  • Page 1 GRAPHIC OPERATION TERMINAL GOT2000 Series User's Manual (Hardware)

  • Page 3: Safety Precautions

    Thank you for choosing Mitsubishi Electric Graphic Operation Terminal (Mitsubishi Electric GOT). Read this manual and make sure you understand the functions and performance of the GOT thoroughly in advance to ensure correct use. SAFETY PRECAUTIONS (Always read these precautions before using this equipment.) Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full attention to safety to handle the product correctly.
  • Page 4 [DESIGN PRECAUTIONS] WARNING When the GOT backlight has a failure, the GOT status will be as follows. Failure to observe this instruction may result in an accident due to incorrect output or malfunction. • GT27, GT25, GT23 The POWER LED blinks (orange/blue), the display section dims, and inputs by a touch switch are disabled.
  • Page 5 [DESIGN PRECAUTIONS] CAUTION Do not bundle the control and communication cables with main-circuit, power or other wiring. Run the above cables separately from such wiring and keep them a minimum of 100mm apart. Not doing so noise can cause a malfunction. Do not press the GOT display section with a pointed material as a pen or driver.
  • Page 6 [MOUNTING PRECAUTIONS] CAUTION Use the GOT in the environment that satisfies the general specifications described in this manual. Not doing so can cause an electric shock, fire, malfunction or product damage or deterioration. When mounting the GOT to the control panel, tighten the mounting screws in the specified torque range with a Phillips-head screwdriver No.
  • Page 7 [MOUNTING PRECAUTIONS] CAUTION For GT2512F-S, GT2510F-V, and GT2508F-V, attach an environmental protection sheet dedicated to the open frame model (sold separately) to the display section. Or, attach a user-prepared environmental protection sheet. Not doing so may damage or soil the GOT or cause foreign matter to enter the GOT, resulting in a failure or malfunction.
  • Page 8 [WIRING PRECAUTIONS] WARNING When making a connection cable or installing wiring, make sure that no chips or wire offcuts enter the Handy GOT. Not doing so may cause a fire, failure or malfunction. [WIRING PRECAUTIONS] CAUTION When grounding the FG terminal and LG terminal of the GOT power supply section, note the following points.
  • Page 9 [WIRING PRECAUTIONS] CAUTION Exercise care to avoid foreign matter such as chips and wire offcuts entering the GOT. Not doing so can cause a fire, failure or malfunction. The module has an ingress prevention label on its top to prevent foreign matter, such as wire offcuts, from entering the module during wiring.
  • Page 10 Before touching the unit, always touch grounded metals, etc. to discharge static electricity from human body, etc. Not doing so can cause the unit to fail or malfunction. Use the battery manufactured by Mitsubishi Electric Corporation. Use of other batteries may cause a risk of fire or explosion. Dispose of used battery promptly.
  • Page 11 [STARTUP/MAINTENANCE PRECAUTIONS] CAUTION Before cleaning the GOT, be sure to turn off the power. Before cleaning, check the following items. • Ensure that there are no problems with the installation condition of the GOT to the control panel. • Ensure that there are no damages on the environmental protection sheet (not replaceable). If the environmental protection sheet peels or the cleaning solution enters between the sheet and the display section during cleaning, stop the cleaning immediately.
  • Page 12 [PRECAUTIONS WHEN THE DATA STORAGE IS IN USE] CAUTION If the data storage is removed from the GOT while being accessed by the GOT, the data storage and files may be damaged. Before removing the data storage from the GOT, check the SD card access LED, system signal, or others to make sure that the data storage is not accessed.
  • Page 13 [PRECAUTIONS FOR USE] CAUTION When you operate the Handy GOT while holding it, slide your hand through the hand strap on the back of the GOT to prevent falling. The hand strap length is adjustable. When you remove a cable from the Handy GOT, do not pull the cable portion. Doing so may damage the unit or cable, or cause a malfunction due to a cable connection fault.
  • Page 14 [PRECAUTIONS FOR REMOTE CONTROL] WARNING Remote control is available through a network by using GOT functions, including theSoftGOT-GOT link function, the remote personal computer operation function, the VNC server function, and the GOT Mobile function. If these functions are used to perform remote control of control equipment, the field operator may not notice the remote control, possibly leading to an accident.
  • Page 15 [TRANSPORTATION PRECAUTIONS] CAUTION When transporting lithium batteries, make sure to treat them based on the transport regulations. (Refer to 13.9 Transportation Precautions for details of the regulated models.) Make sure to transport the GOT main unit and/or relevant unit(s) in the manner they will not be exposed to the impact exceeding the impact resistance described in the general specifications of this manual, as they are precision devices.
  • Page 16 A - 14...

  • Page 17: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ......................... A - 1 CONTENTS ............................A - 13 List of Manuals for GT Works3 .......................A - 19 Abbreviations, Generic Terms, Model Icons ...................A - 21 1. OVERVIEW GOT ..............................1 - 2 Features............................1 - 2 2. SYSTEM CONFIGURATION Overall Configuration ........................
  • Page 18 Battery Specifications ........................3 - 58 4. PART NAMES AND SETTINGS GT27..............................4 - 2 GT2510-WX, GT2507-W ......................... 4 - 6 GT2507T-W ............................. 4 - 8 GT25-S, GT25-V..........................4 - 10 GT25HS-V ............................. 4 - 16 GT23.............................. 4 - 22 GT21..............................
  • Page 19 6.5.1 GT27 ............................6 - 28 6.5.2 GT2510-WX, GT2507-W......................6 - 29 6.5.3 GT2507T-W ........................... 6 - 30 6.5.4 GT25-S, GT25-V ........................6 - 31 6.5.5 GT23 ............................6 - 33 6.5.6 GT21 ............................6 - 33 Installing the GOT.......................... 6 - 34 6.6.1 GT27, GT25, GT23 ........................
  • Page 20 6.15.2 Removing the USB cable ....................... 6 - 96 6.16 Installing and Removing the Panel-Mounted USB Port Extension ..........6 - 98 6.16.1 Applicable panel-mounted USB port extension..............6 - 98 6.16.2 Parts name..........................6 - 98 6.16.3 Installing and removing the panel-mounted USB port extension ........... 6 - 98 7.
  • Page 21 9.3.2 Outside the panel ........................9 - 11 9.3.3 Attaching surge killers to control equipment ................9 - 12 Switch Wiring ..........................9 - 13 9.4.1 Overview for switch ........................ 9 - 13 9.4.2 Switch wiring example......................9 - 14 9.4.3 Operation switch wiring ......................
  • Page 22 13.2.2 GT2712-S..........................13 - 30 13.2.3 GT2710-S, GT2710-V ......................13 - 31 13.2.4 GT2708-S, GT2708-V ......................13 - 32 13.2.5 GT2705-V..........................13 - 33 13.3 Depth Dimensions and Cable Bend Radius for GT25 with an Extension Unit......13 - 34 13.3.1 GT2512-S, GT2510-V, GT2508-V ..................

  • Page 23: List Of Manuals For Gt Works3

    POINT POINT POINT e-Manual e-Manual refers to the Mitsubishi Electric FA electronic book manuals that can be browsed using a dedicated tool. e-Manual has the following features: • Required information can be cross-searched in multiple manuals. • Other manuals can be accessed from the links in the manual.
  • Page 24 Manual number Manual name Format (Model code) SH-081196ENG GOT2000 Series User's Manual (Monitor) PDF, e-Manual (1D7MJ7) A - 22...

