- Page 1 INSTALLATION GUIDE Arlo Single Lever Basin Faucet ™ KBF-1201 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2019 Kraus USA Inc. I REV. FEB 26, 2020...
- Page 2 Congratulations on the purchase of your new Kraus plumbing xture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com...
-
Page 3: Prior To Installation
Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775- 0703 for a replacement • Turn off the hot and cold water lines at the angle stops and turn on the old faucet to release any built-up pressure •... - Page 4 Diagram and Parts List A. Faucet Body E. Aerator Key I. Deck plate & Base plate B. Waterlines F. Hex Wrench J. Drain C. Flange & Washer G. Metal Washer K. Spanner Key D. Aerator H. Nut...
- Page 5 Faucet Dimension 6 3/4" 6 5/8" [172mm] 6 1/4" [169mm] 5" 5" [159mm] [126mm] [126mm] 2 1/4" [56mm] 3/8" compression 3/8" compression Installer Tip:...
- Page 6 Step 1: Remove washer and lock nut old faucet. Clean the mounting surface. WITH FLANGE: Remove the metal washer (G) and lock nut (H) from the faucet (A) as WITH DECK PLATE: Remove the metal Step 2.1: Install faucet (with deck plate) Align the hole on the deck plate (I) with the mounting hole on the sink.
- Page 7 Step 2.2: I Before installation, ensure that the of the faucet (A). Place the faucet (A) through the mounting holes in the sink until the faucet (A) sets on top of the sink. Secure the faucet (A) to the sink using the washer (G) and lock nut (H) provided.
- Page 8 Step 4: Install drain Remove the waste stopper (1) and drain ange (2) from the drain body (5). Screw the nut (4) all the way down, and push the concave washer (3) down. Apply silicone sealant (not included) under the drain ange(1) and place the drain ange (1)into the drain hole of the sink.
- Page 9 Step 4: Install drain Insert the waste stopper (1) into the drain Insert 1 Insert 2 hole in the sink. Remove the strap (6) and clip (5) from the ball rod (3). Remove the ball nut (4). Insert the ball rod (3) into the drain body (2) and through the hole of the stopper (1).
- Page 10 Step 4: Install drain Attach the ball rod (1) to the strap (3) using the clip (2). Loosen the thumb screw (3) on the strap (2). Push down on the lift rod (1) until the stopper is in the open position.
-
Page 11: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # 1. Cover Button GR, BL* KP27002 2. Set Screw KP27001 CH, SFS, ORB, MB, 3. Handle KP27046 BG, SFSB* CH, SFS, ORB, MB, 4. Cap KP27048 BG, SFSB* 5. Bonnet Nut KP27049 6. -
Page 12: Troubleshooting
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Remove the cover button (1). Leakage under the Bonnet nut (5) has Loosen set screw (2) with hex... - Page 13 Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus. This warranty extends to the original owner or end-user, and is not transferable to a subsequent owner.
- Page 14 Puerto Rico shipping charges may apply). International shipping fees are not included. Commercial Warranty Kraus extends the above warranty for a period of one (1) year to purchasers of products for industrial, commercial, and business use. All incidental or consequential damages are specifically excluded. No additional warranties, express or implied, are given, including but not limited to any implied warranty of merchantability or fitness for a particular purpose.
- Page 15 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
