USER MANUAL
Enjoy peace of mind.
Register your appliance today.
Stay updated on better living services, safety notices and
shop for accessories.
1. O pen the camera app on your smartphone and
point at the QR code to scan
Product Registration QR code is located on the
front of your appliance or inside the door rim *.
2. Tap the notification or link to open the registration form
3. Complete your details and enjoy peace of mind
*Exact location of QR code may vary depending on oven model
spire Plus, Gas FSC H2H
E FRONT ASSY)
CAVITY)
o seal)
ASSIS VULCAN FS)
OOLING DECK)
OVEN)
bly (CONTROL PANEL)
AGE DOOR)
(BUMP STOP.1)
(BUMP STOP.2)
TERMINAL COVER)
OVEN CAVITY SCREW #8.6)
or (REGULATOR)
OVEN CAVITY SCREW #8.5)
OVEN CAVITY SCREW #8.4)
OVEN CAVITY SCREW #8.3)
OVEN CAVITY SCREW #8.2)
OVEN CAVITY SCREW #8.1)
COOLING DECK SCREW #8.2)
COOLING DECK SCREW #8.1)
HOB SCREW #8.1)
HOB SCREW #8.2)
HOB SCREW #8.3)
701-009-033.45)
701-009-033.46)
COOLING DECK SCREW #8.3)
COOLING DECK SCREW #8.4)
COOLING DECK SCREW #8.5)
COOLING DECK SCREW #8.6)
z
x
y
90cm COOKING
APPLIANCES
WFEP9717DD
1

Advertisement

Table of Contents
loading

Related Manuals for Westinghouse WFEP9717DD

Summary of Contents for Westinghouse WFEP9717DD

  • Page 1 TERMINAL COVER) OVEN CAVITY SCREW #8.6) or (REGULATOR) OVEN CAVITY SCREW #8.5) OVEN CAVITY SCREW #8.4) OVEN CAVITY SCREW #8.3) WFEP9717DD OVEN CAVITY SCREW #8.2) OVEN CAVITY SCREW #8.1) COOLING DECK SCREW #8.2) COOLING DECK SCREW #8.1) HOB SCREW #8.1) HOB SCREW #8.2)

  • Page 2: Table Of Contents

    CONGRATULATIONS CONTENTS Congratulations and thank you for choosing our product. Important safety instructions ............3 Product description ................5 We are sure you will find your new cooker a pleasure to use and a great asset to your cooking. Before you use the Installation of the appliance ............

  • Page 3: Important Safety Instructions

    Westinghouse manufacturer’s warranty • Ensure that all specified vents, openings and provided with your product. Products must be airspaces are not blocked.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING WARNING WARNING Oven Child safety • During use the appliance becomes hot. Care should • This appliance is not intended for use by persons be taken to avoid touching the hot surfaces inside the (including children) with reduced physical, sensory oven.

  • Page 5: Product Description

    (Refer to Chapter ‘Get to know your cooktop’) Oven door Clip on kick panel (Select model only) Storage compartment (Refer to Chapter ‘Installation’) (Selected model only) Control Panel Model WFEP9717DD Gas hob Oven function Oven/Grill burner selector temperature controls control...

