TV Format
0.65M Small Camera
STC-S133 series
[NTSC Output]
STC-S133N
STC-S133N－NF
STC-S133N－L
STC-S133N－CS
STC-S133N－LS
[PAL Output]
STC-S133P
STC-S133P－NF
STC-S133P－L
STC-S133P－CS
STC-S133P－LS
Product Specifications
STC-S133 Series
Specifications
For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com
(No lens mount type, Dual Pass Filter)
(No IR cut filter type, Non-Dual Pass Filter)
(M12 fixed lens mount type, Dual Pass Filter)
(CS mount type)
(M12 fixed lens mount type, Holder Short
(No lens mount type, Dual Pass Filter)
(No IR cut filter type, Non-Dual Pass Filter)
(M12 fixed lens mount type, Dual Pass Filter)
(CS mount type, Dual Pass Filter)
(M12 fixed lens mount type, Holder Short
Dual Pass Filter)
Dual Pass Filter)
No.16S061-09
1/55
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Omron STC-S133 Series
Summary of Contents for Omron STC-S133 Series
- Page 1 No.16S061-09 (888)687-6877 TV Format 0.65M Small Camera STC-S133 series [NTSC Output] STC-S133N (No lens mount type, Dual Pass Filter) STC-S133N－NF (No IR cut filter type, Non-Dual Pass Filter) STC-S133N－L (M12 fixed lens mount type, Dual Pass Filter) STC-S133N－CS (CS mount type) STC-S133N－LS...
-
Page 2: Table Of Contents
STC-S133N-CS / STC-S133P-CS .................... 17 RC-S133........................... 18 Communication control software users guide ..........19 Requirement software and JIG tool ..................19 Connecting configuration ...................... 19 Communication settings......................19 STC-S133 Series 2/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... - Page 3 DEFOG ....................................49 WDR/ATR .................................... 50 Day/Night ..................................... 51 DNR ..................................... 51 PRIVACY ..................................... 52 LANGUAGE..................................53 CAMERA RESET ................................53 SAVE ALL .................................... 53 STC-S133 Series 3/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
- Page 4 No.16S061-09 Revisions ......................54 STC-S133 Series 4/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
- Page 5 This will cause of fire or malfunction. camera. This will cause of fire, electrification or malfunction. STC-S133 Series 5/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
- Page 6 This will cause of fire, electrification or inspecting the camera. malfunction. This will cause of electrification. [Disposal] Caution It is necessary to dispose as industrial waste. STC-S133 Series 6/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
-
Page 7: Product Precautions
Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility. “Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the camera malfunction is not included. STC-S133 Series 7/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 8: Introduction
L: M12 fixed lens mount type LS: M12 fixed lens mount type, Holder Short CS CS mount type Back Panel N NTSC Output P PAL Output STC-S133 Series 8/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 9: Accessories
No.16S061-09 Accessories Following accessories are available for STC-S133 series camera, please check and purchase necessary accessories. +12V DC power supply: UN310-1210 Communication tool (PC can communicate through USB port): JIG-USB2 Camera to JIG-USB2 cable: KSAF003 Control software: KSACtrl Remote Controller: RC-S133... -
Page 10: Specifications
Shock Acceleration 38 G, half amplitude 5.7 ms, XYZ 3 directions 3 times each RoHS RoHS compliance (*1) Under STC-S133N-CS with FLCL1614-2M (F5.6) lens STC-S133 Series 10/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 11: Spectral Sensitivity Characteristics
No.16S061-09 Spectral Sensitivity Characteristics Dual Pass Filter Spectral Sensitivity Characteristics Transmittance (%) 1050 1150 STC-S133 Series 11/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 12: Connector Specifications
②Sets WB_LOCK Switch ON and holds white This setting can’t be saved. When power off the camera, and turn on the camera, this WB setting didapper To save the WB setting, OSD menu or communication requires. STC-S133 Series 12/55 Specifications... -
Page 13: Osd Menu Control
OSD Menu Down CN1 connecting circuit (user side example) CN1 Pin assignment 1) Up 2) ENTER 3) LEFT 4) RIGHT 5) DOWN 6) GND STC-S133 Series 13/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... - Page 14 No.16S061-09 OSD operation can manipulate through Remote controller (RC-S133) connected with CN1. ENTER LEFT RIGHT DOWN STC-S133 Series 14/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
-
Page 15: Dimensions
Power / Video / Comunication unit mm STC-S133N-NF / STC-S133P-NF (5.5) φ 22.4 2-φ 2.3 NTH 2-R1.7 Power / Video / Comunication unit mm STC-S133 Series 15/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 16: Stc-S133N-L / Stc-S133P-L
4-M3 Depth3.0 (2-M3 on other side) (13.5) M12 x P0.5 φ 25 4-M2 Depth3.0 Power / Video / Dual Pass Filter Communication Unit mm STC-S133 Series 16/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 17: Stc-S133N-Cs / Stc-S133P-Cs
