Courtyard Creations KUS128T Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
PARTS LIST
PART
MATERIAL CODE
NO.
1
KUS128T-CS02-5
2
KUS128T-CS01-2
3
KUS128T-CS01-3
4
KUS128T-CS02-4
5
KUS128T-CS03-1
6
17C40A0705001YX
7
17C02A0755131YX
8
17C40A0716001YX
You will need the following tools:
- Phillips Screwdriver (Not Included)
- Hex. Key Wrench (See Part #12 and #13)
- Nut Wrench (See Part #14)
Attention:
Make sure that all bolts needed for each step matches
the corresponding figure to ensure proper assembly.
Step 1:
Place the right arm (#3) onto a non-abrasive surface,
such as a carpet, with its bracket facing upwards. At the
front of the lounge, insert the rear seat (#1) into the
right arm (#3) and the left arm (#2) by using bolts (#6
and #7). Keep the bolts loose. See Figure 1.
Note:
The labels marked "L" and "R" on arms (#2 and #3)
should coincide with Figure 1 to ensure proper
assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until the lounge is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
PART
REAR SEAT
LEFT ARM
RIGHT ARM
FRONT SEAT
BACK ASSEMBLY
BOLT M6*15
BOLT M6*14
BOLT M6*45
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DO NOT RETURN TO THE STORE!
STOP
KUS128T
PART
Q'TY MATERIAL CODE
NO.
1 9
17FA05040301-YX
1 10
17C17A0403001YX
1 11
18000C23001
1
12
17KAA0101----Y4
1
13
17KAA0201----Y4
6
14
17KAB1101----Y4
2 15
61K128TX00001BA
2 16
61K128TY00001BA
FIGURE 1
6
PAGE 1 OF 2
WASHER d6.5*D13*1.0
SCREW ST4.2*12
PLASTIC NUT M6*P1.0
HEX. KEY WRENCH 4MM
HEX. KEY WRENCH 6MM
NUT WRENCH 10 & 13MM
BACK CUSHION
SEAT CUSHION
2
L
1
3
R
7
COURTYARD CREATIONS INC.
PART Q'TY
2
2
2
1
1
1
1
1
6
6
15
#6 BOLT M6*15
14
#7 BOLT M6*14