  • Page 25: Abbreviations, Generic Terms, Model Icons

    Abbreviations, Generic Terms, Model Icons The following shows the abbreviations, generic terms, and model icons used in this manual. ■1. GOT (1) GOT2000 series Meaning of icon Abbreviations and generic terms Description Support support GT27-X GT2715-X GT2715-XTBA, GT2715-XTBD GT2712-S GT2712-STBA, GT2712-STWA, GT2712-STBD, GT2712-STWD GT27-S GT2710-S GT2710-STBA, GT2710-STBD...
  • Page 26 Meaning of icon Abbreviations and generic terms Description Support support All GT21 models GT21-W GT2107-W GT2107-WTBD, GT2107-WTSD GT21-Q GT2105-Q GT2105-QTBDS, GT2105-QMBDS GT21-R GT2104-R GT2104-RTBD GT2104-PMBD GT2104-PMBDS GT21 GT2104-P GT2104-PMBDS2 GT2104-PMBLS GT21-P GT2103-PMBD GT2103-PMBDS GT2103-P GT2103-PMBDS2 GT2103-PMBLS GT SoftGOT2000 GT SoftGOT2000 Version1 (2) GOT1000 series, GOT900 series, and GOT800 series Meaning of icon Abbreviations and generic terms...
  • Page 27 ■2. Communication unit Abbreviations and generic terms Description GT15-QBUS, GT15-QBUS2, GT15-ABUS, GT15-ABUS2, GT15-75QBUSL, Bus connection unit GT15-75QBUS2L, GT15-75ABUSL, GT15-75ABUS2L Serial communication unit GT15-RS2-9P, GT15-RS4-9S, GT15-RS4-TE MELSECNET/H communication unit GT15-J71LP23-25, GT15-J71BR13 CC-Link IE Controller Network communication unit GT15-J71GP23-SX CC-Link IE Field Network communication unit GT15-J71GF13-T2 CC-Link communication unit GT15-J61BT13...
  • Page 28 Abbreviations and generic terms Description GT15-70ATT-98, GT15-70ATT-87, GT15-60ATT-97, GT15-60ATT-96, GT15- Attachment 60ATT-87, GT15-60ATT-77, GT21-04RATT-40 Panel-mounted USB port extension GT14-C10EXUSB-4S, GT10-C10EXUSB-5S Connector conversion box GT16H-CNB-42S, GT16H-CNB-37S, GT11H-CNB-37S Emergency stop switch guard cover GT16H-60ESCOV, GT14H-50ESCOV Wall-mounting attachment GT14H-50ATT ■5. Software (1) Software related to GOT Abbreviations and generic terms Description GT Works3...
  • Page 29 (□ indicates a version.) SW□DNN-VIEWER-E type software package GX LogViewer (□ indicates a version.) Configuration and monitor tool for Mitsubishi Electric industrial computers (SW MI Configurator □ DNNMICONF-M) ( □ indicates a version.) SW□D5C-FBDQ-E type FBD software package for process control PX Developer (□...
  • Page 30 CLPA CC-Link Partner Association GE Intelligent Platforms, Inc. HMS Industrial Networks LS IS LS Industrial Systems Co., Ltd. MITSUBISHI ELECTRIC INDIA Mitsubishi Electric India Pvt. Ltd. ODVA Open DeviceNet Vendor Association, Inc. SCHNEIDER Schneider Electric SA SICK SICK AG SIEMENS...

  • Page 31: Overview

    1. OVERVIEW GOT ..........1 - 2 Features.

  • Page 32: Got

    The GOT is a device connected to a PLC and others to operate switches and to display lamps, data, and messages. Install the GOT on the panel surface of a control panel or an operating panel. Monitoring device values Data input, switch operation GOT2000 Features ■1.
  • Page 33 ■3. Enhanced compatibility with Mitsubishi Electric FA devices The sequence program monitor function enables enhanced compatibility with Mitsubishi Electric FA devices. You can save programs and data of Mitsubishi Electric FA devices (such as PLCs) to an SD card using the backup/ restoration function.
  • Page 34 1 - 4 1.2 Features...

  • Page 35: System Configuration

    2. SYSTEM CONFIGURATION Overall Configuration ....... . . 2 - 2 System Equipment .

  • Page 36: Overall Configuration

    Overall Configuration The following shows the overall configuration of the GOT2000 series. 2.1.1 Overall configuration of GT27, GT25-W, GT25-S, GT25-V, and GT21 GOT2000 Optional device Peripheral device Extension unit Barcode reader SD card Communication (Commercially unit available) RFID USB memory controller Option unit (Commercially...

  • Page 37: System Equipment

    System Equipment The following shows the system equipment of the GOT2000 series. ➠ 2.2.1 GOT ➠ 2.2.2 CC-Link IE Field Network communication unit set ➠ 2.2.3 Extension unit ➠ 2.2.4 Software ➠ 2.2.5 Option ➠ 2.2.6 Cable ➠ 2.2.7 Others 2.2.1 The following shows the meaning of the GOT model name.
  • Page 38 Display section, Display Panel Classification Model Screen size Power Remarks color color GT2715-XTBA GT2715 15" XGA Black GT2715-XTBD GT2712-STBA Black GT2712-STBD GT2712 12.1" SVGA GT2712-STWA White *1*2 GT2712-STWD Multimedia and GT2710-STBA 10.4" SVGA video/RGB GT2710-STBD compaible Black GT2710-VTBA TFT color GT27 Multi-touch GT2710...
  • Page 39 Display section, Display Panel Classification Model Screen size Power Remarks color color GT2310-VTBA GT2310 10.4" VGA GT2310-VTBD TFT color GT23 Black 65536 colors GT2308-VTBA GT2308 8.4" VGA GT2308-VTBD TFT color RS-232, GT2105-QTBDS 65536 colors RS-422/485 5.7" QVGA GT2105 Black [320 × 240 dots] TFT monochrome RS-232, GT2105-QMBDS...

  • Page 40: Cc-Link Ie Field Network Communication Unit Set

    2.2.2 CC-Link IE Field Network communication unit set Display section, Display Panel Classification Model Screen size Power Remarks color color GT2715-XTBA-GF GT2715 15" XGA Black GT2715-XTBD-GF GT2712-STBA-GF Black GT2712-STBD-GF GT2712 12.1" SVGA GT2712-STWA-GF White GT2712-STWD-GF GT2710-STBA-GF 10.4" SVGA GT2710-STBD-GF Black TFT color GT27 GT2710-VTBA-GF...

  • Page 41: Extension Unit

    2.2.3 Extension unit ■1. Communication unit Supported model Product name Model Specifications GT25-J71E71-100 Data transfer method: 100BASE-TX, 10BASE-T ○ Ethernet communication unit ○ GT15-RS2-9P RS-232 serial communication unit (D-sub 9-pin: male) ○ ○ RS-422/485 serial communication unit (D-sub 9-pin: female) GT15-RS4-9S ○...
  • Page 42 When [Operation Mode] is set to [Access Point] in [Wireless LAN Setting] of GT Designer3, up to five stations are connectable. The product with hardware version A or later (manufactured in December 2013) complies with the regulation. The product with hardware version A can be used only in Japan. The product with hardware version B or later (manufactured from October 2014) complies with the regulation.
  • Page 43 ■2. Option unit Supported model Product name Model Specifications USB slave (PictBridge) for printer connection, 1 channel Printer unit GT15-PRN ○ ○ Cable for connection between printer unit and printer (3m) included For video input (NTSC/PAL), 1 channel, recording video/playing Multimedia unit GT27-MMR-Z video files...

  • Page 44: Software

    2.2.4 Software ■1. Software Product name Model Description SW1DND-GTWK3-E Standard license product HMI/GOT Screen Design English SW1DND-GTWK3-EA Software Volume license product DVD-ROM version MELSOFT GT Works3 *1*6 SW1DND-GTWK3-EAZ Additional license product FA Integrated Engineering English Software SW2DND-IQWK-J Standard license product DVD-ROM version *2*3...
  • Page 45 2.2.5 Option ■1. Option for GT27, GT25-W, GT25-S, GT25-V, and GT21 Supported model Product name Model Description GT27-15PSGC For 15" ○ GT25-12PSGC For 12.1" ○ ○ • Antiglare type • Transparent GT25-10PSGC For 10.4" ○ ○ • With a hole for the USB environmental protection GT25-08PSGC For 8.4"...
  • Page 46 Supported model Product name Model Description GT25F-12ESGS For 12.1" ○ • For conforming to IP67F Environmental protection • Antiglare type sheet (for the open frame GT25F-10ESGS For 10.4" ○ • Slivery model) • 1 sheet GT25F-08ESGS For 8.4" ○ For 15/ GT25-UCOV 12.1/10.4/ ○...
  • Page 47 Supported model Product name Model Description GT15-70ATT-98 ○ ○ ○ For replacing GT168□, GT158□, A985GOT For 10.4" For replacing A870GOT-SWS/TWS or A8GT- GT15-70ATT-87 ○ ○ ○ 70GOT-TB/TW/SB/SW GT15-60ATT-97 For replacing GT167□, GT157□, A97□GOT ○ ○ ○ GT15-60ATT-96 For replacing A960GOT ○...
  • Page 48 ■2. Option for GT25HS-V ○: Usable, -: Not usable Supported model Product name Model Description GT2506HS-V GT2505HS-V • Clear type GT16H-60PSC For 6.5" ○ • A set of 5 sheets Protective sheet • Clear type GT14H-50PSC For 5.7" ○ • A set of 5 sheets GT16H-60ESCOV ○...

