC-DALCS) Transmittance (%) 1050 1150 STC-S133UVC 12/63 Product Specifications and User’s Guide... -
Page 13: Mechanical Specifications
No.17S021-01 Mechanical Specifications STC-S133UVC-BL / STC-S133UVC-DBL Model Number STC-S133UVC-BL STC-S133UVC-DBL Dimensions (*1) 23 (W) x 20 (H) x 15.1 (D) mm Optical Filter IR Cut Filter built in Dual Pass Filter built in Lens Mount No lens mount Camera Mounting... -
Page 14: Stc-S133Uvc-Alcs / Stc-S133Uvc-Dalcs
M2.5 screw holes (Two on Top, bottom and both side plate) Weight Approximately 24 g (*1) Excluding projection Environmental Specifications STC-S133UVC-BL / STC-S133UVC-BLL / STC-S133UVC-BLCS / Model Number STC-S133UVC-DBL / STC-S133UVC-DBLL / STC-S133UVC-DBLCS / STC-S133UVC-ALL / STC-S133UVC-ALCS / STC-S133UVC-DALL / STC-S133UVC-DALCS Operational Temperature / Humidity Environmental Temperature: 0 to +55 deg. -
Page 15: Connector Specifications
No.17S021-01 Connector specifications STC-S133UVC-BL / STC-S133UVC-BLL / STC-S133UVC-BLCS / STC-S133UVC-DBL / STC-S133UVC-DBLL / STC-S133UVC-DBLCS USB3.0 micro B type Bottom of camera STC-S133UVC-ALL / STC-S133UVC-ALCS / STC-S133UVC-DALL / STC-S133UVC-DALCS USB3.0 micro B type STC-S133UVC 15/63 Product Specifications and User’s Guide... -
Page 16: To Use The Camera
No.17S021-01 To use the camera Windows system Requirement software Camera control software: KSACtrl (version 2.02 or newer) OSD software: S133Control (The camera settings are changeable with on screen display) * UVC camera supported viewer software (UVC Viewer) is required to obtain the image. Software installation CDC driver for communicate to the camera, install before camera connects to the PC. -
Page 17: Other
No.17S021-01 Other When the camera connecting to USB2.0 port, the center ROI image is output and field of view becomes narrow. USB3.0 1,280 (H) x 720 (V): 60 / 50 / 30 / 25 fps, 1,280 (H) x 960 (V): 30 / 25 fps 800 (H) x 600 (V) 25 fps, 640 (H) x 480 (V): 30fps / 25 fps USB2.0 * with the image center ROI output... -
Page 18: Dimensions
No.17S021-01 Dimensions STC-S133UVC-BL / STC-S133UVC-DBL (14.1) 11.5 φ 23 Image Optical Filter 4.87 (in Air) 4-M2 Depth2.5 4-M2 Depth2.5 (2-M2 on other side) Unit: mm STC-S133UVC 18/63 Product Specifications and User’s Guide... -
Page 19: 5.2 Stc-S133Uvc-Bll / Stc-S133Uvc-Dbll
No.17S021-01 5.2 STC-S133UVC-BLL / STC-S133UVC-DBLL (16.1) 13.5 M12 X P0.5 φ 25 4-M2 Depth3.0 Optical Filter 4-M3 Depth3.0 (2-M3 on other side) Unit: mm STC-S133UVC 19/63 Product Specifications and User’s Guide... -
Page 20: Stc-S133Uvc-Blcs / Stc-S133Uvc-Dblcs
No.17S021-01 STC-S133UVC-BLCS / STC-S133UVC-DBLCS (21.7) 19.1 13.6 CS mount φ 23 Optical Filter 4-M2 Depth2.5 (2-M2 on other side) Unit: mm STC-S133UVC 20/63 Product Specifications and User’s Guide... -
Page 21: Stc-S133Uvc-All / Stc-S133Uvc-Dall
No.17S021-01 STC-S133UVC-ALL / STC-S133UVC-DALL 10.4 M12x0.5 R1.6 Image 4-M2 Depth3.0 Optical Filter 15.27 (in Air) Both sides are same 2-M2.5 Depth3.0 (Top, bottom and both sides) 2-M2 Depth4.0 Unit: mm STC-S133UVC 21/63 Product Specifications and User’s Guide... -
Page 22: Stc-S133Uvc-Alcs / Stc-S133Uvc-Dalcs
No.17S021-01 STC-S133UVC-ALCS / STC-S133UVC-DALCS 25.6 10.3 CS Mount R1.6 Optical Filter 14.6 Both sides are same 2-M2.5 Depth3.0 (Top, bottom and both sides) 2-M2 Depth4.0 Unit: mm STC-S133UVC 22/63 Product Specifications and User’s Guide... -
Page 23: Communication Control Software Users Guide
No.17S021-01 Communication control software users guide Requirement software Control software KSACtrl v2.02 or newer Connecting configuration When KSACtrl (v2.02 or newer) is installing, the installation menu for CDC driver is added to the program menu. Please install CDC driver before STC-S133UVC camera connects to the PC. Communication settings UART (RS232C compliant), Binary communication Setting... -