  • Page 6: Installation Of The Appliance

    Cabinet requirement if combustible surfaces are protected in accordance with AS/NZS 5601.1, or AS/NZS 5601.2. Model WFEP9717DD is designed to fit into a 900mm • When setting the cooker height, ensure the top of wide gap between standard kitchen cabinets. The...
  • Page 7 To ensure cooker stability, the anti-tilt brackets must be installed. Four screw-in feet are supplied with the appliance and can be found in the accessories pack in the oven. WFEP9717DD is supplied with a clip-on kick panel. Cabinet construction for freestanding installation INSTALLATION Of ThE APPLIANCE...
  • Page 8 Freestanding installation (continued) Gently close the door until it comes to a stop. Then lift the door off the hinge. Installation of screw-in feet • Freestanding appliance are supplied with four screw-in feet in the internal accessory pack. The screw-in feet can be adjusted by turning the lower half clockwise or anti-clockwise.
  • Page 9 INSTALLATION OF THE APPLIANCE (CONTINUED) Leveling oven Place a level in the oven as below making sure the level sits on the front and rear forms. Adjust the feet accordingly to level the appliance. If your kitchen has a 900mm height kitchen bench top, follow the quick measurement guide below before Installing splashback putting the cooker upright...
  • Page 10 Freestanding installation (continued) Installation the anti-tilt brackets To ensure cooker stability, the anti-tilt brackets must be installed. There are left and right engagement slots for the anti-tilt bracket at the bottom rear of the appliance. The following steps must be followed to ensure the correct installation of anti-tilt brackets and the stability of the appliances.
  • Page 11 INSTALLATION OF THE APPLIANCE (CONTINUED) Freestanding installation (continued) WARNING WARNING • Appropriate fasteners must be used to suit the type of wall on which the anti-tilt brackets are installed. • Freestanding unit must be pushed up against the wall on installation. On gas units check that the gas hose, if used, has not been kinked during installation.
  • Page 12 • Gas only: check that the gas hose, if used, has not been kinked during installation. Installing the clip-on kick panel Model WFEP9717DD is supplied with a clip-on kick panel that can be assembled to clip onto the front feet for a more integrated and seamless kitchen appearance.
  • Page 13 INSTALLATION OF THE APPLIANCE (CONTINUED) Freestanding installation (continued) Make sure both clip modules are in the same orientation after installation. Clip the kick panel onto the front feet of the appliance. Make sure the kick panel snaps onto the larger section of the front feet.
  • Page 14 Slot-in installation The slot-in type installation use the appliance as supplied. The appliance can be mounted on a plinth. This enables a continuous cupboard kickboard to be installed, giving a more integrated appearance. There is no clearance requirement between oven and adjacent side cabinets.
  • Page 15 INSTALLATION OF THE APPLIANCE (CONTINUED) Slot-in installation (continued) • The anti-tilt brackets are to be secured to the back • Once services are connected, product can be lifted wall with appropriate fasteners. onto the plinth and pushed back carefully, ensuring the appliance engages into both brackets at the rear •...

  • Page 16: Wiring Requirements

    This appliance must be installed by an authorised person, according to all codes and regulations of: Supply cord size required: • Electrical supply authorities. WFEP9717DD - 4.0mm • Building regulations. • Local government and council authorities. The Data plate gives information about rating and is •...

  • Page 17: Installing The Freestanding Cooker

    INSTALLING THE FREESTANDING COOKER Model WFEP9717DD For WFEP9717DD The following table shows the injector sizes for each burner. Gas hose restraints point to regulator Gas connection point INJECTOR ORIfICE NATURAL UNIVERSAL LPG to regulator Low heat burner 1.00mm 0.55mm Medium heat burner 1.35mm...

  • Page 18: Lpg Conversion Gas Cooktop Model

    LPG CONVERSION GAS COOKTOP MODEL A conversion kit is included with the product for 10. Attach the LPG sticker to the cooker, near the gas Universal LPG usage. The conversion kit contains 5 or supply inlet. Cover the Natural Gas label that is 7 injectors (refer to LPG conversion table) and 1 LPG factory fitted.

  • Page 19: Testing The Operation Of The Gas Cooker

    TESTING THE OPERATION OF THE GAS COOKER Checking gas supply When maximum flame appearance is correct, then check the turn-down setting on each burner. If the settings 1. Check the manometer zero point is correct. appear to be incorrect, proceed as follows: 2.

  • Page 20: Before Operating Your Appliance For The First Time

    BEFORE OPERATING YOUR APPLIANCE FOR THE FIRST TIME Preparing your appliance for the first time Setting the time • Please remove all internal boxes and bags from the If you have purchased a model fitted with an electronic oven before operation. or programmable timer, you must set the time of day before you can operate your appliance.

  • Page 21: Installing Your Oven Accessories

    INSTALLING YOUR OVEN ACCESSORIES Slides (telescopic runners) (on selected models) Installing the side racks 1. Insert the rear peg into the rear access hole provided, 1. The selected models are supplied with a set of slides ensuring peg is fully inserted. and instructions on how to assemble.
  • Page 22 Fitting grill dish and insert Your oven comes with a full width grill dish and a grill insert. The grill dish insert is designed with flexibility to adjust distance between the food and the grill element. Maximum grill power Grill dish insert brings the food closer to the grill element.

  • Page 23: Installing Burners And Trivets

    INSTALLING BURNERS AND TRIVETS Installing burners Trivet installation sequence The burner crown must be fitted correctly into the Install the middle trivet first by aligning the trivet with burner cup or damage will occur during operation. the wok burner and gently placing the trivet on hob. •...