  • Page 49: Cable

    2.2.6 Cable ■1. Cable for MITSUBISHI ELECTRIC PLC Reco Supported model mmen Cable Product name Model Specifications length produ GT15-QC06B 0.6 m GT15-QC12B 1.2 m QCPU connection cable ○ QCPU ←→ GOT GOT-to-GOT GT15-QC30B ○ ○ GOT ←→ GOT connection cable...
  • Page 50 Reco Supported model mmen Cable Product name Model Specifications length produ GT01-C30R4-25P For connecting the QnA/ACPU/ FXCPU/motion controller (A GT01-C100R4-25P 10 m series) and the GOT GT01-C200R4-25P 20 m For connecting the RS-422 connector conversion cable (FA- CNV□CBL) and the GOT ○...
  • Page 51 Reco Supported model mmen Cable Product name Model Specifications length produ GT01-C10R4-8P For connecting the FXCPU and GT01-C30R4-8P For connecting the FXCPU ○ ○ GT01-C100R4-8P 10 m communication expansion board ○ ○ *3*7 and GOT GT01-C200R4-8P 20 m [MINI-DIN 8-pin ←→ D-sub 9 GT01-C300R4-8P 30 m pin]...
  • Page 52 Reco Supported model mmen Cable Product name Model Specifications length produ For connecting the Q/LCPU and For connecting L6ADP-R2 and ○ ○ GT01-C30R2-6P GOT/personal computer (GT ○ ○ *5*8 SoftGOT2000) [MINI-DIN 6-pin ←→ D-sub 9 pin] For connecting the Q/LCPU and Q/LCPU direct [MINI-DIN 6-pin ←→...
  • Page 53 Reco Supported model mmen Cable Product name Model Specifications length produ For connecting an external I/O unit (GT15-DIO) and external I/O ○ Conversion cable for connecting GT15-C03HTB 0.3 m ○ interface unit (A8GT-C05TK, ○ external I/O unit A8GT-C30TB, user-fabricated cable) for GOT-A900 For connecting an RGB image output device (external monitor, Analog RGB cable...
  • Page 54 FA-LTBGT2R4CBL□, FA-CNV240□CBL are developed by Mitsubishi Electric Engineering Company Limited and sold through your local sales office. The other products listed are developed by Mitsubishi Electric Systems & Service Co., LTD. and sold through your local sales office. This cable is usable for GT2104-PMBD, GT2103-PMBD.
  • Page 55 Supported model Cable Product name Model Specifications length GT09-C30R40101-9P For connecting an OMRON PLC/serial GT09-C100R40101-9P 10 m communication module/serial communication ○ ○ ○ ○ GT09-C200R40101-9P 20 m board and GOT GT09-C300R40101-9P 30 m GT09-C30R40102-9P GT09-C100R40102-9P 10 m For connecting an OMRON rack type host link RS-422 cable ○...
  • Page 56 ■4. Cable for SHARP PLC Supported model Cable Product name Model Specifications length GT09-C30R20601-15P RS-232 cable For connecting a SHARP PLC and GOT ○ ○ ○ GT09-C30R20602-15P GT09-C30R40601-15P GT09-C100R40601-15P 10 m GT09-C200R40601-15P 20 m GT09-C300R40601-15P 30 m GT09-C30R40602-15P GT09-C100R40602-15P 10 m RS-422 cable For connecting a SHARP PLC and GOT ○...
  • Page 57 Supported model Cable Product name Model Specifications length GT09-C30R40501-15P GT09-C100R40501-15P 10 m GT09-C200R40501-15P 20 m GT09-C300R40501-15P 30 m GT09-C30R40502-6C GT09-C100R40502-6C 10 m RS-422 cable For connecting a TOSHIBA PLC and GOT ○ ○ ○ GT09-C200R40502-6C 20 m GT09-C300R40502-6C 30 m GT09-C30R40503-15P GT09-C100R40503-15P 10 m...
  • Page 58 ■10. Cable for FUJI FA PLC Supported model Cable Product name Model Specifications length For connecting a FUJI FA RS-232C interface card/RS-232C interface capsule/RS-485 RS-232 cable GT09-C30R21003-25P ○ ○ ○ interface capsule/general-purpose interface module and GOT GT09-C30R41001-6T For connecting a FUJI FA RS-232C interface GT09-C100R41001-6T 10 m RS-422 cable...
  • Page 59 ■13. Cable for YOKOGAWA PLC and temperature controller Supported model Cable Product name Model Specifications length For connecting a YOKOGAWA CPU port/D- GT09-C30R20301-9P ○ ○ ○ sub 9-pin conversion cable and GOT For connecting a YOKOGAWA PC link module GT09-C30R20302-9P ○...

  • Page 60: Others

    For the validated models of the SD cards, refer to the following Technical News. ➠ Information of valid Non-Mitsubishi SD cards applicable for GOT2000 series(GOT-A-0065) For Technical News, go to the MITSUBISHI ELECTRIC FA Global Website. http://www.mitsubishielectric.co.jp/fa/ Product name Overview...

  • Page 61: Specifications

    3. SPECIFICATIONS General Specifications ....... . . 3 - 2 Performance Specifications .

  • Page 62: General Specifications

    General Specifications The following shows the general specifications of the GOT. 3.1.1 GT27, GT2510-WX, GT2507-W, GT25-S, GT25-V Item Specifications *2*7 Operating ambient temperature 0 °C to 55 °C Storage ambient temperature -20°C to 60°C Operating ambient humidity 10% RH to 90% RH, non-condensing Storage ambient humidity 10% RH to 90% RH, non-condensing Frequency...

  • Page 63: Gt2507T-W

    3.1.2 GT2507T-W CAUTION The GOT rugged model uses the environmental protection sheet (not replaceable) with UV protection function on the front surface. Therefore, it is possible to suppress deterioration of the touch panel or the liquid crystal display panel that may be caused by ultraviolet rays. Note that if the rugged model is exposed to ultraviolet rays for an extended period of time, the front surface may turn yellow.

  • Page 64: Gt25Hs-V

    3.1.3 GT25HS-V Item Specifications Operating ambient temperature 0 °C to 40 °C Storage ambient temperature -20 °C to 60 °C Operating ambient humidity 10% RH to 90% RH, non-condensing Storage ambient humidity 10% RH to 90% RH, non-condensing Frequency Acceleration Half amplitude Sweep count Under...

  • Page 65: Gt23

    3.1.4 GT23 Item Specifications 0 °C to 55 °C Operating ambient temperature Storage ambient temperature -20 °C to 60 °C Operating ambient humidity 10% RH to 90% RH, non-condensing Storage ambient humidity 10% RH to 90% RH, non-condensing Frequency Acceleration Half amplitude Sweep count Under...
  • Page 66 3.1.5 GT21 Item Specifications 0°C to 55°C (Horizontal installation), 0°C to 50°C (Vertical installation) Operating ambient temperature Storage ambient temperature -20°C to 60°C Operating ambient humidity 10% RH to 90% RH, non-condensing Storage ambient humidity 10% RH to 90% RH, non-condensing Frequency Acceleration Half amplitude...
  • Page 67 3 - 7 3.1 General Specifications...

  • Page 68: Performance Specifications

    Performance Specifications The following shows the performance specifications of the GOT. 3.2.1 GT27 ■1. GT2715-X Specifications Item GT2715-XTBA, GT2715-XTBD Display device TFT color LCD Screen size 15" Resolution XGA: 1024 × 768 dots Display size 304.1(11.97)(W) × 228.1(8.98)(H) mm(inch) Number of displayed 16-dot standard font: 64 characters ×...
  • Page 69 Specifications Item GT2715-XTBA, GT2715-XTBD Panel cut dimensions 383.5(15.10)(W) × 282.5(11.12)(H) mm(inch) Weight (excluding a fitting) 4.5(9.9) kg(lb) Compatible software package GT Works3 Version1.112S or later As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 70 ■2. GT2712-S Specifications Item GT2712-STBA, GT2712-STBD GT2712-STWA, GT2712-STWD Display device TFT color LCD Screen size 12.1" Resolution SVGA: 800 × 600 dots Display size 246(9.69) (W) × 184.5(7.26) (H) mm(inch) Number of displayed 16-dot standard font: 50 characters × 37 lines (two-byte characters) Display section characters 12-dot standard font: 66 characters ×...
  • Page 71 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 72 ■3. GT2710-S, GT2710-V Specifications Item GT2710-STBA GT2710-VTBA GT2710-VTWA GT2710-STBD GT2710-VTBD GT2710-VTWD Display device TFT color LCD Screen size 10.4" Resolution SVGA: 800 × 600 dots VGA: 640 × 480 dots Display size 211.2(8.31) (W) × 158.4(6.24) (H) mm(inch) 16-dot standard font: 50 characters Number of displayed ×...
  • Page 73 Specifications Item GT2710-STBA GT2710-VTBA GT2710-VTWA GT2710-STBD GT2710-VTBD GT2710-VTWD Compatible software package GT Works3 Version1.100E or later As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 74 ■4. GT2708-S, GT2708-V Specifications Item GT2708-STBA, GT2708-STBD GT2708-VTBA, GT2708-VTBD Display device TFT color LCD Screen size 8.4" Resolution SVGA: 800 × 600 dots VGA: 640 × 480 dots Display size 170.9(6.73) (W) × 128.2(5.05) (H) mm(inch) 16-dot standard font: 50 characters × 37 lines (two-byte 16-dot standard font: 40 characters ×...
  • Page 75 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 76 ■5. GT2705-V Specifications Item GT2705-VTBD Display device TFT color LCD Screen size 5.7" Resolution VGA: 640 × 480 dots Display size 115.2(4.54) (W) × 86.4(3.40) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 77 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.

