- Page 1 USER MANUAL 540MM AND 600MM SLOT-IN UPRIGHT RANGE COOKER WFE517, WFE547, WFE616, WFE619 WFE642, WFE647, WFG617...
-
Page 2: Table Of Contents
CONGRATULATIONS CONTENTS Congratulations and thank you for choosing our cooker. Important safety instructions ............3 We are sure you will find your new appliance a pleasure Description of your appliance ............4 to use and a great asset to your cooking. Before you use Before operating your appliance for the first time ..... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING • This appliance is not intended for use by persons • Do not place thick portions of food under the grill. (including children) with reduced physical, sensory Foods may curl, catch and ignite. or mental capabilities, or lack of experience and •... -
Page 4: Description Of Your Appliance
Oven indicator Model WFE517 lamp lamp Hotplate Grill Oven controls temperature temperature 2 hour timer selector selector Grill indicator Oven indicator Model WFE547 lamp lamp Grill Oven Dual ring Hotplate 2 hour temperature temperature hotplate controls timer selector selector control... - Page 5 Grill/Oven Model WFE642 indicator lamp Hotplate Dual ring controls Grill/Oven Grill/Oven 2 hour hotplate selector temperature timer control selector Grill indicator Oven indicator Model WFE647 lamp lamp Hotplate Grill Oven Dual ring controls hotplate temperature temperature 2 hour selector selector control timer Model WFG617...
-
Page 6: Before Operating Your Appliance For The First Time
BEFORE OPERATING YOUR APPLIANCE FOR THE FIRST TIME Preparing your appliance for the first time Grill in oven • Please remove all internal boxes and bags from the (refer to Fitting Oven Shelves) oven before operation. The grill dish with wire insert can be used in any of the two upper height positions (shelf positions 4 and 5) •... -
Page 7: Installing Your Oven Accessories
INSTALLING YOUR OVEN ACCESSORIES Trivets Burner crowns and caps • Take care when placing the trivets as dropping them • The burner crown must be fitted correctly into the may damage the hob or trivet. burner cup or damage will occur during operation. •... -
Page 8: Using The Hotplate
USING THE HOTPLATE Hotplate dos and dont’s Ceramic hotplates • Do not place heat resistant mats, wire mats or The cooktop is made from ceramic glass, a tough, durable aluminium foil under pots and pans. material that withstands heating and cooling without breaking. -
Page 9: Operating For The First Time
OPERATING FOR THE FIRST TIME Choosing utensils for electric hotplates Choosing utensils for gas hotplates Refer to the diagram below. Refer to the diagram below. Good Good (recessed base) (undersize) (convex base) (oversize) (undersize) Do not use utensils which are too large or too small. Installation and service warning (oversize) WARNING... -
Page 10: Using The Gas Cooker
USING THE GAS COOKER Lighting gas hotplate, grill and oven Gas hotplate Ensure burner caps, crowns and trivets are properly assembled. Electronic ignition (For models WFE616, WFE619 and WFE517) These hobs are fitted with mains powered electronic ignition. When the appliance has been connected and the power is on, depressing any knob will release sparks to all burners. - Page 11 USING THE GAS COOKER Gas hotplates (Energy rating) Medium heat burner (9.0 MJ/h) Used for normal cooking and simmering with mid size cookware items. High heat burner (12.1 MJ/h) Used for fast heating with large size cookware items. Intense heat wok burner (14.2 MJ/h) Used for very fast heating with woks and other large size cook ware items.
-
Page 12: General Hints And Tips
GENERAL HINTS AND TIPS General hints WARNING CAUTION • DO NOT place baking trays and oven dishes For best baking results preheat oven for 30 minutes. directly against the grid covering the fan at the back The material and finish of baking trays and dishes used of the oven. -
Page 13: Guide To Better Grilling
GUIDE TO BETTER GRILLING WARNING CAUTION No definite times can be given for grilling because this depends on your own taste and the size of the Using the Grill food. These times should only be used as a guide and remember to turn the food over halfway through the Separate Grill Grill with door open. -
Page 14: Operating The 120Min Mechanical Timer
OPERATING THE 120 MINUTE MECHANICAL RINGER TIMER (WHERE SUPPLIED) Operating your 120 minute ringer timer To set the timer, simply turn the knob clockwise to the required number of minutes. Note: For any time below ten minutes, turn the knob past the thirty minute mark, then turn it back to the required number of minutes. -
Page 15: Using The Oven
USING THE OVEN Fan baking Cooking guide The temperature in the oven is controlled by a thermostat. • Select the correct shelf location for food being The fan distributes the heat throughout the oven cooked. compartment. This allows: • The grill tray can be used in the oven as a baking dish. •... -
Page 16: Oven Guide
OVEN GUIDE The following is intended as a guide. Cooking variation is natural and to be expected. You should experiment with times, temperatures and recipes to obtain the best results to your own taste. Get to know your oven before making a service call. - Page 17 GET TO KNOW YOUR NEW OVEN WITH THIS ‘SIMPLE TEST CAKE’ Roasting Meat Although we strive for a perfect performing oven, it’s possible that there will be some variation in colour • You can use the grill tray and grill tray insert for when baking.
