ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
KUS128N-CS01
2
KUS128N-CS02
3
KUS128N-CS03
4
KUS130E-CS04
5
KUS128N-CS05
6
17C33A0706001Y4
7
17C02A0755131Y4
8
17C01A0714003Y4
9
17FA05040301-Y4
Attention:
Make sure that all bolts needed for each step matches
the corresponding figure to ensure proper assembly.
Step 1:
Place the right leg (#3) onto a non-abrasive surface,
such as a carpet, with its bracket facing upwards. At the
front of the lounge, insert the rear seat (#1) into the
right leg (#3) and the left leg (#2) by using bolt (#6 and
#7) and washers (#9). Keep the bolts loose.
See Figure 1.
Note:
The labels marked "L" and "R" on the legs (#2 and #3)
should coincide with Figure 1 to ensure proper
assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
KUS128N-
PART
Q'TY
REAR SEAT
LEFT LEG
RIGHT LEG
FRONT SEAT
BACK ASSEMBLY
BOLT M6*16
BOLT M6*14
BOLT M6*40
10
WASHER d6.5*D13*1.0
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
PART
MATERIAL CODE
NO.
1
10
18000C23001
1
11
18000337004
12
1
18000337006
13
1
18000337002
14
1
17KAA0201----Y4
6
15
17KAA0201----Y4
2
16
17KAB1101----Y4
17
2
61K128NX00001BA
18
61K128NY00001BA
FIGURE 1
1
11
6
9
PART
PLASTIC NUT M6*P1.0
BOLT CAP
BOLT CAP M6
BOLT CAP M6
HEX.KEY WRENCH 4MM
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
BACK CUSHION
SEAT CUSHION
L
2
11
3
R
#6 BOLT M6*16
14
7
12
#7 BOLT M6*14
COURTYARD CREATIONS INC.
Q'TY
2
6
2
2
1
1
1
1
1
11
6
6
9
9
16
Advertisement
Table of Contents
Related Manuals for Courtyard Creations KUS128N-WM
Summary of Contents for Courtyard Creations KUS128N-WM
- Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DON’T RETURN TO STORE! STOP COURTYARD CREATIONS INC. PAGE 1 OF 2...
- Page 2 FIGURE 2 FIGURE 3 #8 BOLT M6*40 Step 2: Step 3: Insert the rear seat (#1) into the front seat (#4). Make Fasten the back assembly (#5) to the rear seat (#1) by sure that the spring clips on the rear seat (#1) come using bolts (#8), washers (#9), and plastic nuts (#10).