  • Page 78: Gt2510-Wx, Gt2507-W

    3.2.2 GT2510-WX, GT2507-W ■1. GT2510-WX Specifications Item GT2510-WXTBD, GT2510-WXTSD Display device TFT color LCD Screen size 10.1" wide screen Resolution WXGA: 1280 × 800 dots Display size 216.96(8.54) (W) × 135.6(5.34) (H) mm(inch) Number of displayed 16-dot standard font: 80 characters × 50 lines (two-byte characters) Display section characters 12-dot standard font: 106 characters ×...
  • Page 79 Specifications Item GT2510-WXTBD, GT2510-WXTSD Panel cut dimensions 243.5(9.59) (W) × 185.5(7.30) (H) mm(inch) Weight (Excluding installation fitting) 1.2 (2.6) kg(lb) Compatible software package GT Works3 Version1.175H or later As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 80 ■2. GT2507-W Specifications Item GT2507-WTBD, GT2507-WTSD Display device TFT color LCD Screen size 7" wide screen Resolution WVGA: 800 × 480 dots Display size 152.40(6.00) (W) × 91.44(3.60) (H) mm(inch) Number of displayed 16-dot standard font: 50 characters × 30 rows (Two-byte characters) Display section characters 12-dot standard font: 66 characters ×...
  • Page 81 Specifications Item GT2507-WTBD, GT2507-WTSD Weight (excluding a fitting) 0.75(1.7) kg(lb) Compatible software package GT Works3 Version1.175H or later As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.

  • Page 82: Gt2507T-W

    3.2.3 GT2507T-W ■1. GT2507T-W Specifications Item GT2507T-WTSD Display device TFT color LCD Screen size 7" wide screen Resolution WVGA: 800 × 480 dots Display size 152.40(6.00) (W) × 91.44(3.60) (H) mm(inch) Number of displayed 16-dot standard font: 50 characters × 30 rows (Two-byte characters) Display section characters 12-dot standard font: 66 characters ×...
  • Page 83 Specifications Item GT2507T-WTSD External dimensions 214(8.43) (W) × 158(6.22) (H) × 55(2.17) (D) mm(inch) Panel cut dimensions 197(7.76) (W) × 141(5.55) (H) mm(inch) Weight (excluding a fitting) 1.2(2.6) kg(lb) Compatible software package GT Works3 Version1.175H or later As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.

  • Page 84: Gt25-S, Gt25-V

    3.2.4 GT25-S, GT25-V ■1. GT2512-S, GT2512F-S Specifications Item GT2512-STBA, GT2512-STBD GT2512F-STNA, GT2512F-STND Display device TFT color LCD Screen size 12.1" Resolution SVGA: 800 × 600 dots Display size 246(9.69) (W) × 184.5(7.26) (H) mm(inch) Number of displayed 16-dot standard font: 50 characters × 37 lines (two-byte characters) Display section characters 12-dot standard font: 66 characters ×...
  • Page 85 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 86 ■2. GT2510-V, GT2510F-V Specifications Item GT2510-VTBA, GT2510-VTBD GT2510-VTWA, GT2510-VTWD GT2510F-VTNA, GT2510F-VTND Display device TFT color LCD Screen size 10.4" Resolution VGA: 640 × 480 dots Display size 211.2(8.31) (W) × 158.4(6.24) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 87 Specifications Item GT2510-VTBA, GT2510-VTBD GT2510-VTWA, GT2510-VTWD GT2510F-VTNA, GT2510F-VTND Compatible software package GT Works3 Version1.112S or later GT Works3 Version1.150G or later As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 88 ■3. GT2508-V, GT2508F-V Specifications Item GT2508-VTBA, GT2508-VTBD GT2508-VTWA, GT2508-VTWD GT2508F-VTNA, GT2508F-VTND Display device TFT color LCD Screen size 8.4" Resolution VGA: 640 × 480 dots Display size 170.9(6.73) (W) × 128.2(5.05) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 89 Specifications Item GT2508-VTBA, GT2508-VTBD GT2508-VTWA, GT2508-VTWD GT2508F-VTNA, GT2508F-VTND Compatible software package GT Works3 Version1.112S or later GT Works3 Version1.150G or later As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 90 ■4. GT2505-V Specifications Item GT2505-VTBD Display device TFT color LCD Screen size 5.7" Resolution VGA: 640 × 480 dots Display size 115.2(4.54) (W) × 86.4(3.40) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 91 For the details of the GOT multi-drop connection, refer to the following. ➠ GOT2000 Series Connection Manual (Mitsubishi Electric Products) For GT Works3 Version1 The minimum size of a key that can be arranged. To ensure safe use of the product, the following settings are recommended.

  • Page 92: Gt25Hs-V

    3.2.5 GT25HS-V ■1. GT2506HS-V Specifications Item GT2506HS-VTBD Display device TFT color LCD Screen size 6.5" Resolution VGA: 640 × 480 dots Display size 132.5(5.22) (W) × 99.4(3.91) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 93 Specifications Item GT2506HS-VTBD Buzzer output Single tone (tone and tone length adjustable) POWER LED 2 colors (blue and orange) *6*8 IP65F Protective structure (When an external cable is connected. The rating is not applied to the relay connector side of the external cable.) 201(7.91) (W) ×...
  • Page 94 ■2. GT2505HS-V Specifications Item GT2505HS-VTBD Display device TFT color LCD Screen size 5.7" Resolution VGA: 640 × 480 dots Display size 115.2(4.54) (W) × 86.4(3.4) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 95 Specifications Item GT2505HS-VTBD POWER LED 2 colors (blue and orange) *6*8 IP65F Protective structure (When an external cable is connected. The rating is not applied to the relay connector side of the external cable.) 145(5.71) (W) × 185(7.28) (H) × 79.3(3.12) (D) mm(inch) External dimensions (Excluding projections such as the emergency stop switch) 0.79(1.7) kg(lb)

  • Page 96: Gt23

    3.2.6 GT23 ■1. GT2310-V Specifications Item GT2310-VTBA, GT2310-VTBD Display device TFT color LCD Screen size 10.4" Resolution VGA: 640 × 480 dots Display size 211.2(8.31) (W) × 158.4(6.24) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 97 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 98 ■2. GT2308-V Specifications Item GT2308-VTBA, GT2308-VTBD Display device TFT color LCD Screen size 8.4" Resolution VGA: 640 × 480 dots Display size 170.9(6.73) (W) × 128.2(5.05) (H) mm(inch) Number of displayed 16-dot standard font: 40 characters × 30 lines (two-byte characters) Display section characters 12-dot standard font: 53 characters ×...
  • Page 99 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.

  • Page 100: Gt21

    3.2.7 GT21 ■1. GT2107-W Specifications Item GT2107-WTBD, GT2107-WTSD Display device TFT color LCD Screen size 7" wide screen Resolution WVGA: 800 × 480 dots Display size 152.4 (6.00)(W) × 91.44 (3.60)(H) mm(inch) Display section Number of displayed 16-dot standard font: 50 characters × 30 rows (Two-byte characters) characters 12-dot standard font: 66 characters ×...
  • Page 101 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 102 ■2. GT2105-Q Specifications Item GT2105-QTBDS GT2105-QMBDS Display device TFT color LCD TFT monochrome LCD Screen size 5.7" Resolution QVGA: 320 × 240 dots Display size 115 (4.53)(W) × 86 (3.39)(H) mm(inch) Number of displayed 16-dot standard font: 20 characters × 15 rows (Two-byte characters) Display section characters 12-dot standard font: 26 characters ×...
  • Page 103 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 104 ■3. GT2104-R Specifications Item GT2104-RTBD Display device TFT color LCD Screen size 4.3" Resolution 480 × 272 dots Display size 95.0 (3.74)(W) × 53.8 (2.12)(H) mm(inch) Number of displayed 16-dot standard font: 30 characters × 17 rows (Two-byte characters) Display section characters 12-dot standard font: 40 characters ×...
  • Page 105 As a characteristic of liquid crystal display panels, bright dots (always lit) and dark dots (never lit) may appear on the panel. Since liquid crystal display panels comprise a great number of display elements, the appearance of bright and dark dots cannot be reduced to zero.
  • Page 106 ■4. GT2104-P Specifications Item GT2104-PMBD GT2104-PMBDS GT2104-PMBDS2 GT2104-PMBLS Display device TFT monochrome LCD Screen size 4.5" Resolution 384 × 128 dots Display size 109.4 (4.31)(W) × 36.5 (1.44)(H) mm(inch) Number of 16-dot standard font: 24 characters × 8 rows (Two-byte characters) Display section displayed 12-dot standard font: 32 characters ×...
  • Page 107 Specifications Item GT2104-PMBD GT2104-PMBDS GT2104-PMBDS2 GT2104-PMBLS USB (Host) 1 channel (rear face) USB (Device) USB version: USB1.1 (Full-Speed 12 Mbps), Connector shape: USB Mini-B Built-in interface SD card 1 channel, SDHC compliant (maximum 32 GB) Extension interface Auxiliary extension interface Side interface Buzzer output Single tone (Tone length adjustable)
  • Page 108 ■5. GT2103-P Specifications Item GT2103-PMBD GT2103-PMBDS GT2103-PMBDS2 GT2103-PMBLS Display device TFT monochrome LCD Screen size 3.8" Resolution 320 × 128 dots Display size 89.0 (3.50)(W) × 35.6 (1.40)(H) mm(inch) Number of displayed 16-dot standard font: 20 characters × 8 rows (Two-byte characters) Display section characters 12-dot standard font: 26 characters ×...
  • Page 109 Specifications Item GT2103-PMBD GT2103-PMBDS GT2103-PMBDS2 GT2103-PMBLS USB (Host) 1 channel (rear face) USB (Device) USB version: USB1.1 (Full-Speed 12 Mbps), Connector shape: USB Mini-B Built-in interface 1 channel, SDHC compliant (maximum 32 GB) SD card Extension interface Auxiliary extension interface Side interface Buzzer output Single tone (Tone length adjustable)

  • Page 110: Specifications Of Power Supply Section

    Specifications of Power Supply Section The following shows the power supply specifications of the GOT. POINT POINT POINT Operation at instantaneous power failure If an instantaneous power failure occurs in the power supply and continues for more than the permissible period, the GOT may be reset. Make sure to power on the unit more than 5 seconds after power-off.
  • Page 111 ■2. GT27 Input power supply 24 V DC Specifications GT2710-STBD Item GT2712-STBD GT2708-STBD GT2715-XTBD GT2710-VTBD GT2705-VTBD GT2712-STWD GT2708-VTBD GT2710-VTWD Power supply voltage 24 V DC (+25%, -20%) Under the maximum 48 W or less 45 W or less 42 W or less 39 W or less 30 W or less load...

