- Page 1 M150-LD40LV40-001 HIGH PERFORMANCE WDR FLAT DOME CAMERA O P ER AT I O N M A N UA L VANDAL DOME PLASTIC DOME Thank you for choosing our high quality camera. Before attempting to connect operate this unit, please read and follow these instructions.
- Page 2 CO NTEN T S 1. CAUTIONS 2. IMPORTANT SAFETY INSTRUCTION 3. EQUIPMENT AND ACCESSORIES 4. CAMERA COMPONENT DESCRIPTIONS • Plastic Dome / Vandal Dome Type 5. INSTALLATION • Plastic Dome / Vandal Dome Type 6. DIMENSIONS • Plastic Dome / Vandal Dome Type 7.
- Page 3 1 . C AU TIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation.
- Page 4 1 . C AU TIONS Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicate that it should not be disposed with other household wastes at the end of its working life.
-
Page 5: Important Safety Instruction
2 . IMPOR TANT SA FET Y INS TRUCTION 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 6: Equipment And Accessories
3 . EQUI PM ENT AND ACCES SORIES Plastic Dome Type Mount Guide (Plastic Dome Type) Vandal Dome Type Mount Guide (Vandal Dome Type) Manual Screws(3ea) / L-Wrench Service Video Output Test Cable / Fixed Tape... -
Page 7: C Ame R A Compon Ent Description S
4 . C AME R A COMPON ENT DESCRIPTION S • Plastic Dome Type PART NAME Top Case Dome Cover Dome Bracket Dome Ass'y Cable Main PCB OSD Controller Bottom Case... - Page 8 4 . C AME R A COMPON ENT DESCRIPTION S • Vandal Dome Type PART NAME Top Case Dome Cover Case Rubber Dome Bracket Dome Ass'y Main PCB Safety Wire OSD Controller Bottom Case...
-
Page 9: Installation
5 . IN STA L LATION (Plastic Dome) 1. Attach the FLAT DOME on the ceiling with using the screws provided, considering the camera angle required for the surveillance function. 2. Adjust the LENS ANGLE to the desired location by hand. TAPPING SCREW (4 x 20L) - 3EA 3. - Page 10 5 . IN STA L LATION (Vandal Dome) 1. Attach the FLAT DOME on the ceiling with using the screws provided, considering the camera angle required for the surveillance function. 2. Adjust the LENS ANGLE to the desired ocation by hand. 3.
- Page 11 5 . IN STA L LATION • MONITOR CONNECTION - DC12V/AC24V DC12V/AC24V POWER SUPPLY DC12V/AC24V (TERMINAL BLOCK) MONITOR VIDEO IN BNC FEMALE CAMERA DC12V ADAPTER DC12V (DC JACK) - DC12V MONITOR VIDEO IN BNC FEMALE CAMERA When you install the camera, please glue up the end of cable to keep it stable in order to protect the camera from the humidity problems.
- Page 12 6 . D IME N S IONS • Plastic Dome Type • Vandal Dome Type Unit(mm)
-
Page 13: Specification
7 . SPE CI FICAT ION NTSC Image Sensor 1/3” 960H SONY Double Scan Super HAD CCD II Scanning System 2 : 1 Interlace H Resolution. 750TV Lines Scanning Frequency 15.734KHz(H), 59.94Hz(V) 15 . 625KHz( H) , 50H z ( V) Total Pixels No. - Page 14 8 . OS D MANUAL • Menu structure Main MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU 5th Sub MENU FLICKERLESS OFF / ON HIGH LUMINANCE BRIGHTNESS 0 ~ 255 AGC, SLOW, AGC > SLOW, SLOW > MODE AGC, OFF AUTO...
- Page 15 8 . OS D MANUAL Main MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU 5th Sub MENU LEVEL 0 ~ 15 CONTRAST1 0 ~ 7 WDR MODE OFF, ON CONTRAST2 0 ~ 4 RETURN CENTER, TOP, BOTTOM, ZONE LEFT, RIGHT WDR/BLC...