-
Page 18: Cooking
DEALING WITH COOKING PROBLEMS PROBLEM CAUSES WHAT TO DO Uneven cooking Incorrect shelf position Select shelf that puts food in centre of oven Oven tray too large Try other trays or dishes Trays not in centre Put trays in centre Air flow in oven uneven Rotate food during cooking Grill tray affecting thermostat... -
Page 19: Cleaning
CLEANING THE COOKER Ovens and hotplates are made from steel and enamel. Do not use abrasives and harsh scourers as they may WARNING CAUTION scratch the surface. DO NOT remove the oven door. Enamel Glass • Keep enamel clean by wiping it with a soft cloth •... - Page 20 CLEANING THE COOKER CLEANING YOUR OVEN (CONTINUED) ACCESSORIES Cleaning the grill WARNING WARNING Grill tray and grill pan Grill • Wash the grill tray and grill pan in hot soapy water. • Always keep the grill tray and grill tray insert clean, as any fat deposits may catch fire.
-
Page 21: Solving Problems
SOLVING PROBLEMS Faults Further information If there is a problem with the oven and/or grill, please: If you need more information, service, replacement parts or have a warranty enquiry, please contact the Customer • Check the points listed below before calling for Care Centre: service. -
Page 22: Installing The Appliance
INSTALLING THE APPLIANCE (600mm wide product) Cabinet requirements Recommended cabinet design This appliance has been designed to ‘slot-in’ to a 600mm Clearance to side wall wide gap built-in standard kitchen cabinets. As such the (refer notes) appliance can be installed to suit the height of the benches 600mm 600mm minimum... - Page 23 Fitting the anti-tilt plate & stabilising bolt Rear cover Cooker Stability NOTE: To ensure cooker stability, both the anti-tilt plate and stability bolt MUST be installed on all cookers (electric and gas). Installation Sequence 48mm to side The cooker is delivered with the anti-tilt plate. Locate of plate the anti-tilt plate against the rear wall.
-
Page 24: 540Mm
INSTALLING THE APPLIANCE (540mm wide product) Cabinet Requirements Position anti-tilt plate to the rear wall and 25mm from side of cupboard. Securely fix anti-tilt plate to the floor This appliance has been designed to ‘slot-in’ to a 540mm with fasteners. Adjust levelling feet on cooker as required. wide gap built-in standard kitchen cabinets. - Page 25 WFE616 and WFG617 models are fitted with appliance in an accessible position (AS/NZS 3000 - a 10-Amp service cord. Clause 4.7.1). Hard wiring detail (WFE547, WFE642 and WFE647 • Wiring MUST be protected against mechanical failure models only) (AS/NZS 3000 - Clause 3.9).
- Page 26 650mm INSTALLATION Wiring connection for gas cooker Operation on SNG (WFG617 models only) To allow for disconnection of the appliance after • If the cooker is to be used with SNG, then the grill installation, the plug must be accessible after installation. burner MUST be modified by the replacement of the shutter, which fits into the throat of the grill burner.
- Page 27 INSTALLATION Gas requirements This appliance must be installed by an authorised person, according to all codes and regulations of: • AS/NZS 5601.1 (particular attention to clause 6.10.1 and figure 6.3 on page 97, and clause 6.10.1.11) The cookers come in two gas types: Natural gas and Universal LPG.
- Page 28 LPG CONVERSION DONG Y ANG – IMPORTANT (MODELS WFE517, WFE616 AND WFE619 ONLY) This appliance is fitted with Natural Gas burner injectors. One by one, turn the knobs to minimum and screw in the bypass screw (accessible when the knob is Please follow the procedure below if a conversion to suit removed) until a small stable flame results.
- Page 29 LPG CONVERSION CHANT – IMPORTANT (MODELS WFE517, WFE616 AND WFE619 ONLY) This appliance is supplied set up for Natural Gas usage. 9. One by one, turn the knobs to minimum and screw A conversion kit is included with the product for Universal in the bypass screw (accessible when the knob is LPG usage.
-
Page 30: Testing The Operation Of The Gas Cooker
TESTING THE OPERATION OF THE GAS COOKER NOTE: You MUST test the cooker after installation, before Check that the regulator has been fitted to the gas you hand it over to the customer. supply line in the correct orientation, the arrow on the base of the body indicates the direction of gas flow. -
Page 31: Warranty
Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND APPLIANCE: BUILT-IN OVEN, COOKTOP AND FREESTANDING COOKERS This document sets out the terms and conditions of the product 7. You may not make a claim under this warranty unless the defect claimed is due to faulty or defective parts or workmanship. - Page 32 Top Service encompasses the after sales service provided by The Electrolux Group to consumers including delivery, home service and spare parts. Westinghouse. We are part of the Electrolux family. Share more of our thinking at electrolux.com.au and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation.