  • Page 112: Gt2510-Wx, Gt2507-W

    3.3.2 GT2510-WX, GT2507-W ■1. GT25 Input power supply 24 V DC Specifications Item GT2510-WXTBD GT2507-WTBD GT2510-WXTSD GT2507-WTSD Power supply voltage 24 V DC (+25%, -20%) Under the maximum 16 W or less 16 W or less load Power Main unit 9 W or less 9 W or less consumption...

  • Page 113: Gt2507T-W

    3.3.3 GT2507T-W ■1. GT25 Input power supply 24 V DC Specifications Item GT2507T-WTSD Power supply voltage 24 V DC (+25%, -20%) Under the maximum 17 W or less load Power Main unit 11 W consumption Main unit (Backlight OFF) Inrush current 59 A or less (2 ms, ambient temperature: 25 °C, under the maximum load) Permissible instantaneous power 5 ms or less...

  • Page 114: Gt25-S, Gt25-V

    3.3.4 GT25-S, GT25-V ■1. GT25 Input power supply 100 V AC to 240 V AC Specifications GT2510-VTBA GT2508-VTBA Item GT2512-STBA GT2510-VTWA GT2508-VTWA GT2512F-STNA GT2510F-VTNA GT2508F-VTNA Power supply voltage 100 V AC to 240 V AC (+10%, -15%) Power supply frequency 50 Hz/60 Hz (±5%) Maximum apparent power 80 VA...

  • Page 115: Gt25Hs-V

    Specifications GT2510-VTBD GT2508-VTBD Item GT2512-STBD GT2510-VTWD GT2508-VTWD GT2505-VTBD GT2512F-STND GT2510F-VTND GT2508F-VTND Applicable tightening torque 0.5 N·m to 0.8 N·m (Terminal block terminal screw) 3.3.5 GT25HS-V ■1. GT25 Input power supply 24 V DC Specifications Item GT2506HS-VTBD GT2505HS-VTBD Power supply voltage 24 V DC (+10%, -15%) Under the maximum 11.6 W or less...

  • Page 116: Gt23

    3.3.6 GT23 ■1. GT23 Input power supply 100 V AC to 240 V AC Specifications Item GT2310-VTBA GT2308-VTBA Power supply voltage 100 V AC to 240 V AC (+10%, -15%) Power supply frequency 50 Hz/60 Hz (±5%) Maximum apparent power 44 VA (under the maximum load) 30 VA (under the maximum load) Under the maximum...

  • Page 117: Gt21

    3.3.7 GT21 ■1. GT21 Input power supply 24 V DC/5 V DC (1) For GT2107, GT2105 Specifications Item GT2107-WTBD, GT2107-WTSD GT2105-QTBDS GT2105-QMBDS Power supply voltage 24 V DC (+10%, -15%) Under the maximum 11.3 W or less 4.5 W or less 2.9 W or less Power load...

  • Page 118: Battery Specifications

    Battery Specifications ■1. Applicable battery The following batteries are applicable for GOT2000 series. Model name Description Target GOT GT11-50BAT Battery for backup of SRAM data, clock data, and system status log data GT27, GT25 , GT23, GT21 GT15-BAT Battery for backup of SRAM data, clock data, and system status log data GT2506HS-V GT2103-P does not have a built-in battery.
  • Page 119 (3) GT2507T-W Data backup time after detection of Operating ambient temperature Operating ambient temperature Operating ambient temperature of -20° to 25°C of 25° to 45°C of 45° to 65°C battery voltage low 3 years 4 years 3 years 14 days In the following conditions, the data backup time is 5 minutes after the power supply is turned off.
  • Page 120 3 - 60 3.4 Battery Specifications...

  • Page 121: Part Names And Settings

    4. PART NAMES AND SETTINGS GT27..........4 - 2 GT2510-WX, GT2507-W .
  • Page 122 GT27 ■1. GT2715-X 1)2) 3)4) 25) 24) 22) For the names of parts, refer to the following. ➠ ■6. Part names and settings of GT27 ■2. GT2712-S 1)2) 3)4) For the names of parts, refer to the following. ➠ ■6. Part names and settings of GT27 4 - 2 4.1 GT27...
  • Page 123 ■3. GT2710-S, GT2710-V 1)2) 3)4) For the names of parts, refer to the following. ➠ ■6. Part names and settings of GT27 ■4. GT2708-S, GT2708-V 1)2) 11)12)13) 3)4) 16) 26) For the names of parts, refer to the following. ➠ ■6.
  • Page 124 ■5. GT2705-V 1)2) 11)12)13) 3)4) 24) 22) 21) For the names of parts, refer to the following. ➠ ■6. Part names and settings of GT27 4 - 4 4.1 GT27...
  • Page 125 ■6. Part names and settings of GT27 Name Description Display section Displays the utility and the user-created screen. Touch panel For operating the touch switches in the utility and the user-created screen For connecting a USB mouse, a USB keyboard, or a USB barcode reader, and transferring or saving data (Connector shape: TYPE-A) USB interface (Host/front) Applicable models: GT2715-XTBA/D, GT2712-STBA/D, GT2710-STBA/D, GT2710-VTBA/D,...

  • Page 126: Gt2510-Wx, Gt2507-W

    GT2510-WX, GT2507-W ■1. GT2510-WX 11)12) 7) 13) 1)2) 21) 18) 19) 17) For the names of parts, refer to the following. ➠ ■3. Part names and settings of GT2510-WX and GT2507-W ■2. GT2507-W 1)2) 11)12) 18) 19) 17) For the names of parts, refer to the following. ➠...
  • Page 127 ■3. Part names and settings of GT2510-WX and GT2507-W Name Description Display section Displays the utility and the user-created screen. Touch panel For operating the touch switches in the utility and the user-created screen USB interface (Device/front) For connecting a personal computer (Connector shape: Mini-B) Lit in blue : Power is properly supplied.

  • Page 128: Gt2507T-W

    GT2507T-W ■1. GT2507T-W 1)2) 10)11) 6) 12) 18) 19) For the names of parts, refer to the following. ➠ ■2. Part names and settings of GT2507T-W 4 - 8 4.3 GT2507T-W...
  • Page 129 ■2. Part names and settings of GT2507T-W Name Description Display section Displays the utility and the user-created screen. Touch panel For operating the touch switches in the utility and the user-created screen Lit in blue : Power is properly supplied. Lit in orange : Screen saving Blinks in orange and blue: Backlight failure...

  • Page 130: Gt25-S, Gt25-V

    GT25-S, GT25-V ■1. GT2512-S 1)2) 3)4) For the names of parts, refer to the following. ➠ ■8. Part names and settings of GT25-S and GT25-V ■2. GT2512F-S 1)2) 11)12) The figure shows a GOT with the fittings installed on the top, bottom, right, and left. 24) 22) Install the fittings on the top and bottom, or the right and left of the GOT.
  • Page 131 ■3. GT2510-V 1)2) 3)4) For the names of parts, refer to the following. ➠ ■8. Part names and settings of GT25-S and GT25-V ■4. GT2510F-V 1)2) 11)12) 27)19) 24) 22) The figure shows a GOT with the fittings installed on the top, bottom, right, and left. Install the fittings on the top and bottom, or the right and left of the GOT.
  • Page 132 ■5. GT2508-V 1)2) 11)12)13) 3)4) 16) 26) For the names of parts, refer to the following. ➠ ■8. Part names and settings of GT25-S and GT25-V ■6. GT2508F-V 1)2) 11)12)13) The figure shows a GOT with the fittings installed on the top, bottom, right, and left. 24) 22) Install the fittings on the top and bottom, or the right and left of the GOT.
  • Page 133 ■7. GT2505-V 1) 2) For the names of parts, refer to the following. ➠ ■8. Part names and settings of GT25-S and GT25-V 4 - 13 4.4 GT25-S, GT25-V...
  • Page 134 ■8. Part names and settings of GT25-S and GT25-V Name Description Display section Displays the utility and the user-created screen. Touch panel For operating the touch switches in the utility and the user-created screen For connecting a USB mouse, a USB keyboard, or a USB barcode reader, and transferring or USB interface (Host/front) saving data (Connector shape: USB-A) Applicable models: GT2512-STBA/D, GT2510-VTBA/D, GT2508-VTBA/D...
  • Page 135 Name Description For enabling or disabling the access to the SD card when the SD card is inserted/removed to/ from the GOT SD card access switch ON: SD card access allowed (The SD card cannot be removed.) OFF: SD card access prohibited (The SD card can be removed.) The special fittings are sold separately.
  • Page 136 GT25HS-V ■1. GT2506HS-V (1) Front Panel 5） 1） 2） 4） 4） 3） 8） 6） 7） For the names of parts, refer to the following. ➠ ■3. Part names and settings of GT25HS-V (2) Back Panel Environmental protection back cover closed Environmental protection back cover opened 12）...

