Koldfront WTC12001W Owner's Manual

Through the wall air conditioner with supplemental heater
Hide thumbs Also See for WTC12001W:
Table of Contents

Advertisement

Quick Links

Through The Wall Air Conditioner
With Supplemental Heater
WTC8001W / WTC12001W
Owner's Manual
For more information on other great EdgeStar products on the web, go to
http://www.edgestar.com
To use the EdgeStar self-diagnostic tool, go to
https://support.edgestar.com
V2.3-07132018

Advertisement

Table of Contents
loading

Related Manuals for Koldfront WTC12001W

Summary of Contents for Koldfront WTC12001W

  • Page 1 Through The Wall Air Conditioner With Supplemental Heater WTC8001W / WTC12001W Owner’s Manual For more information on other great EdgeStar products on the web, go to http://www.edgestar.com To use the EdgeStar self-diagnostic tool, go to https://support.edgestar.com V2.3-07132018...
  • Page 2 Important Safety Information Warning: The water produced by the window AC is not potable or suitable for drinking. Do not drink the water drained from the unit as it contains contaminates and could make you sick. Improper handling can cause serious damage to the appliance and/or to the user. Please read the following safety information Electrical Safety ...

  • Page 3: Operation Of Safety Plug

    Operation of Safety Plug Note: Electrical products should not be disposed of with household waste. Please contact your local recycling center for more information on how to recycle electronic waste. Your air conditioner is supplied with a Leakage-Current Detection and Interruption (LCDI) safety plug.

  • Page 4: Table Of Contents

    Alternate and Supplemental Installation Instructions ........................12   Install Rear Louver Panel / Grille Directly on Back of Air Conditioner....................12   Non-Koldfront Wall Sleeve Types ..............................12 CONTROL PANEL OPERATIONS ..............................13   To Turn the Unit on: ..................................13  ...

  • Page 5: Introduction

    Introduction Thank you for purchasing this Koldfront by EdgeStar air conditioner. We hope that this purchase will be the beginning of a lasting and rewarding relationship between you and EdgeStar. We will provide the customer support and exemplary products necessary to nurture that relationship.

  • Page 6: Parts Identification

    Parts Identification Air Conditioner Unit Wall Sleeve (purchased or provided separately)

  • Page 7: Preparations For Installation

    Tools You May Need: • Flat Screwdriver or Putty Knife • Phillips Screwdriver • Tape Measure • Level • Drill Parts Supplied: The parts below are intended to be used in conjunction with a Koldfront branded Wall Sleeve. Part Name...

  • Page 8: Installation Instructions

     Attach the Front Frame pieces. Before Getting Started Your Koldfront though the wall air conditioner is designed to be installed in conjunction with a wall sleeve. If you are installing your new Koldfront air conditioner into an existing wall sleeve, please check to confirm that the wall sleeve is in sound structural condition and that is sized appropriately to accommodate your Koldfront air conditioner.

  • Page 9: Install The Rear Louver Panel / Grille Into The New Wall Sleeve

    Koldfront’s line of through the wall air conditioners and can be purchased at www.edgestar.com. To properly install your new Koldfront Through The Wall Air Conditioner into a wall sleeve, it is required that you use the Rear Louver Panel / Grille that was shipped with your new air conditioning unit.

  • Page 10: Rear Louver Panel / Grille Installation Into Wall Sleeve Diagram

    Also, please note that when aligned as instructed above, the holes in the louver panel / grille will properly line up to the holes in the Koldfront wall sleeve. If you are unable to secure the Rear Panel Louver / Grille to the wall sleeve, it may be attached directly to the rear of the air conditioning unit.
  • Page 11 Important: The below instructions are to be used in conjunction with the Koldfront Wall Sleeve model WTCSLV. Instructions for other compatible wall sleeves can be found in the “Alternate...

  • Page 12: Prepare Ground Wire

    If using the Koldfront wall sleeve (model WTCSLV), the hole should be pre-drilled for you. Also, please note that additional fastener types may have been included and may be used to suit your particular installation setup.

  • Page 13: Install Air Conditioner Unit Into Wall Sleeve

    Install Air Conditioner Unit into Wall Sleeve With the wall sleeve fully prepared, you are now ready to insert the air conditioner unit into the wall sleeve. Two or more people may be required for this step. 1. Remove the cabinet screw on the left lower side of the air conditioner cabinet. Set aside and / or discard the plastic washer.

  • Page 14: Completing Installation

    Completing Installation With the air conditioner installed into the Wall Sleeve and the ground wire properly attached, it is time to complete installation by inserting the Main Insulating Seal (stuffer seal) and attaching the Trim Frame. 1. Locate the Main Insulating Seal (stuffer seal) included with the installation kit. This is the longest seal and measures 1”...