Page 24: Basic Operating Procedure
No.17S021-01 Basic operating procedure The camera communication software (KSACtrl) is usable after install KSACtrl software. Start KSACtrl software. Select the COM port number to use the camera communication by selecting “Port Setting” under “Comm (C)” in the menu. Select “Read All” button to read all of the register information from the camera. All of the camera settings are configurable through the camera control software. -
Page 25: The Descriptions For The Buttons
No.17S021-01 The descriptions for the buttons Read All Read out all camera settings in the camera. Please select this button every time when the camera power is turning on. This software stores as the camera default settings in to the Flash memory on the camera when first time select “Read All”... -
Page 26: The Descriptions Of The Functions
No.17S021-01 The descriptions of the functions Menue File(F) Save As[DSP->File]… Read the camera settings and creates the camera settings file. Open[File->DSP]… Load the camera settings from the camera settings file then apply to the camera. Open[File->Flash]… Load the camera settings from the camera settings file then apply to the camera and save the camera settings in to the flash memory. -
Page 27: Shutter/Gain Tab
No.17S021-01 Shutter/Gain Tab Exposure Control Mode (Default: AE) The brightness level is adjusting with the shutter and gain automatically. It is necessary to set the shutter and the gain at “Normal AE” Tab. HOLD The shutter and gain are holding. When the brightness of the target is changed, the camera does not adjust the brightness. Scale ME The brightness level is adjusting by the shutter and gain settings. - Page 28 No.17S021-01 Minimum / Maximum shutter time, Minimum / Maximum Gain Set the limit for the shutter and gain. Shutter Priority time The AE becomes the shutter prioritized AE when setting other than “0” while AE mode. It is necessary to select the value that between the minimum and maximum shutter time. The shutter is fixed as the selected shutter time and the brightness level is adjusting by the gain.
- Page 29 No.17S021-01 Flicker-less AE Mode (Default: Auto) Auto When the power on the camera with auto flicker-less, the default: condition is “OFF” and the function does not work unless detecting the flicker. The shutter time is adjusting continuously when the flicker less function starting. The flicker-less function is Off when the brightness of image becoming bright from 1/100seconds or 1/120 seconds condition, or the flicker less reset function is 50Hz / 60Hz Forced This mode forces to 50Hz/60Hz flicker less function even does not detect the flicker.
-
Page 30: Lens Tab
No.17S021-01 Lens Tab The lens compensation settings are selectable in this Tab. Vignetting and distortion Select “Enable” or “Disable” for the vignetting compensation and distortion compensation functions. Please select “Enable” if the vignetting or distortion compensation function uses. (Default: Disable) Vignetting compensation Select “Enable”... - Page 31 No.17S021-01 Distortion compensation settings KNOT K0 (optical center) to KNOT K13 (edge) are the compensation points for the distortion compensation. When set the greater value, the distortion is reduced. When set the smaller value, the distortion is extended. There are four types (A, B, C and D) of the compensation points are available. Distortion compensation OFF Distortion compensation ON STC-S133UVC...
