- Page 1 MITSUBISHI ELECTRIC E1071 Installation manual English MA00777A 2006-04...
- Page 2 This manual explains how to install the operator terminal. Please refer to the reference manual for further information. © Mitsubishi Electric, MA00777A, 2006-04 The information in this document is subject to change without notice and is provided as available at the time of printing.
-
Page 3: Table Of Contents
4.2 Touch Screen and Overlay ............. 4-1 4.2.1 Autotex F250....................4-1 4.2.2 Touch Screen Surface ..................4-2 4.2.3 Autoflex EB ....................4-3 5 Operator Terminal Drawings ............5-1 5.1 Communication Ports..............5-1 5.2 E1071 Outline ................5-2 Mitsubishi Electric, MA00777A... - Page 4 Table of Contents Mitsubishi Electric, MA00777A...
-
Page 5: Safety Precautions
– Keep the operator terminal clean. – Emergency stop and other safety functions may not be controlled from the operator terminal. – Do not use too much force or sharp objects when touching the keys, display etc. Mitsubishi Electric, MA00777A... -
Page 6: Service And Maintenance
1.5 Dismantling and Scrapping – The operator terminal or parts thereof shall be recycled according to local regulations. – The following components contain substances that might be hazardous to health and the environment: lithium battery, electrolytic capacitor and display. Mitsubishi Electric, MA00777A... -
Page 7: Installation
Dropping it or letting it fall may cause damage. 2. Place the panel cut out where the operator terminal is to be situated, draw along the outer sides of the holes and cut according to the markings. Mitsubishi Electric, MA00777A... - Page 8 - Ensure that the voltage and polarity of the power source is correct. Power Controller RS422/RS485 24V DC 24V DC RS232 Ethernet 5. Carefully remove the laminated film over the operator terminal display, to avoid static electricity that could damage the terminal. Mitsubishi Electric, MA00777A...
-
Page 9: Mode Switches
Cables, peripheral equipment and accessories must be suitable for the application and its environment. For further details or recommendations, please refer to the supplier. Caution When using a compact flash card, do not remove the card when the busy indicator is illuminated. Mitsubishi Electric, MA00777A... - Page 10 Installation Mitsubishi Electric, MA00777A...
-
Page 11: Technical Data
EN61000-6-4 emission and EN61000-6-2 immunity. UL, cUL approvals UL 1604 Class I, Div 2 / UL 508 / UL 50 4x indoor use only (when procuct or packing is marked) NEMA 4x indoor use only * See section Chemical Resistance Mitsubishi Electric, MA00777A... - Page 12 Technical Data Mitsubishi Electric, MA00777A...
-
Page 13: Chemical Resistance
Hydrochloric acid <36% Potassium carbonate Metyl ethyl ketone Nitric acid <10% Washing powders Dioxan Trichloracetic acid <50% Fabric conditioner Cyclohexanone Sulphuric acid <10% Ferric chloride Ethanol Formaldehyde 37% - 42% Ferrous chlorid Isophorone Potassium hydroxide <30% Dibutyl Phthalate Mitsubishi Electric, MA00777A... -
Page 14: Touch Screen Surface
4.2.2 Touch Screen Surface The touch screen surface on the operator terminal withstands exposure to the following solvents without visible change: Solvents Time Acetone 10 minutes Isopropanol 10 minutes Toulene 5 hours Mitsubishi Electric, MA00777A... -
Page 15: Autoflex Eb
Autoflex withstands DIN 42 115 Part 2 exposure of up to 1 hour duration to glacial acetic acid without visible change. Autoflex is not resistant to high pressure steam at over 100 °C or the following chemicals: Concentrated mineral acids Benzyl alcohol Concentrated caustic solution Mehylene chloride Mitsubishi Electric, MA00777A... - Page 16 Very slight discoloration was noted under critical viewing conditions with the following materials: Tomato juice Tomato ketchup Lemon juice Mustard Outdoor Use In common with all polyester based films Autoflex EB is not suitable for use in conditions of long term exposure to direct sunlight. Mitsubishi Electric, MA00777A...
-
Page 17: Operator Terminal Drawings
Operator Terminal Drawings Operator Terminal Drawings 5.1 Communication Ports RS-232 RS-422 RS-485 RS-422/485 Ethernet Drawing No. S-5005, Date 2004-10-27 Mitsubishi Electric, MA00777... -
Page 18: E1071 Outline
Operator Terminal Drawings 5.2 E1071 Outline Drawing No. S-5055, Date 2004-10-26 Mitsubishi Electric, MA00777... - Page 20 MITSUBISHI ELECTRIC Mitsubishi Electric Automation, Inc. 500 Corporate Woods Parkway Vernon Hills, IL 60061, USA Mitsubishi Electric Europe B.V. Gothaer Strasse 8 D-40880 Ratingen, Germany...
