Congratulations on the purchase of your new Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com Have the model number available, and retain a copy of your receipt...
Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775- 0703 for a replacement • Turn off the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure •...
Page 4
Diagram and Parts List A. Faucet Body B. Aerator C. Flange D. Metal Washer E. Lock Nut F. Spanner Key G. Hex Wrench...
Page 5
Diagram and Parts List-Lift Rod Drain h i j k f. Mounting Nut k. Retaining Nut a. Waste Stopper b. Drain Flange g. Tail Pipe l. Clip c. Rubber Washer h. Top Hat Washer m. Extender Rod d. Concave Washer i.
Page 8
Step 1: Remove lock nut Shut off the water supply. Remove the lock nut (E) from the faucet (A). Step 2: Installing the faucet Before installation, ensure that the flange (C) is placed on the bottom of the new faucet (A). Place faucet (A) through the hole in sink.
Page 9
Step 3: Connect waterlines to main valve Attach waterlines to angle stops and tighten until snug. Turn on angles stops and check for leaks (DO NOT TURN FAUCET ON) Step 4A: Installing the drain Remove waste stopper (a) and drain flange (b) from tailpipe (g).
Page 10
Step 4B: Installing the drain Insert drain flange (b) through drain hole with rubber washer (c) attached. From underneath, place concave (d) and metal washer (e) on drain flange. Secure with mounting nut (f). Thread tailpipe (g) onto drain (b) and hand tighten. Step 4C: Installing the drain Insert waste stopper (a) into drain flange.
Page 11
Step 4D: Installing the drain Insert lift rod (o) through spout and connect with extender rod (m). Tighten thumb screw (n). Step 4E: Installing the drain Attach drain off pole (i) to extender rod (m) with clip (I).
Page 12
Step 4F: Installing the drain Loosen thumb screw (n) on extender rod (m). Push down on lift rod (o) until stopper is in open position. Retighten thumb screw (n). Step 5: Flush faucet After installing faucet, remove aerator (B) with a coin. Turn water on for 30 seconds to remove any debris.
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following coorective steps: P R O B L E M C A U S E A C T I O N Leakage under the Bonnet nut (5) has Remove the cover button (1).
Page 15
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
Page 16
Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
Page 17
IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