  • Page 24: Getting To Know Your Cooktop

    GETTING TO KNOW YOUR COOKTOP Model WFEP9717DD Using your gas hot plates To light a burner with this knob, firstly depress and turn anti-clockwise to the ‘High’ flame position. The knob maybe released once the flame is established 1. Low heat burner (5.1MJ/h) and turned further anti-clockwise to reduce the flame Used for simmering with small cookware items.

  • Page 25: Using Your Oven

    USING YOUR OVEN COOKING FUNCTIONS Symbol Function description Fan Forced Heat comes from the element surrounding the fan. This fan circulates the hot air around the oven cavity so that you can put your food in different places in the oven and still cook them at the same time.
  • Page 26 OPERATING SEQUENCE USING THE APPLIANCE Select the oven function Control panel Turn the oven function selector clockwise to select the Control panel sensor fields desired oven function. Oven Timer NOTE: each oven function has a default temperature which can then be adjusted as outlined below. Fast heat up This knob cannot be turned anticlockwise...
  • Page 27 USING YOUR OVEN (CONTINUED) BEFORE FIRST USE WARNING Refer to safety chapters. Initial cleaning Before the first use, clean the empty oven and set the time: The display with the maximum number of functions set. Display indicators Remove all accessories and removable shelf supports from Lock the oven.
  • Page 28 DAILY USE Select Assisted Cooking. Press OK. Start cooking Set a heating function. Select the dish. Press OK. Refer to “Menu structure” chapter. Set the temperature. P1 - P41 Insert the dish into the oven. Confirm setting. How to set: Assisted Cooking Every dish in this submenu has a recommended function and temperature.
  • Page 29 USING YOUR OVEN (CONTINUED) CLOCK FUNCTIONS Press OK again. Clock function Application Minute minder. When the timer ends, the signal sounds. Cooking time. When the timer ends, the signal sounds and the heating function stops. Rotate Temperature Selector until the current time is Time Delay.
  • Page 30 How to set: Minute minder How to set: Cooking time Press: Timer Choose a heating function and set the temperature. Press repeatedly: Timer The display shows: Set the Minute minder The display shows: h:min STOP Press OK. Set the cooking time. Press OK.
  • Page 31 How to set: Time Delay Select the heating function. START STOP Set the end time. Press repeatedly: Timer Press OK. The display shows: the time of day h:min Timer starts counting down immediately. START STOP Set the start time. How to set: Child lock Press and hold Lock to turn Child Lock ON/OFF.
  • Page 32 How to change: Settings Press OK to confirm selection. Select Adjust the value and press OK. Menu structure Assisted cooking Cleaning Settings Select Settings. Press OK. Settings Time of Day Change Display Brightness Change 1 - Beep Key Tones 2 - Click 3 - Sound off Select the required setting 01 to 11 Buzzer Volume...

  • Page 33: Easybake +Steam

    EASYBAKE +STEAM Your WFEP9717DD has the ability to add steam while baking. Cooking with steam is a great addition to straight ‘hot air’ cooking. Steam brings out all the natural flavours and goodness in the food, cooks evenly from surface to centre and retains more nutrients and vitamins.

  • Page 34: Cooking Test

    COOKING TEST Get to know your new oven with this • The grill tray can be used in the oven as a baking dish, except in oven shelf location 1. ‘Simple Test Cake’ • Make sure dishes will fit into the oven before you Although we strive for a perfect performing oven, it’s switch it on.

  • Page 35: Cooking Guide

    COOKING GUIDE Choosing the best oven settings The following table is intended as a guide and experience may show some variation in cooking times necessary to meet individual requirements. We recommend that you preheat your oven for 30 minutes. Modes without Oven Fan fOOD TEMPERATURE ˚C OVEN ShELf POSITION*...
  • Page 36 EasyBake +Steam function WATER IN CAVITy TEMPERATURE OVEN ShELf fOOD TIME IN MINUTES WELL (ML) • POSITION* Yeast goods Bread loaves 180 - 200 2 or 3 35 - 45 Bread rolls 190 - 210 2 or 3 20 - 25 Gluten free bread 180 - 200 2 or 3...
  • Page 37 COOKING GUIDE (CONTINUED) AirFry Cooking Guide We recommend that you pre-heat the oven for 5 minutes for the best AirFry performance. TEMPERATURE OVEN ShELf fOOD TIME IN MINUTES • POSITION* Potatoes Frozen chips 2 or 3 18 - 20 Potato wedges 20 - 23 Coated/battered Chicken drummetts/wingettes...

