- Page 1 Installation Instructions / Warranty 04222XX0 04227XX0 04232XX0...
- Page 2 04222XX0 04227XX0 04232XX0...
-
Page 3: Installation Considerations
Installation Considerations • For best results, Hansgrohe recommends that • To prevent scald injury, the maximum output this unit be installed by a licensed, profes- temperature of the shower valve must be no higher than 120°F. In Massachusetts, the sional plumber. maximum output temperature of the shower •... - Page 4 English Installation Cut the plaster shield so that it extends ¹⁄₁₆" out- side the surface of the finished wall. Seal the wall around the plaster shield with water- proof sealant (1). Failure to seal the wall can lead to possible water damage.
- Page 5 Français Español Installation Instalación Coupez le protecteur de façon à ce qu’une partie Corte el protector de yeso de modo que sobre- de ¹⁄₁₆ po soit à l’extérieur de la surface du mur salga ¹⁄₁₆" de la superficie de la pared terminada. fini.
- Page 6 English Cut the extension spindle so that it extends ¾" outside the surface of the finished wall. Install the escutcheon. Install the nut and o-ring. Install the snap connector. Tighten the screw. Install the handle. 2.5 mm Tighten the screw using a 2.5 mm Allen wrench. Install the screw cover.
- Page 7 Français Español Coupez la tige d’extension de façon à ce qu’une Corte el husillo de extensión de modo que sobre- partie de ¾ po soit à l’extérieur de la surface du salga ¾" de la superficie de la pared terminada. mur fini.
- Page 8 English Press the icons into the escutcheon.
- Page 9 Français Español Installez les icônes sur l’écusson. Instale los iconos en el escudo.
- Page 10 Replacement Parts / Pièces détachées / Repuestos 95238XX0 96392000 94184000 95181000 98677XX0 95238XX0 96392000 94184000 95181000 95181000 98677XX0 94184000...
- Page 11 Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for Faucets and Showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 12 Recommandations pour le nettoyage des produits Hansgrohe Les robinetteries modernes de lavabo, de cuisine et de douche utilisent des matériaux très différents pour répondre aux besoins du marché en termes de conception et de fonctionnalité. Certaines règles de base doivent être respectées lors du nettoyage de ces produits afin d’éviter de les endommager ou d’avoir à...
- Page 13 Recomendación de limpieza para los productos de Hansgrohe Hoy en día, las griferías de baño y de cocina así como duchas modernas se componen de materiales muy distintos para satisfacer las exigencias del mercado respecto al diseño y la funcionalidad. Para evitar daños reclamaciones hay que tener en cuenta ciertos aspectos tanto en el uso como en su limpieza posterior.
-
Page 14: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and installed in either the United States or Canada. - Page 15 Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from State to State. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
- Page 16 Hansgrohe, Inc. • 10 Bluegrass Lakes Parkway • Alpharetta, GA 000 Tel. 0-0-0 • Fax 0-0- www.hansgrohe-usa.com...