  • Page 137: Gt25Hs-V

    (3) Top Face (Interface) Interface environmental protection cover closed 24） 23） 25） Interface environmental protection cover opened 28） 27） 29） 26） LED1 LED2 30） 31） 32） 33） For the names of parts, refer to the following. ➠ ■3. Part names and settings of GT25HS-V 4 - 17 4.5 GT25HS-V...
  • Page 138 ■2. GT2505HS-V (1) Front Panel 27） 5） 1） 2） 6） 8） 3） For the names of parts, refer to the following. ➠ ■3. Part names and settings of GT25HS-V (2) Back Panel Environmental protection back cover closed Environmental protection back cover opened 12） 11） 13） 17） 10） 18） 16）...
  • Page 139 (3) Top Face (Interface) Interface environmental protection cover closed 26） 25） Interface environmental protection cover opened 35） 29） 28） LED2  LED1 34） 33） 32） For the names of parts, refer to the following. ➠ ■3. Part names and settings of GT25HS-V 4 - 19 4.5 GT25HS-V...
  • Page 140 ■3. Part names and settings of GT25HS-V Name Description Display section Displays the utility screen and the user creation screen. Touch panel For touch switch operation on the utility screen and the user creation screen. Operation switch (6 switches) Switch for external direct wiring (independent contact) Place (concave shape) where the operation switch name sheet (Insert into the space from a transverse direction) is installed.
  • Page 141 Name Description For switching the RS-422/485 communication interface terminating resistor (Set to Disable before shipping) Terminating resistor setting switch enlarged view Terminating resistor setting switch ON side Switch No. Terminating resistor Enable Disable OFF side Set to “Disable” before shipping Emergency stop switch guard cover For installing an emergency stop switch guard cover (option) installing hole...
  • Page 142 GT23 ■1. GT2310-V, GT2308-V Example) GT2310-VTBA 1)2) For the names of parts, refer to the following. ➠ ■2. Part names and settings of GT23 4 - 22 4.6 GT23...
  • Page 143 ■2. Part names and settings of GT23 Name Description Display section Displays the utility and the user-created screen. Touch panel For operating the touch switches in the utility and the user-created screen Lit in blue : Power is properly supplied. Lit in orange : Screen saving POWER LED...
  • Page 144 GT21 ■1. GT2107-WTBD, GT2107-WTSD 1)2) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 ■2. GT2105-QTBDS, GT2105-QMBDS 1)2) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 4 - 24 4.7 GT21...
  • Page 145 ■3. GT2104-RTBD 1)2) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 ■4. GT2104-PMBD 1)2) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 4 - 25 4.7 GT21...
  • Page 146 ■5. GT2104-PMBDS 1)2) 13) 15) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 ■6. GT2104-PMBDS2 1)2) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 ■7.
  • Page 147 ■8. GT2103-PMBD 1)2) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 ■9. GT2103-PMBDS 1)2) For the names of parts, refer to the following. ➠ ■12. Part names and settings of GT21 ■10.
  • Page 148 ■12. Part names and settings of GT21 Name Description Display section Displays the utility and the user-created screen Touch panel For operating the touch switches in the utility and the user-created screen For communicating with a controller or connecting a personal computer (Connector shape: Ethernet interface RJ-45 (Modular jack)) SD/RD LED ON: Data sent or received...

  • Page 149: Emc Directive And Low Voltage Directive

    5. EMC DIRECTIVE AND LOW VOLTAGE DIRECTIVE Overview ..........5 - 2 EMC Directive Requirements.

  • Page 150: Overview

    Directives and put a CE mark on the products. ■1. Sales representative in Europe The sales representative in Europe is as shown below. Company name: Mitsubishi Electric Europe BV Address: Mitsubishi-Electric-Platz 1, 40882 Ratingen, Germany 5.1.1 Conforming standards in the EMC Directive The GOT complies with the following standards in the EMC Directive.

  • Page 151: Conforming Standards In The Low Voltage Directive

    The GOT is an open type device (designed to be integrated in equipment). Make sure to install the GOT on a control panel. This test item is conducted in the condition where the GOT is installed on a control panel and combined with the MITSUBISHI ELECTRIC PLC.

  • Page 152: Emc Directive Requirements

    The data described herein are produced with our best, based on the regulation requirements and standards obtained by Mitsubishi Electric. However, the data do not guarantee that the whole equipment produced according to the data comply with the above directive.

  • Page 153: Installing A Noise Filter (Power Supply Line Filter)

    5.2.2 Installing a noise filter (power supply line filter) A noise filter is a part to effectively reduce conducted noise. Except some models, installation of a noise filter to the power supply lines is not necessary. However, installing the noise filter can reduce conducted noise.

  • Page 154: System Configuration

    5.2.3 System configuration You can also check the EMC Directive compliance status of the GOT2000 series at the Mitsubishi Electric Factory Automation Global Website. For the latest information, go to the Mitsubishi Electric Factory Automation Global Website. http://www.mitsubishielectric.co.jp/fa/ ■1. GOT Use the following GOTs having a CE mark on the rating plate.
  • Page 155 ➠ GOT2000 Series Connection Manual For GT Works3 Version1 compatible for a controller used When connecting the GOT to other controllers such as a non-Mitsubishi Electric PLC, fabricate connection cables and configure the system following the EMC Directive specifications. ➠...
  • Page 156 POINT Connected devices When connecting the GOT to a non-Mitsubishi Electric PLC, refer to the manual about the EMC Directive compliance of the connected device (such as a PLC and a microcomputer). The GT25HS-V is compliant with the EMC Directive only when it is connected via a connector conversion box using an applicable connection type mentioned above.
  • Page 157 Connection type Communication unit Hardware version (Manufacture year and month) GOT RS-232 interface GOT RS-422/485 interface Servo amplifier connection GT15-RS2-9P Version D or later (January 2006) GT15-RS4-9S GOT RS-232 interface GOT RS-422/485 interface GT15-RS2-9P Version D or later (January 2006) CNC connection GT15-RS4-9S GT15-J71LP23-25...
  • Page 158 (2) CC-Link IE Field Network connection Use the following cable dedicated to the CC-Link IE Field Network. Manufacturer Model Mitsubishi Electric System & Service Co., Ltd. SC-E5EW-S□M (3) External cable Use version C or later of GT11H-C□□-37P. (4) Other connections For the details of the cables used, refer to the following manual.

  • Page 159: Connection Of Power Cables And Ground Cables

    5.2.4 Connection of power cables and ground cables Carry out wiring and connect the power and ground cables according to the following instruction. By the different wiring or connection method, the system may not comply with EMC Directive. ■1. Wiring method As shown in the figure below, connect the power cable and the ground cable, and then attach a ferrite core (ZCAT3035-1330, manufactured by TDK Corporation) within the specified range.
  • Page 160 (3) 24 V DC power supply section (Handy GOT only) 1 turn 75 mm or less 5 - 12 5.2 EMC Directive Requirements...

  • Page 161: Fabricating A Connection Cable

    Fabricate the cables used for the GOT by the methods as shown in this section. The fabrication requires a ferrite core, cable clamp, and cable shielding materials. The following products have passed the Mitsubishi Electric EMC Directive compliance test. • ZCAT3035-1330 ferrite core (TDK Corporation) •...
  • Page 162 ■4. Bus connection (1) GT15-QC□B and GT15-QC□BS Strip off the sheath at both ends of the cable as shown in the figure below to expose braided shield sections for grounding. The braided shield sections are used for grounding with a cable clamp. ➠...
  • Page 163 ■5. MELSECNET/H connection (PLC to PLC network) connection (1) Coaxial cable Step 1. Strip off the sheath at both ends of the cable as shown in the figure below to expose outer braided shield for grounding. The braided shield sections are used for grounding with a cable clamp. ➠...
  • Page 164 ■7. CC-Link connection (Intelligent device station) Step 1. Strip off the sheath at both ends of the cable as shown in the figure below to expose braided shield for grounding. The braided shield sections are used for grounding with a cable clamp. ➠...
  • Page 165 ■9. Video/RGB connection (1) Video input cable Step 1. Strip off the sheath at both ends of the cable as shown in the figure below to expose outer braided shield for grounding. The braided shield sections are used for grounding with a cable clamp. ➠...
  • Page 166 ■10. Sound output device connection (GT25-W only) Install a ferrite core to the cable in the positions as shown in the figure below. Ferrite core (ZCAT3035-1330) GOT side Sound output device side 60 or less 100 or less (2.36) (3.94) Unit: mm (inch) 5 - 18 5.2 EMC Directive Requirements...
  • Page 167 ■11. Non-Mitsubishi Electric PLC, microcomputer, temperature controller, inverter, servo amplifier, CNC, MODBUS/RTU, and MODBUS/TCP connections Create the cables (RS-232 cable, RS-422/485 cable) for connecting the GOT and a controller by yourself. For how to create a cable, refer to the following.