  • Page 38: Dealing With Cooking Problems

    DEALING WITH COOKING PROBLEMS (See also troubleshooting) PROBLEM CAUSES REMEDIES Uneven cooking: • Incorrect shelf position. – Select shelf that puts food in the centre of the oven. • Oven tray too large. – Experiment with other trays or dishes. •...

  • Page 39: Cleaning Your Oven

    CLEANING YOUR OVEN Gas hotplate WARNING WARNING • The trivets can be removed for cleaning by carefully lifting them from the hob. • Always make sure that the oven is electrically isolated before cleaning. This can be done by • Clean by washing with warm soapy water. the functional switch nearby.
  • Page 40 CAUTION Ensure the appliance is off and cool before cleaning. Enamel (on burner skirts and trivets) Persistent stains may require rubbing with a nylon scourer or creamed powder cleansers. Household enamel cleaners are available, follow the manufacturer’s instructions in their use. Harsh abrasive cleaners, powder cleaners, steel wool or wax polishes should not be used.
  • Page 41 Ceramic Cooktop Cleaning CUSTOMER ADVICE Sometimes SURFACE stains appear to be a “bubble” mark under the ceramic glass. These can be cleaned off with a razor blade scraper and ceramic cleaner. Keeping the ceramic cooktop clean and protected will keep it in good condition and help avoid breakage. Ceramic Cerapol Ceraseal...
  • Page 42 Stainless Steel Cooktop Cleaning NOTE: Ensure any oil is cleaned off the hob before use, otherwise it may cause the hob to turn a yellowish colour. All grades of stainless steel may stain, discolour or attain an adhering layer of grime in normal operation.

  • Page 43: Cleaning Your Oven Accessories

    CLEANING YOUR OVEN ACCESSORIES Removing the trays and shelves from your Cleaning your oven door appliance The oven door has been designed to allow the two inner door glasses to be removed for cleaning without • Slide the dish and grill tray towards you until they removing the door from the product.
  • Page 44 Cleaning your oven door Changing the light globes • There are 2 light globes located in the top of the oven cavity towards the front. The light globe glass is WARNING WARNING accessible between the passes of the upper element. •...

  • Page 45: Steam Assisted Cleaning

    STEAM ASSISTED CLEANING Steam Assisted Clean This function assists in the removal of food residue from inside the oven. This method is effective in removing light soiling only. It is not effective in removing stubborn baked-on stains. This function can only be used when the oven is cold.

  • Page 46: Cleaning Your Pyrolytic Oven

    CLEANING YOUR PYROLYTIC OVEN PYROLYTIC CLEANING THE OVEN Heavy clean When the oven is very dirty it may need a longer cycle Pyrolytic cleaning of the oven cavity to clean it thoroughly. This cycle will clean the dirtiest of The oven has the Pyrolytic self-cleaning function. It ovens.

  • Page 47: Troubleshooting

    TROUBLESHOOTING Faults If there is a problem with the oven and/or grill, please: • Check the points listed below before calling for service. NOTE: We may charge for service even in the It may be possible to avoid a call by fixing the problem guarantee period if your problem is due to the yourself –...
  • Page 48 TROUBLESHOOTING (CONTINUED) NOTE: Only authorised personnel should carry out servicing. If the household fuse continues to blow, call the Customer Care Centre. In the event of a power failure the gas burners may be lit with a hand held igniter and used. Take care to avoid letting unburnt gas flow for more than 5 seconds when attempting to light the burner.

  • Page 49: Warranty

    (c) ‘ASC’ means Electrolux’s authorised serviced centres; the Appliance; (d) ‘Westinghouse’ is the brand controlled by Electrolux Home Products In addition, Electrolux is not liable under this warranty if: Pty Ltd of 163 O’Riordan Street, Mascot NSW 2020, ABN 51 004...
  • Page 50 0800 10 66 10 email: customercare@electrolux.co.nz web: westinghouse.co.nz and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license by Electrolux Home Products Pty Ltd. All Rights Reserved. © 2023 Electrolux Home Products Pty Ltd ABN 51 004 762 341...