-
Page 32: Osd Tab
No.17S021-01 OSD Tab OSD settings are selectable in this Tab. OSD is available when the resolution is 1,280 x 720 or 1,280 x 900. The OSD is usable with “Up”, “Down”, “Left”, “Right” and “Enter” buttons. Save button Save the OSD horizontal and vertical start position for the OSD parameter load is valid. Note. - Page 33 No.17S021-01 Cursor, character and character edge settings Cursor blend ratio / Character blend ratio Set the transparent ratio for the cursor and character of the OSD. Cursor Brightness / Character Brightness Set the brightness for the cursor and character of the OSD. Cursor Cb / Cursor Cr / Character Cb / Character Cr Set the color (Cb and Cr) for cursor and character of the OSD.
-
Page 34: Wdr Tab
No.17S021-01 WDR Tab The image is composed with two or three different shutter time images to compensate the clipped white image and crushed shadow image. Wide Dynamic Range (Default: Auto) Auto: WDR exposure and long exposure switch automatically for the object condition. WDR fixed when select “Long exposure fixed”... - Page 35 No.17S021-01 High Luminance Compensation (HLC) The high luminance compensation function is improved the visibility for the license plate under the dark condition with the strong light (like headlights), with suppression and mask process. H-luminance threshold ON-OFF Set the threshold for high luminance compensation from ON to OFF H-luminance threshold OFF-ON Set the threshold for high luminance compensation from OFF to ON L-luminance threshold ON-OFF...
-
Page 36: Ae Weight Tab
No.17S021-01 AE Weight Tab Photometry mode It is possible to keep the brightness level or the specific image are by adjusting the weight of the histogram for the area or the brightness. The photometry mode is selectable from “Average”, “Center”, “Spot” and “Histogram”. The average brightness of the full image uses for the average photometry mode. -
Page 37: Normal Ae Tab
No.17S021-01 Normal AE Tab Set the shutter and gain for the normal AE mode. 5 steps control rage for the shutter and gain is selectable for Normal AE. Please set from 1 (Bright) to 5 (Dark). Please set with the monotonous inclement. The default settings for the shutter and gain for 5 steps control are in below table. -
Page 38: Full Me Tab
No.17S021-01 Full ME Tab Set the shutter and gain for the full ME AE mode. Set the shutter speed and gain for the long exposure, short exposure 1 and short exposure 2. STC-S133UVC 38/63 Product Specifications and User’s Guide... -
Page 39: Ae Mask Tab
No.17S021-01 AE Mask Tab Set the mask frame for AE frame detection. Set mask frame is excluding frame for AE detection. The mask frame can set up to 16 frames. In case of the image has vignetting, the optimized brightness of the image can keep it by excluding the vignetting area for AE detection. -
Page 40: Whitebalance Tab
No.17S021-01 WhiteBalance Tab Push lock pin White balance mode ATW mode The white balance control automatically with the indoor/outdoor judgement and estimate the light source. ATW mode is less inference for the color saturated target. All pull in mode The white balance control automatically without dependence of the indoor/outdoor light source. The wide rage color pull into the white. - Page 41 No.17S021-01 White balance offset This function is shifting the convergence point by adding the offset. This function is useful when keep the color. User mode Five different use modes are available. The default setting for five user modes are in below table. User mode0 Fine weather (shade) 5,800 K...
