COnTROL PAnEL AnD FEATURES

1
WASHER
1
WASH CYCLE KNOB
Use the Wash Cycle knob to select available cycles on your
washer. Turn the knob to select a cycle for your laundry load.
See "Cycle Guide" for detailed descriptions of cycles.
WASH TEMP
2
You may select a Wash Temperature based on the type of
fabric and soils being washed. Use the warmest wash water
safe for the fabric. Follow garment label instructions.
LOAD SIZE
3
Use this option to adjust the amount of water used with
your load size. Use enough water to allow the load to
move freely.
NOTE: The highest water level will be lower than that
of pre-2011 washers.
FABRIC SOFTENER
4
This option must be selected if using fabric softener
during a cycle. It ensures that fabric softener is added
at the correct time in the rinse for even distribution.
6
2
3
Not all features and options are available on all models.
Appearance may vary.
4
5
DRYER
END OF CYCLE SIGNAL/PUSH TO START
5
The End of Cycle Signal produces an audible sound when
the drying cycle is finished. Promptly removing clothes at
the end of the cycle reduces wrinkling.
Turn the END OF CYCLE SIGNAL knob to select the
desired setting (On or Off). Press the PUSH TO START
knob to start the dryer.
DRYER CYCLE KNOB
6
Use your Dryer Cycle knob to select available cycles on
your dryer. Turn the knob to select a cycle for your laundry
load. See "Cycle Guide" for detailed descriptions of cycles.
TIMED DRYING
Will run the dryer for the specified time on the control.
Drying time and temperature will depend on your dryer
model.
AUTOMATIC DRY
Senses moisture in the load or air temperature and shuts
off when the load reaches the selected dryness level.
Gives the best drying in the shortest time. Drying time will
vary based on fabric type, load size, and dryness setting.
6
