- Page 1 INSTALLATION GUIDE Esta™ Single Handle Lavatory Faucet KBF-1211 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2021 Kraus USA Plumbing LLC I REV. NOV 17, 2021...
- Page 2 Congratulations on the purchase of your new Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com Have the model number available, and retain a copy of your receipt...
-
Page 3: Prior To Installation
Prior to Installation: • Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775- 0703 for a replacement • Read all instructions and safety warnings and ensure you have all tools, parts, and equipment necessary for a safe installation. - Page 4 Diagram and Parts List A. Faucet Body B. Aerator C. Aerator Key D. Metal Washer E. Lock Nut F. Spanner Key G. Hex Wrench...
- Page 5 Diagram and Parts List-Lift Rod Drain h i j k f. Mounting Nut k. Retaining Nut a. Waste Stopper b. Drain Flange g. Tail Pipe l. Clip c. Rubber Washer h. Top Hat Washer m. Extender Rod d. Concave Washer i.
- Page 6 Faucet Dimension 6 1/4" [159.2mm] 2 1/8" 4 3/4" [54.6mm] [120.3mm] M18.5X1.0-6g 1 7/8" [47.8mm] 3/8” compression Installer Tip:...
- Page 7 Drain Dimension 2 1/8” Ø [Ø54.0mm] 1 1/4-18UNEF-2A 5 5/8” [141.6mm] 1 1/4” Ø [Ø32.0mm] Installer Tip:...
- Page 8 Step 1: Remove lock nut Shut off the water supply. Remove the lock nut (E) from the faucet (A). Step 2: Installing the faucet Place faucet (A) through the hole in sink. Secure the faucet (A) to the sink using the metal washer (D) and lock nut (E) provided.
- Page 9 Step 3: Connect waterlines to main valve Attach waterlines to angle stops and tighten until snug. Turn on angles stops and check for leaks (DO NOT TURN FAUCET ON) NOTE are installed before connecting to the main valve. Step 4A: Installing the drain Remove waste stopper (a) and drain flange (b) from tailpipe (g).
- Page 10 Step 4B: Installing the drain Insert drain flange (b) through drain hole with rubber washer (c) attached. From underneath, place concave (d) and metal washer (e) on drain flange. Secure with mounting nut (f). Thread tailpipe (g) onto drain (b) and hand tighten. Step 4C: Installing the drain Insert waste stopper (a) into drain flange.
- Page 11 Step 4D: Installing the drain Insert lift rod (o) through spout and connect with extender rod (m). Tighten thumb screw (n). Step 4E: Installing the drain Attach drain off pole (i) to extender rod (m) with clip (I).
- Page 12 Step 4F: Installing the drain Loosen thumb screw (n) on extender rod (m). Push down on lift rod (o) until stopper is in open position. Retighten thumb screw (n). Step 5: Flush faucet After installing faucet, remove aerator (B) with included aerator key (C). Turn water on for 30 seconds to remove any debris.
-
Page 13: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # 1. Cover Button GR, BL* KP27002 2. Set Screw KP27001 SFS, MB, GM, 3. Handle KP27150 BG, SFSB* SFS, MB, GM, 4. Cap KP27151 BG, SFSB* 5. Bonnet Nut KP27152 6. -
Page 14: Troubleshooting
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following coorective steps: P R O B L E M C A U S E A C T I O N Leakage under the Bonnet nut (5) has Remove the cover button (1). - Page 15 Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
- Page 16 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at: Kraus USA Plumbing, LLC 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
- Page 17 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
