- Page 1 INSTALLATION GUIDE Arlo Single Lever Basin Faucet ™ KBF-1201 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2017 Kraus USA Inc. I REV. Dec 2, 2017...
- Page 2 Congratulations on the purchase of your new Kraus plumbing xture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
- Page 3 Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775- 0703 for a replacement • Turn o the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure •...
- Page 4 Diagram and Parts List A. Faucet Body E. Aerator Key I. Deckplate B. Waterlines F. Hex Wrench J. Drain C. Flange G. Washer D. Aerator H. Lock Nut...
- Page 5 Faucet Dimension 6 3/4” 6 5/8” [172mm] 6 1/4” [169mm] 5” [159mm] 5” [126mm] [126mm] 8” 8” [203mm] [203mm] 4” 4” [100mm] [100mm] 2 1/4” 2 1/2in 2 1/2in [57mm] [64mm] [64mm] 2-9/16-24UNEF-2B 2-9/16-24UNEF-2B Installer Tip: Shut o main water supply before installing new faucet...
- Page 6 Step 1: Remove washer and lock nut Shut o the water supply. Remove the old faucet. Clean the mounting surface. WITH FLANGE: Remove the washer (G) and lock nut (H) from the faucet (A) as shown in gure a. WITH DECK PLATE: Remove the washer (G), the ange (C )and lock nut (H) from the faucet (A) as shown in gure b.
- Page 7 Step 2.2: Install faucet (with ange) Before installation, ensure that the ange (C) is placed on the bottom of the faucet (A). Place the faucet (A) through the mounting holes in the sink until the faucet (A) sets on top of the sink.
- Page 8 Step 4: Install drain Remove the waste stopper (1) and drain ange (2) from the drain body (5). Screw the nut (4) all the way down, and push the concave washer (3) down. Apply silicone sealant (not included) under the drain ange(1) and place the drain ange (1)into the drain hole of the sink.
- Page 9 Step 4: Install drain Insert the waste stopper (1) into the drain Insert 1 Insert 2 hole in the sink. Remove the strap (6) and clip (5) from the ball rod (3). Remove the ball nut (4). Insert the ball rod (3) into the drain body (2) and through the hole of the stopper (1).
- Page 10 Step 4: Install drain Attach the ball rod (1) to the strap (3) using the clip (2). Loosen the thumb screw (3) on the strap (2). Push down on the lift rod (1) until the stopper is in the open position.
- Page 11 Diagram and Parts List 8 17/32”...
- Page 12 Diagram and Parts List Tools you will need: 1. Index 2. Set Screw 3. Handle Adjustable Wrench 4. Screw 5. Cap 7 5/8” 6. Bonnet Nut 7. Cartridge Ø35~Ø38 8. Aerator Ø1 3/8”~ Ø1 1/2” 9. Aerator Wrench Ø35~Ø38 10. Flange Ø1 3/8~Ø1 1/2”...
-
Page 13: Troubleshooting
Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leakage under the Bonnet nut (6) has Remove the index (1). - Page 14 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 15 Puerto Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
- Page 16 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