STC-S133N-CS / STC-S133P-CS 4-M2 Depth 2.5 (19.1) (2-M2 on other side) 14.8 13.6 CS Mount Power / Video / Dual Pass Filter Comunication Unit mm STC-S133 Series 17/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 18: Rc-S133
No.16S061-09 RC-S133 Unit mm STC-S133 Series 18/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 19: Communication Control Software Users Guide
Please refer to another chapter. Communication settings UART (RS232C compliant), Binary communication Baud rate 115,200bps Data bit 8bits Parity None Stop bit 1bit Flow control None STC-S133 Series 19/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 20: Basic Operating Procedure
“Comm (C)” in the menu. 3) Select “Read All” button to read all of the register information from the camera. 4) All of the camera settings are configurable through the camera control software. STC-S133 Series 20/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 21: The Descriptions For The Buttons
The camera holds the camera settings as the Default: camera settings after read out the camera settings. Please use this button to synchronize the camera settings and the camera settings information in the camera communication software. STC-S133 Series 21/55 Specifications... -
Page 22: The Descriptions Of The Functions
Adjustment The individual camera settings are adjustable. One Shot The camera settings save to the file and load from the file by the function. STC-S133 Series 22/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 23: Shutter/Gain Tab
AE convergence starts when AE error is greater than this setting and keeps the same condition more than the frame counter of the dead band. EV correction Set the amount of the exposure. STC-S133 Series 23/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... - Page 24 The AE becomes the gain prioritized AE when set other than “0” while AE mode. It is necessary to select the value that between the minimum and maximum gain. The gain is fixed as the selected gain and the brightness level is adjusting by the shutter time. STC-S133 Series 24/55 Specifications...
- Page 25 Shutter and gain settings for each User Preset are below: User Preset Preset 0 (Default) Preset 1 Preset 2 Preset 3 Shutter 16666 10000 15000 16666 Gain STC-S133 Series 25/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
-
Page 26: Lens Tab
Set the optical horizontal and vertical center position. Radius Set the compensation radius from the optical center position. Ellipticity Set the ellipticity ratio. Vegnetting compensation OFF Vegnetting compensation ON STC-S133 Series 26/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... - Page 27 When set the greater value, the distortion is reduced. When set the smaller value, the distortion is extended. There are four types (A, B, C and D) of the compensation points are available. Distortion compensation OFF Distortion compensation ON STC-S133 Series 27/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
-
Page 28: Osd Tab
Set the OSD horizontal and vertical start position (display position). OSD Time out setting Set the time out setting for the OSD with second unit. This function is invalid when set 0. STC-S133 Series 28/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... - Page 29 3 [h] Gray Character F [h] 8 [h] 8 [h] 3 [h] White Character edge 0 [h] 8 [h] 8 [h] 3 [h] Black STC-S133 Series 29/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
-
Page 30: Wdr Tab
Defog function is improved the visibility with When selecting “Auto” for Defog, the response sensitivity is adjusting with the number of the frame for On and OFF. STC-S133 Series 30/55 Specifications... - Page 31 Bright side Dark side L-luminance ON-OFF H-luminance ON-OFF It is necessary to set L-luminance ON-OFF < L-luminance OFF-ON < H-luminance OFF-ON < H-luminance On-OFF. STC-S133 Series 31/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
-
Page 32: Ae Weight Tab
The average brightness of the full image uses for the average photometry mode. The weighted brightness of 63 areas (7x9 areas) uses for the center photometry mode. The weighted brightness of surround frame of the target frame uses for the spot photometry mode. STC-S133 Series 32/55 Specifications... -
Page 33: Normal Ae Tab
Full ME Tab Set the shutter and gain for the full ME AE mode. Set the shutter speed and gain for the long exposure, short exposure 1 and short exposure 2. STC-S133 Series 33/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 34: Ae Mask Tab
The mask frame can set up to 16 frames. In case of the image has vignetting, the optimized brightness of the image can keep it by excluding the vignetting area for AE detection. STC-S133 Series 34/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 35: Whitebalance Tab
Pull in the blue sky then suppress red at Outdoor (blue sky) mode. Other settings Set the sensitivity for ATW mode and all pull in mode. STC-S133 Series 35/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... - Page 36 Select all pull in mode with the white target. Read CONT_R and CONT_B after select “Read” button. Set value of CONT_R to modex R/G and value of CONT_B to modex B/G. (x 0 to 4 mode number) STC-S133 Series 36/55 Specifications...