  • Page 168: Grounding A Cable

    • Install a ferrite core to the cable in the positions as shown in the figure below. Ferrite core (ZCAT3035-1330) GOT side PLC CPU side 100 or less 100 or less Unit: mm (inch) (3.94) (3.94) 5.2.6 Grounding a cable ■1.

  • Page 169: Low Voltage Directive Requirements

    This section explains the precautions for the installation and wiring of the GOT to comply with the Low Voltage Directive. The data described herein are produced with our best, based on the regulation requirements and standards obtained by Mitsubishi Electric. However, the data do not guarantee that the equipment produced according to the data comply with the above directive.

  • Page 170: Grounding

    5.3.3 Grounding The GOT has the following ground terminals. The ground terminals must be grounded in use. Ground the GOT to ensure the safety and to comply with the EMC Directive. Functional grounding : The functional ground terminal improves noise resistance. 5.3.4 External wiring ■1.

  • Page 171: Installation And Removal

    6. INSTALLATION AND REMOVAL Installation Precautions ....... . 6 - 2 Panel Cut Dimensions .

  • Page 172: Installation Precautions

    Installation Precautions Install the GOT with consideration of the control panel inside dimensions and the installation prohibited area. Depending on the types of connection cables connected to the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. Panel Cut Dimensions 6.2.1 GT27...
  • Page 173 ■2. GT2712-S, GT2710-S, GT2710-V, GT2708-S, GT2708-V, GT2705-V Open an installation hole on the control panel with the dimensions as shown below. Horizontal Vertical Unit: mm (inch) Model Panel thickness 302(11.89) 228(8.98) GT2712-S (+2(0.08), 0(0)) (+2(0.08), 0(0)) 289(11.38) 200(7.87) GT2710-S, GT2710-V (+2(0.08), 0(0)) (+2(0.08), 0(0)) 10(0.39) or More...

  • Page 174: Gt2510-Wx, Gt2507-W

    6.2.2 GT2510-WX, GT2507-W ■1. GT2510-WX, GT2507-W Open an installation hole on the control panel with the dimensions as shown below. Horizontal Vertical Unit: mm (inch) Model Panel thickness 243.5(9.59) 185.5(7.30) GT2510-WX (+1(0.04), 0(0)) (+1(0.04), 0(0)) 1.6(0.06) to 4(0.16) 180.5(7.11) 133.5(5.26) GT2507-W (+1(0.04), 0(0)) (+1(0.04), 0(0))

  • Page 175: Gt2507T-W

    6.2.3 GT2507T-W ■1. GT2507T-W Open an installation hole on the control panel with the dimensions as shown below. Horizontal Vertical Unit: mm (inch) Model Panel thickness 197(7.76) 141(5.55) GT2507T-W 1.6(0.06) to 4(0.16) (+1(0.04), 0(0)) (+1(0.04), 0(0)) 6 - 5 6.2 Panel Cut Dimensions...

  • Page 176: Gt25-S, Gt25-V

    6.2.4 GT25-S, GT25-V ■1. GT2512-S, GT2510-V, GT2508-V, GT2505-V Open an installation hole on the control panel with the dimensions as shown below. Horizontal Vertical Unit: mm (inch) Model Panel thickness 302(11.89) 228(8.98) GT2512-S (+2(0.08), 0(0)) (+2(0.08), 0(0)) 289(11.38) 200(7.87) GT2510-V (+2(0.08), 0(0)) (+2(0.08), 0(0)) 10(0.39) or More...
  • Page 177 ■2. GT2512F-S, GT2510F-V, GT2508F-V Open an installation hole on the control panel with the dimensions as shown below. Horizontal Vertical Back of the control panel Back of the control panel Unit: mm (inch) Fitting installation Panel Model position thickness (on the GOT) Long side 28(1.10)

  • Page 178: Gt23

    6.2.5 GT23 Open an installation hole on the control panel with the dimensions as shown below. Horizontal Vertical Unit: mm (inch) Model Panel thickness 289(11.38) 200(7.87) GT2310 (+2(0.08), 0(0)) (+2(0.08), 0(0)) 10(0.39) or More 1.6(0.06) to 4(0.16) 227(8.94) 176(6.93) GT2308 (+2(0.08), 0(0)) (+2(0.08), 0(0)) The C dimension shows the measurements for installing fittings on the control panel.

  • Page 179: Stud

    Stud 6.3.1 Stud specifications Use the studs that satisfy the following specifications. Diameter Length 10 mm (0.39 inch) or more The studs on the control panel must have strength adequate to withstand a tightening torque of 0.9 N•m or more. Make sure that no foreign matter such as welding waste is at and around the bases of the studs.
  • Page 180 (2) Measurements for the horizontally-oriented GOT with fittings on its top and bottom Screen center panel opening Stud Back of the control panel Unit: mm (inch) Model 98(3.86)± 113(4.45)± 7.5(0.30)± 98(3.86)± 113(4.45)± 7.5(0.30)± 128.5(5.06)± 132.5(5.22)± GT2512F-S 0.15(0.01) 0.15(0.01) 0.15(0.01) 0.15(0.01) 0.15(0.01) 0.15(0.01) 0.15(0.01)
  • Page 181 (4) Measurements for the vertically-oriented GOT with fittings on its top and bottom panel opening Screen center Screen center Screen center Stud Back of the control panel Unit: mm (inch) Model 75.5(2.97)± 79.5(3.13)± 160(6.30)± 175(6.89)± 75.5(2.97)± 79.5(3.13)± GT2512F-S 0.15(0.01) 0.15(0.01) 0.15(0.01) 0.15(0.01) 0.15(0.01)

  • Page 182: Installation Position

    Installation Position To install the GOT, some distance is required between the GOT and the other devices. 6.4.1 GT27 Depending on the units and cables used for the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. For the cable pull-out distance from the bottom of the GOT, refer to the following.
  • Page 183 The following tables list the distance required between the GOT and the other devices. The dimensions within the parentheses apply when no equipment generating radiated noise (such as a contactor) or heat is installed near the GOT. However, always keep the ambient temperature of the GOT to 55 °C or lower. Unit: mm (inch) GT27 Item...

  • Page 184: Gt2510-Wx, Gt2507-W

    6.4.2 GT2510-WX, GT2507-W ■1. GT2510-WX, GT2507-W Depending on the units and cables used for the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. For the vertical installation, install the GOT so that the vertical installation arrow printed on the GOT rear face points upward.
  • Page 185 The following tables list the distance required between the GOT and the other devices. The dimensions within the parentheses apply when no equipment generating radiated noise (such as a contactor) or heat is installed near the GOT. However, always keep the ambient temperature of the GOT to 55 °C or lower. Unit: mm (inch) GT25 Item...

  • Page 186: Gt2507T-W

    6.4.3 GT2507T-W ■1. GT2507T-W Depending on the units and cables used for the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. For the vertical installation, install the GOT so that the vertical installation arrow printed on the GOT rear face points upward.
  • Page 187 The following tables list the distance required between the GOT and the other devices. The dimensions within the parentheses apply when no equipment generating radiated noise (such as a contactor) or heat is installed near the GOT. However, always keep the ambient temperature of the GOT to 55 °C or lower. Unit: mm (inch) GT25 Item...

  • Page 188: Gt25-S, Gt-25V

    6.4.4 GT25-S, GT25-V ■1. GT2512-S, GT2510-V, GT2508-V, GT2505-V Depending on the units and cables used for the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. For the cable pull-out distance from the bottom of the GOT, refer to the following.
  • Page 189 (2) For GT2505 Horizontal Panel thickness: 1.6 mm to 4 mm (0.06 to 0.16inch) Vertical Panel thickness: 1.6 mm to 4 mm (0.06 to 0.16inch) 6 - 19 6.4 Installation Position...
  • Page 190 The following tables list the distance required between the GOT and the other devices. The dimensions within the parentheses apply when no equipment generating radiated noise (such as a contactor) or heat is installed near the GOT. However, always keep the ambient temperature of the GOT to 55 °C or lower. Unit: mm (inch) GT25 Item...
  • Page 191 6 - 21 6.4 Installation Position...
  • Page 192 ■2. GT2512F-S, GT2510F-V, GT2508F-V Depending on the units and cables used for the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. For the cable pull-out distance from the bottom of the GOT, refer to the following. ➠...
  • Page 193 The following tables list the distance required between the GOT and the other devices. The dimensions within the parentheses apply when no equipment generating radiated noise (such as a contactor) or heat is installed near the GOT. However, always keep the ambient temperature of the GOT to 55 °C or lower. Unit: mm (inch) GT25 Item...

