Hans Grohe Allegro E 04067 0 Series Installation/User Instructions/Warranty
Hide thumbs
Also See for Allegro E 04067 0 Series:
- Installation/user instructions/warranty (16 pages) ,
- Installation instructions / warranty (16 pages) ,
- Installation instructions / warranty (16 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for Hans Grohe Allegro E 04067 0 Series
Summary of Contents for Hans Grohe Allegro E 04067 0 Series
- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Allegro E Allegro E 06461xx0 04067xx0 Allegro E Gourmet Allegro E Gourmet 06460xx0 04066xx0 04297xx0...
-
Page 2: Technical Information
English Français Technical Information Données techniques Water pressure Pression d’eau Recommended 15 - 75 PSI (0.1 - 0.5 MPa) recommandée 15 - 75 PSI (0.1 - 0.5 MPa) Maximum 145 PSI (1 MPa) maximum 145 PSI (1 MPa) Hot water temp. Température d'eau chaude Recommended 120°-140°... -
Page 3: Consideraciones Para La Instalación
Español Datos tecnicos Tools Required / Outiles Utiles / Herramientas Útiles Presión en servicio recomendada 15 - 75 PSI (0.1 - 0.5 MPa) max. 145 PSI (1 MPa) Temperatura del agua caliente recomendada 120°-140° F (48° - 60° C)* max. 158°F (70°... - Page 4 Allegro E Gourmet Allegro E Gourmet Allegro E Gourmet 06460xx0 04066xx0 04297xx0 11⅜" (289 mm) 10⅝" (270 mm) 9" (230 mm) Ø2⅜" (60 mm) Ø2⅜" (60 mm) Ø2⅜" (62 mm) Ø1⅜" (34 mm) Ø1⅜" (34 mm) Ø1⅜" (34 mm) ⅜ ⅜...
- Page 5 Optional: Install the baseplate / En Option : Installez l'embasse / Opcional: Instale la placa de base 04066xx0 English Français Español Position the baseplate and Placez l’embase et le joint sur la Ubique la placa de base y la gasket over the holes in the surface de montage.
-
Page 6: Installation / Installation / Instalación
Installation / Installation / Instalación English Français Español Place the faucet and sealing ring Placez l'anneau d'étanchéite Coloque el oro de sellado y on the mounting surface. et le robinet sur la surface de el grifo sobre la superficie de montage. - Page 7 English Français Español Connect the handspray hose to Raccordez le tuyau de la dou- Conecte la manguera de rocia- the connection hose: chette au tuyau d'arrivée de la dor de mano a la manguera de douchette: suministro: • Open the quick connect by pushing it upwards.
- Page 8 > 2 min English Français Español Remove the handspray. Retirez la douchette. Retire la ducha. Remove the filter. Retirez le filtre. Retire el filtro. Flush the hot and cold supplies Rincez les conduites Lave los suministros de agua for at least two minutes. d’alimentation de l’eau chaude caliente y fría.
- Page 9 English Français Español Install the filter in the handspray Instale el filtro en la manguera. Installez le filtre dans le tuyau hose. flexible. Lubrique ligeramente la junta Lightly lubricate the hose o-ring. tórica de la manguera. Lubrifiez le joint torique du tuyau.
- Page 10 Replacement Parts / Pièces détachées / Repuestos Allegro E 06461xx0 04067xx0 97735000 97350000 98598xx1 88655000 95008000 96059000 98597xx1 96468xx0 96461000 92730000 96316001 88624000 95049000 xx = Colors / Couleurs / Acabados 00 = chrome 80 = steel optik...
- Page 11 Allegro E Gourmet 06460xx0 04066xx0 04297xx0 97735000 88655000 98597xx1 95008000 96468xx0 96059000 97350000 96461000 98599xx1 92730000 88624000 04066xx0 only / seulement / solamente 95049000 14019xx1 96316001 xx = Colors / Couleurs / Acabados 00 = chrome 80 = steel optik...
- Page 12 User Instructions / Instructions de service / Manejo ouvert fermé abierto cerrar cold chaud froid caliente frío Allegro E Allegro E Gourmet...
- Page 13 Cleaning / Nettoyage / Limpieza...
- Page 14 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it.
- Page 15 Important • Les residus de produits pour le corps comme les savons liquides, shampooings, gels de douche, teintures pour cheveux, parfums, apres-rasage et vernis a ongles peuvent causer des deteriorations. Rincez le produit avec de l’eau propre après chaque utilisation. •...
-
Page 16: Limited Consumer Warranty
Limited Consumer Warranty This warranty is limited to products manufactured by Hansgrohe, conditions in the home such as excessive water pressure Inc. (“Hansgrohe”) that are purchased by a consumer in the United or corrosion. States or Canada after March 1, 1996, and installed in either the Labor and other expenses for disconnection, deinstallation, United States or in Canada.