-
Page 42: Gamma Tab
No.17S021-01 Gamma Tab Gamma offset Add the offset for the gamma curve. When set the greater offset, the output for the preset point become smaller. Gamma through Set the through or magnification for the input data. Gamma preset (manual gamma) 27 points adjustment is available for the manual gamma. -
Page 43: Chroma Tab
No.17S021-01 Chroma Tab Hue adjustment Hue is the center adjustment position when set 0[h]. When set 1[h] to 5A[h], the hue changes with the clockwise rotation. When set FF[h] to A6[h], the hue changes with the counter clockwise rotation. The unit is 1deg. / step. Saturation adjustment Saturation is the center adjustment position when set 80[h]. -
Page 44: Other Tab
No.17S021-01 Other Tab UART Changed baud rate is enabled when restart the camera after save the baud rate setting to the flash memory on the camera by selecting “DSP->FLASH” button. Mirror/Flip Set the image output with the horizontal flip, vertical flip or horizontal and vertical flip. Sharpness / Contrast / Brightness / Negative-positive Adjust each setting for the image. -
Page 45: Privacy Mask Tab
No.17S021-01 Privacy Mask Tab Set the privacy mask setting. Up to 16 frames are available. Mosaicing horizontal width / vertical width Set the mosaicing width when the mosicing mask is enabled. The unit for the horizontal width is an even number of the pixels and the 1 line for the vertical width. Mask x Select On/Off for the mask. - Page 46 No.17S021-01 Mask * Gate When set on this, the masking area is excluding from the AE detection. Note) The smaller mask number has the priority for mask display. STC-S133UVC 46/63 Product Specifications and User’s Guide...
-
Page 47: Day&Night Tab
No.17S021-01 Day&Night Tab Set the Day & Night function. Day&Night The camera switches automatically based on AE status when set “AUTO” Manual Mode Day or Night mode is selectable when selecting “MANUAL” at Day&Night. Counter unit Select the unit of the judgement time (frame or second) Day/Night Threshold dark side / threshold light side Set the threshold for the auto Day/Night. -
Page 48: Aperture Tab
No.17S021-01 Aperture Tab Set the enhancement settings for the edge of the image. Set the horizontal, vertical and oblique aperture gain for 1/2fs (high frequency) and 1/4fs (low frequency). When setting 40[h], enhancement gain is x1. Analog Tab STC-S133UVC 48/63 Product Specifications and User’s Guide... -
Page 49: Blemish Pixel Tab
No.17S021-01 Blemish Pixel Tab When selecting “Auto Detect” button, the white pixel compensates automatically. It is necessary to shade the camera before using this function. Note If the auto detects fails due to the too bright (not shading the camera), saved compensated values are cleared. Info. -
Page 50: One Shot
No.17S021-01 One Shot One shot mode is selectable by “OneShot” under “Mode” in the menu. Save or load the settings by the function group. Read DSP Read DSP data form the camera and make setting file. Write FALSH Write selected setting file into camera’s DSP, and load to Flash and verify. Verify Verify DSP register value to setting file. -
Page 51: Camera Setting By The Osd
No.17S021-01 Camera setting by the OSD This camera can change the camera settings by the On Screen Display with camera control software (S133Control). OSD operation by camera control software A. Please check the 4-6. OSD tab descriptions for details of the operation. Note. -
Page 52: Osd Menu
No.17S021-01 OSD menu SETUP MENU Page 1 SHUTTER/AGC Shutter/ Gain Setting (Default: AUTO) WHITE BAL White Balance Setting (Default: ATW) BACKLIGHT Back Light Compensation (Default: OFF) PICT ADJUST Image Processing Setting DEFOG Defog Function (Default: OFF) WDR/ATR WDR/ATR Setting (Default: WDR and ATR ON) Page 2 DAT/NIGHT Day Night Setting (Default: AUTO fixed) -
Page 53: Shutter/Agc
No.17S021-01 SHUTTER/AGC 1) AUTO SETUP Setup the AE (Auto Exposure) settings When selecting “ENTER” after select “AUTO” at “SHUTTER/AGC”, AE settings are selectable. HIGH LUMINANCE MODE SHUT Fixed shutter AE LEVEL Set the target brightness level for AE (Default:56) LOW LUMINANCE Select AGC mode (ON/OFF) (Default: ON) AE LEVEL Set the target brightness level for AE (AGC) (Default: X1.00) -
Page 54: White Bal
No.17S021-01 WHITE BAL ATW Auto White balance mode When selecting “ENTER” after select “AUTO” at “WHITE BAL”, ATW settings are selectable. SPEED Set pull in speed for ATW (Default: 128) DELAY CNT Set delay time for ATW (Default: 8) ATW FRAME Select pull in frame for INDOOR/OUTDOOR ENVIRONMENT Select pull in frame for ATW (Default: INDOOR) - Page 55 No.17S021-01 MANUAL Manual White balance mode When selecting “ENTER” after select “MANUAL” at “WHITE BAL”, the color temperature for the manual white balance is adjustable. PUSH LOCK Push to set White Balance BACK LIGHT Back light compensation is OFF Back light compensation is ON HLC (High Luminance Compensation) is enabled STC-S133UVC 55/63...