  • Page 15: Alternate And Supplemental Installation Instructions

    5. Install unit into sleeve. Non-Koldfront Wall Sleeve Types The below diagrams may be used as a reference when installing your Koldfront Through The Wall Air Conditioner into a non-Koldfront branded Wall Sleeve. Regardless of brand, please ensure your wall sleeve is securely installed into the wall opening and is properly sealed.

  • Page 16: Control Panel Operations

    Control Panel Operations On/Off Energy Saver Timer Mode Check Filter Fan Speed Sleep Temp/Timer Up Temp/Timer Down Using the Control Panel To Turn the Unit on: Press the On/Off button. Note-The Energy Saver feature will automatically turn on in “Cool”, “Dry”, and “Auto” mode. To Change the Temperature: Press or hold either Up or Down...

  • Page 17: To Select Operating Mode

    To Select Operating Mode: To choose the operating mode press Mode . Each time you press the button a mode is selected in a sequence that goes from Auto, Cool, Heat, Dry, to Fan. The indicator light beside the mode button will be illuminated and remain on once the mode is selected. Note: Heat function is intended to provide supplemental heating in addition to an existing heat source.

  • Page 18: To Use The Energy Saver Feature

    To Use the Energy Saver Feature: To start the Energy Saver feature, press the Energy Saver button. This feature is available on “Cool”, “Dry”, and “Auto”. The fan continues to run for 3 minutes after the compressor shuts off. The fan then cycles on for 2 minutes at 10 minute intervals until the room temperature is above the set temperature, at which point the compressor turns back on and cooling starts.

  • Page 19: Error Codes

    Error Codes AS - Room temperature sensor error  Unplug the unit and plug it back in.  If the error repeats call for service.  Note- In Fan only mode it will display “LO” or “HI”. - Evaporator temperature sensor error ...

  • Page 20: Remote Operations

    Remote Operations Warning:  This product contains a lithium button/coin cell battery which is a potential Chemical Burn Hazard. Keep away from children.  Always completely secure the battery compartment. If the battery compartment does not close securely, stop using the product, remove the batteries, and keep away from children. If a new or used lithium button/coin cell battery is swallowed or enters the body, it can cause severe internal burns and can lead to death in as little as 2 hours.

  • Page 21: Additional Notes On Remote Operations

    Additional Notes on Remote Operations  The remote control has an operating range of 16 ft from the appliance.  The remote signal receiver/sensor is located on the control panel of the air conditioner.  Reception of signal commands is confirmed by an audible beep. ...

  • Page 22: Maintenance

    Maintenance Clean the air conditioner and filters regularly to maximize performance and efficiency, and prolong the unit’s life. Be sure to always unplug the air conditioner from the power outlet before cleaning. Air Filter Cleaning The air filter should be checked at least once a month to see if cleaning is necessary. Trapped particles in the filter can build up, preventing proper air flow and potentially resulting in an accumulation of frost on the cooling coils.

  • Page 23: Normal Sounds

    Normal Sounds  High Pitched Chatter - High efficiency compressors may have a high pitched chatter during the cooling cycle.  Sound of Rushing Air - At the front of the unit, you may hear the sound of rushing air being moved by the fan.

  • Page 24: Troubleshooting Tips

    Troubleshooting Tips Follow the troubleshooting guide below to resolve common issues. Issue Possible Cause Solution My air conditioner is not The wall plug is disconnected. Make sure the unit is plugged functioning at all. The LCDI power cord is Press the Reset button on the tripped.
  • Page 25 Troubleshooting Tips Continued Issue Possible Cause Solution The air conditioner is The front of the unit is blocked Clear any blockage in front of cooling but the room is too by drapes, blinds, furniture, etc., the unit. warm. NO ice is forming on that restrict air distribution.

  • Page 26: Specifications

    Specifications Model WTC8001W WTC12001W Voltage 115V 208 / 230 Frequency 60Hz 60Hz Plug Type (NEMA) 5-15P 6-20P BTUs (cooling) 8,000 12,000 / 11,700 BTU’s (heating) 4,200 10,600 / 8,600 Current (cooling) 7.8A 5.5A / 5.9A Current (heating) 12.0A 15.0A / 13.5A...

  • Page 27: Edgestar Limited Warranty

    EdgeStar Limited Warranty Full Two-Year Parts and Labor This product is warrantied by EdgeStar and is subject to any conditions set forth as follows: WHAT IS COVERED: For a period of TWO (2) YEARS from the date of original retail purchase, EdgeStar will repair or replace any part free of charge, including labor, that fails due to a defect in materials or workmanship.
