Courtyard Creations KUS128X-WM Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
KUS128X-CS01
2
KUS128X-CS02
3
KUS128X-CS03
4
KFS128W-CS02
5
17C02A0712003Y4
6
17C01A0714003Y4
7
17XA3309
Attention:
Make sure that all bolts needed for each step matches
the corresponding figure to ensure proper assembly.

Step 1:

Insert the rear seat (#1) into the legs (#2). Fasten the
legs (#2) to the rear seat (#1) by using bolts (#5) and
steel washers (#7). See Figure 1.
Note:
The labeled arrow marks on the legs (#2) should
coincide with Figure 1 to ensure proper assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
KUS128X-
PART Q'TY
REAR SEAT
LEG
FRONT SEAT
BACK ASSEMBLY
BOLT M6*35
BOLT M6*40
STEEL WASHER
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
8
17FA05040301-Y4
9
1
18000C23001
2 10
18000337006
1 11
18000337002
1 12
17KAA0201----Y4
4 13
17KAB1101----Y4
2 14
61K128XX00001BA
4 15
61K128XY00001BA
FIGURE 1
2
1
WASHER d6.5*D13*1.0
PLASTIC NUT M6*P1.0
BOLT CAP M6
BOLT CAP M6
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
BACK CUSHION
SEAT CUSHION
2
7
35
#5 BOLT M6*35
COURTYARD CREATIONS INC.
4
2
4
2
1
1
1
1
5 10
