Summary of Contents for Koldfront WAC25001W
- Page 1 Window Air Conditioner and Heater WAC25001W Owner’s Manual For more information on other great EdgeStar products on the web, go to http://www.edgestar.com...
-
Page 2: Important Safety Information
Important Safety Information Improper handling can cause serious damage to the appliance and/or to the user. Please read the following safety information. Electrical Safety Make sure your hands are dry before operating the unit. Do not wet the front housing or control panel. ... -
Page 3: Operation Of Safety Plug
Do not use the TEST and RESET buttons as an ON/OFF switch. Electrical products should not be disposed of with household waste. Please contact your local recycling center for more information on how to recycle electronic waste. Koldfront Window Air Conditioner... -
Page 4: Table Of Contents
Table of Contents IMPORTANT SAFETY INFORMATION ..............I ................PERATION OF AFETY TABLE OF CONTENTS ..................III INTRODUCTION ....................1 PARTS IDENTIFICATION ..................2 ......................2 ......................2 RONT PREPARATIONS FOR INSTALLATION .............. 3 WINDOW INSTALLATION INSTRUCTIONS ............4 ..........4 REPARING THE UNIT FOR WINDOW NSTALLATION Remove the Air Conditioner unit from Cabinet .......... -
Page 5: Introduction
Introduction Thank you for purchasing this Koldfront by EdgeStar window air conditioner. We are glad you chose us. We believe that your purchase of this product opens a relationship between you and EdgeStar. We will provide the customer support needed to nurture that relationship. -
Page 6: Parts Identification
Side View Control Panel Air Outlet Front Air Intake Panel Side and Back Vent Front View Top Channel CAUTION: Make sure the drain plug is firmly installed Side Curtains before using the unit to prevent leaking. Koldfront Window Air Conditioner... -
Page 7: Preparations For Installation
Preparations for Installation Tools Needed: The following measurements are required to properly install the air conditioner. Flat Screwdriver Window Width: 31” to 42” Phillips Screwdriver Window Minimum Height: 19 ½” Tape Measure Level NOTE: To avoid risk of injury and/or product/property damage, Drill please take the following precautions: Two or more people are needed to properly handle and install. -
Page 8: Window Installation Instructions
(Figure 2) 4. Push both sides of the metal cabinet to release the plastic tabs on each side of the front panel. (See Figure 3) Lift the front panel off of the unit. (Figure 3A) Koldfront Window Air Conditioner... -
Page 9: Attaching The Top Channel And Side Curtains
6. Disconnect the plug of the display panel from the unit and place the front panel to the side. (Figure 4) 7. Take out the shipping screws from the top and sides of the unit. (Figure 5) 8. Hold the cabinet while pulling on the base pan handle, and carefully remove the unit. - Page 10 6. Insert 2 washer head locking 7/16” screws into the holes located on the top leg of the window curtain frame. Do not tighten fully; the leg should slide freely. These will be tightened later in the installation. Koldfront Window Air Conditioner...
-
Page 11: Installing The Cabinet Into The Window
Installing the Cabinet into the Window NOTE: When choosing your window make sure Follow the steps listed below to install the cabinet into the window power supply cord is within 4 feet of a grounded 1. Center empty cabinet into window: 3-prong outlet ... -
Page 12: Install The Support Bracket
2. Assemble the sill angle bracket to the support brackets at the marked position. (Figure 10B) 3. Install the support brackets (with the sill angle brackets attached) to the correct holes in the bottom of the cabinet as shown below in Figure 11. Koldfront Window Air Conditioner... -
Page 13: Extend Side Curtains To Window Frame
Extend Side Curtains to Window Frame 1. Carefully raise the window to expose the window curtain panel locking screws. Loosen the screws so the curtains slide easily. 2. Extend the panels to fill the window opening completely. Tighten the locking screws on top. (Figure 12) 3. -
Page 14: Control Panel Operations
To choose the operating mode press Mode . Each time you press the button, a mode is selected -Auto, Cool, Dry, Heat to Fan. The indicator light beside the button will be illuminated and remain on once the mode is selected. Koldfront Window Air Conditioner... -
Page 15: To Operate On Auto Feature
To operate on Auto Feature: When you set the unit to “Auto” mode it will automatically select cooling, heating, or fan only operation depending on the desired temperature selected and the current room temperature. Once the desired temperature is reached, the unit will automatically maintain the room temperature. -
Page 16: To Use Timer (Auto Start/Stop) Feature
- Evaporator temperature sensor error Unplug the unit and plug back in. If error repeats, call for service. HS-Electric Heating sensor error Unplug the unit and plug back in. If error repeats, call for service. Koldfront Window Air Conditioner... -
Page 17: Additional Tips
Air Directional Louvers: The 4-way air directional louvers allow you to direct the air flow Up, Down, Left, and Right. To adjust the air directional louvers side to side use the center handles. Additional Tips: The “Cool” mode has an automatic 3 minute start delay if the unit is turned off and on too quickly. -
Page 18: Remote Operationsmaintenance
MODE program will be cancelled. SPEED MODE button- Press this button to selected desired operation mode from AUTO, COOL, DRY, HEAT, and FAN. TEMP DOWN button- Use to increase either Koldfront Window Air Conditioner temperature of timer depending on function. -
Page 19: Air Filter Cleaning
Maintenance Clean the air conditioner and filters regularly to maximize performance and efficiency, and prolong the unit’s life. Be sure to always unplug the air conditioner from the power outlet before cleaning to prevent injury or damage to person or property. Air Filter Cleaning The air filter should be checked at least once a month to see if NOTE: Winter Storage-... -
Page 20: Normal Sounds
To prolong the compressor's life, please wait at least 3 minutes before turning the unit back on after shutting it off. Inspect and keep the air filters clear by cleaning regularly. Perform routine maintenance. Koldfront Window Air Conditioner... -
Page 21: Troubleshooting
Troubleshooting Follow the troubleshooting guide below to resolve common issues. Issue Possible Cause Solution My air conditioner is not Wall plug Make sure the unit is functioning at all disconnected plugged in. LCDI power cord is Press the Reset button tripped on the LCDI cord. - Page 22 Remote control not Place remote control located within range with 20 feet and 180 degrees radius of the front of the unit. Remote control signal Remove obstruction. obstructed Room too cold Set temperature too Increase set temperature. Koldfront Window Air Conditioner...
-
Page 23: Specifications
Specifications Description of product Window Air Conditioner and Heater Model WAC25001W Voltage/Frequency 208-230V / 60Hz BTUs (Cooling / Heating) 25,000 / 16,000 Current (Cooling / Heating) 11.3 / 22.5A Color White Coolant R410A, 36.7 oz. Timer 24 Hour 26.5” x 26.5” x 18.6”... -
Page 24: Edgestar Limited Warranty
OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. SOME STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. Koldfront Window Air Conditioner... - Page 25 Register your product, download owner’s manuals, access additional troubleshooting resources, and obtain more information on other great EdgeStar & Koldfront products on the web at: http://www.edgestar.com Product contents and specifications may change without notice. Copyright © 2015 Living Direct, Inc.