-
Page 56: Pict Adjust
No.17S021-01 PICT ADJUST When selecting “ENTER” after select “PICT ADJUST”, image processing settings are selectable. FLIP Normal image H-FLIP Horizontal flip image V-FLIP Vertical flip image HV-FLIP Horizontal and vertical flip image BRIGHTNESS Set the brightness of the image (Default: 128) CONTRAST Set the contrast of the image (Default: 128) SHARPNESS... -
Page 57: Defog
No.17S021-01 DEFOG Default: OFF When selecting “ENTER” after select “ON” at “DEFOG”, defog setting is selectable. LEVEL Set the defog level and sensitivity Middle HIGH High STC-S133UVC 57/63 Product Specifications and User’s Guide... -
Page 58: Wdr/Atr
No.17S021-01 WDR/ATR Set WDR and ATR function OFF When selecting “ENTER” after select “ATR” at “WDR/ATR”, ATR settings are selectable. BRIGHTNESS Set the brightness highlight level Middle(Default:) HIGH High CONTRAST Set the contrast highlight level Middle HIGH High When selecting “ENTER” after select “WDR” at “WDR/ATR”, WDR settings are selectable. BRIGHTNESS Set the brightness compression level Middle... -
Page 59: Day/Night
No.17S021-01 Day/Night AUTO (Default DELAY CNT Transition time between Day / Night (Default: 5) DAY->NIGHT Threshold for switch from Day to Night (Default: 90) NIGHT->DAY Threshold for switch from Night to Day (Default: 110) Set the noise reduction settings When selecting “ENTER” after select “ON” at “DNR”, noise reduction settings are selectable. MODE Noise reduction is OFF Y/C Filter is ON (Default:) -
Page 60: Privacy
No.17S021-01 PRIVACY Set the privacy mask settings When selecting “ENTER” after select “ON” at “PRIVACY”, privacy mask settings are selectable. AREA SEL Select the privacy mask frame TOP, BOTTOM, LEFT, RIGHT Set the privacy mask position (Default: 0) COLOR Se the color for the privacy mask (Default: 1) TANSP (0.00 / 050 / 0.75 / 1.00) Set the transparent level for the privacy mask Default: 0.00) MOSAIC OFF Mosaic is OFF(Default:) -
Page 61: Language
No.17S021-01 LANGUAGE Select the language for the OSD menu from English, Douche, French, Russian, Portuguese or Spanish. CAMERA RESET Initialize all OSD settings SAVE ALL When selecting “SAVE ALL” after select “EXIT”, save all OSD settings to the flash memory on the camera. It is necessary to enable “OSD parameter Load”... -
Page 62: Revisions History
No.17S021-01 Revisions History Date Changes Note 2018/05/21 New document 2018/09/26 Revised Added cased models Note Product specifications would be modified without notification. STC-S133UVC 62/63 Product Specifications and User’s Guide... - Page 63 No.17S021-01 9F, Ebina Prime Tower 9-50, Chuo 2 chome Ebina-city, Kanagawa 243-0432 Japan TEL 81-46-236-6660 FAX 81-46-236-6661 URL http://www.sentech.co.jp/ STC-S133UVC 63/63 Product Specifications and User’s Guide...