-
Page 37: Gamma Tab
When decreases from 80[h] to 0[h], the image becomes low saturation image. When increases from 80[h] to FF[h], the image becomes high saturation image. 0[h] x0 saturation, 80[h] x1 saturation, FF[h] x2 saturation STC-S133 Series 37/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 38: Other Tab
The noise reduces by the flatten process for the microscopic chroma change of the vertical direction. Vertical IIR C-NR Observes the vertical direction pixels then control the color gap of the vertical direction. STC-S133 Series 38/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 39: Privacy Mask Tab
Mask * Gate When set on this, the masking area is excluding from the AE detection. Note) The smaller mask number has the priority for mask display. STC-S133 Series 39/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 40: Day&Night Tab
Please check the “AE weight” for the photometry mode operation. Read Read camera’s brightness and show on the chart, show the status of Day/Night mode STC-S133 Series 40/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 41: Aperture Tab
Mute Set the mute (Disabled video output) of the image. Y LPF/C LPF Set the LPF for the Y signal and C (chroma) signal. STC-S133 Series 41/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 42: Blemish Pixel Tab
Display the version information of the flash memory data on the camera. Field Table Display the list of the settings. Initial is first time read out data after the control software started. STC-S133 Series 42/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 43: One Shot
Read DSP data form the camera and make setting file. Write FALSH Write selected setting file into camera’s DSP, and load to Flash and verify. Verify Verify DSP register value to setting file. STC-S133 Series 43/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 44: Camera Setting By The Osd
OSD operation by the communication software A. It is necessary to disable the OSD switch function by the communication software before use it Please check the 4-6. OSD tab descriptions for details of the operation. STC-S133 Series 44/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 45: Osd Menu
WDR/ATR Setting (Default: WDR and ATR ON) Page 2 DAT/NIGHT Day Night Setting (Default: AUTO) PRIVACY Privacy Mask (Default: OFF) LANGUAGE OSD Language (Default: ENGLISH) STC-S133 Series 45/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 46: Shutter/Agc
Set the target brightness level for AE (AGC) (Default: X1.00) 2) MANUAL SETUP Set up the ME (Manual Exposure) settings SHUTTER Select shutter speed (Default: 1/60) Set the gain (Default: MIN Gain 0) STC-S133 Series 46/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 47: White Bal
Set the B gain and R gain for User White balance. MANUAL Manual White balance mode Select the color temperature for the manual white balance STC-S133 Series 47/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 48: Back Light
PUSH LOCK Push to set White Balance BACK LIGHT Back light compensation is OFF Back light compensation is ON HLC (High Luminance Compensation) is enabled STC-S133 Series 48/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 49: Pict Adjust
Set the hue of the image (Default: 90) COLOR GAIN Set the color saturation of the image (Default: 128) DEFOG LEVEL Set the defog level and sensitivity Middle HIGH High STC-S133 Series 49/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 50: Wdr/Atr
Set the contrast highlight level Middle HIGH High BRIGHTNESS Set the brightness compression level Middle HIGH High CONTRAST Set the contrast highlight level Middle HIGH High STC-S133 Series 50/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 51: Day/Night
Y Filter is OFF, C Filter is ON Y LEVEL Set the Y filter level (Default: 4) C LEVEL Set the C filter level (Default:4) STC-S133 Series 51/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 52: Privacy
Se the color for the privacy mask (Default: 1) TANSP (0.00, 050, 0.75, 1.00) Set the transparent level for the privacy mask Default: 0.00) MOSAIC OFF Mosaic is OFF(Default:) Mosaic is ON STC-S133 Series 52/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... -
Page 53: Language
SAVE ALL Save all OSD settings to the flash memory on the camera It is necessary to enable “OSD parameter Load” function to use saved settings STC-S133 Series 53/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com... - Page 54 2017/08/28 Revised Added -LS model 2018/05/01 Revised Change the dimension drawing for -L and -LS models Note: Product specifications would be modified without notification. STC-S133 Series 54/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
- Page 55 No.16S061-09 STC-S133 Series 55/55 Specifications For more information please contact Aegis Electronic Group, Inc. *(888)687-6877 *aegis-g2@aegiselect.com *http://www.aegiselect.com...