  • Page 194: Gt23

    6.4.5 GT23 Depending on the units and cables used for the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. For the cable pull-out distance from the bottom of the GOT, refer to the following. ➠...
  • Page 195 Unit: mm (inch) Item GT2310-V GT2308-V 48(1.89) or more [18(0.71) or more] Horizontal: 78(3.07) or more [18(0.71) or more] Vertical: 50(1.97) or more [20(0.79) or more] Horizontal: 50(1.97) or more [20(0.79) or more] Horizontal: 50(1.97) or more When the SD card is used Vertical: 80(3.15) or more [20(0.79) or more] Vertical: 80(3.15) or more [50(1.97) or more] When the SD card is not...

  • Page 196: Gt21

    6.4.6 GT21 Depending on the units and cables used for the GOT, the distance more than the described dimensions may be required. Install the GOT with consideration of the connector dimensions and the cable bend radius. For the cable pull-out distance from the bottom of the GOT, refer to the following. ➠...
  • Page 197 The following table lists the distance required between the GOT and the other devices. The dimensions within the parentheses apply when no equipment generating radiated noise (such as a contactor) or heat is installed near the GOT. Unit: mm (inch) GT21 Item GT2107, GT2105, GT2104-R, GT2104-P, GT2103-P...

  • Page 198: Control Panel Inside Temperature And Got Installation Angle

    Control Panel Inside Temperature and GOT Installation Angle 6.5.1 GT27 Install the GOT with its display section positioned as shown below. Using the GOT with the installation angle other than the following accelerates the deterioration of the GOT. ■1. GT27 When a multimedia unit (GT27-MMR-Z), MELSECNET/H communication unit (GT15-J71LP23-25, GT15-J71BR13), or CC-Link communication unit (GT15-J61BT13) is mounted, the operating ambient temperature must be 5°C lower than the maximum temperature described in Section 3.1 General Specifications.
  • Page 199 6.5.2 GT2510-WX, GT2507-W Install the GOT with its display section positioned as shown below. Using the GOT with the installation angle other than the following accelerates the deterioration of the GOT. ■1. GT2510-WX, GT2507-W (1) Installing the GOT horizontally When the GOT is installed at any angle from 60 ° to 105 °, the control panel inside temperature must be within 55 °C. When the GOT is installed at any angle outside the range from 60 °...
  • Page 200 6.5.3 GT2507T-W Install the GOT with its display section positioned as shown below. Using the GOT with the installation angle other than the following accelerates the deterioration of the GOT. ■1. GT2507T-W (1) Installing the GOT horizontally When the GOT is installed at any angle from 60 ° to 105 °, the control panel inside temperature must be within 65 °C. When the GOT is installed at any angle outside the range from 60 °...
  • Page 201 6.5.4 GT25-S, GT25-V Install the GOT with its display section positioned as shown below. Using the GOT with the installation angle other than the following accelerates the deterioration of the GOT. ■1. GT2512-S, GT2510-V, GT2508-V, GT2505-V When a multimedia unit (GT27-MMR-Z), MELSECNET/H communication unit (GT15-J71LP23-25, GT15-J71BR13), or CC-Link communication unit (GT15-J61BT13) is mounted, the operating ambient temperature must be 5°C lower than the maximum temperature described in Section 3.1 General Specifications.
  • Page 202 ■2. GT2512F-S, GT2510F-V, GT2508F-V When a multimedia unit (GT27-MMR-Z), MELSECNET/H communication unit (GT15-J71LP23-25, GT15-J71BR13), or CC-Link communication unit (GT15-J61BT13) is mounted, the operating ambient temperature must be 5°C lower than the maximum temperature described in Section 3.1 General Specifications. (1) Installing the GOT horizontally When the GOT is installed at any angle from 60 °...
  • Page 203 6.5.5 GT23 ■1. GT23 Regardless of the installation orientation, install the GT23 so that the following conditions are satisfied. When the GOT is installed at any angle from 60 ° to 105 °, the control panel inside temperature must be within 55 °C. When the GOT is installed at any angle outside the range from 60 °...

  • Page 204: Installing The Got

    Installing the GOT Install the GOT in the following procedure. For the panel cut dimensions for the GOT, refer to the following. ➠ 6.2 Panel Cut Dimensions 6.6.1 GT27, GT25, GT23 The following shows an installation example for the horizontal direction. For the vertical installation, install the GOT so that the vertical installation arrow printed on the GOT rear face points upward.

  • Page 205: Stud

    For GT27 except GT2715-X, GT25, and GT23 (4 fittings) Step 3. Remove the protective film from the GOT. ■2. GT2512F-S, GT2510F-V, GT2508F-V To fasten the fittings on the control panel, studs are neccessary. For the details of panel cutting dimensions and studs, refer to the following. ➠...
  • Page 206 Step 1. Install the supplied fittings on the top and bottom of the GOT with screws. Each fitting has two types of holes as shown below.Use the appropriate type of holes according to the control panel thickness. Hole A: for the control panel thickness 1.5 mm to 3.0 mm Hole B: for the control panel thickness 2.0 mm to 4.0 mm When installing the fittings on the GOT, you are recommended to put a cloth or others under the GOT to prevent the display section from being damaged.
  • Page 207 Step 3. Tighten nuts on the studs in the specified torque range (0.8 N•m to 0.9 N•m) with a wrench for M4 nuts. Loosen the screws in the slotted holes of the fittings, and adjust the positons of the screws to make the GOT display section and the control panel surface be in the same plane.
  • Page 208 Step 5. Mark the four corners of the stencil on the control panel with a pencil or others. Remove the stencil. panel Stencil Peeling off Marking Step 6. Remove the protective film from the GOT, and make sure that no dust or other substances adhere to the display section.
  • Page 209 Step 8. Peel off the remainder of the release paper, and attach the whole environmental protection sheet to the control panel. Make sure to attach the sheet from the attached part in step 7, and fit the sheet onto the control panel without leaving any air between them.
  • Page 210 ■3. GT2505-V For the vertical installation, check that the vertical installation arrow mark on the GOT rear face points upward. Step 1. Install a gasket to the gasket installation groove on the GOT rear face. Fit the thin side of the gasket in the gasket installation groove. Gasket Enlarged view Gasket...
  • Page 211 POINT POINT POINT Cautions for the GOT installation (1) Tightening torque of the mounting screws Tighten mounting screws within the specified torque range. Undertightening can cause the GOT to drop. In addition, waterproof effect or oilproof effect may not be obtained. Tightening the screw in the specified torque range or more may damage the GOT or distort the panel, causing wrinkles on the surface of the display section.

  • Page 212: Gt21

    6.6.2 GT21 The following shows an installation example for the horizontal direction. For the vertical installation, install the GOT so that the power supply terminal, which is located on the GOT rear face, is at the lower side. ➠ 4. PART NAMES AND SETTINGS ■1.
  • Page 213 Step 3. For GT2107 Insert the hook of an installation fitting (supplied) into the mounting hole of the GOT. Tighten the supplied screws within the specified torque range (0.36 N•m to 0.48 N•m) to fix the GOT. For GT2105 Insert the hook of an installation fitting (supplied) into the mounting hole of the GOT. Tighten the supplied screws within the specified torque range (0.3 N•m to 0.5 N•m) to fix the GOT.
  • Page 214 POINT POINT POINT Cautions for the GOT installation (1) Tightening torque of the mounting screws Tighten mounting screws within the specified torque range. Undertightening can cause the GOT to drop. In addition, waterproof effect or oilproof effect may not be obtained. Tightening the screw in the specified torque range or more may damage the GOT or distort the panel, causing wrinkles on the surface of the display section.

  • Page 215: Removing The Got

    Removing the GOT The following shows the procedure for removing the GOT. 6.7.1 GT27, GT25, GT23 ■1. GT27, GT2512-S, GT2510-WX, GT2510-V, GT2508-V, GT2507-W, GT2507T-W, GT2505-V, and GT23 Step 1. Remove the screws from the GOT. Remove the fittings from the GOT. For GT2715-X (8 fittings) For GT27 except GT2715-X, GT25, and GT23 (4 fittings) Step 2.
  • Page 216 ■2. GT2512F-S, GT2510F-V, GT2508F-V The following shows the procedure for removing GT2512F-S as an example. Step 1. Remove the nuts. Step 2. Remove the GOT from the panel opening. Stud panel opening Step 3. Remove the environmental protection sheet gradually. If the sheet is difficult to remove, warm the sheet with a dryer or others.
  • Page 217 Step 4. Remove the screws from the GOT. Remove the fittings from the GOT. You are recommended to put a cloth or others under the GOT to prevent the display section from being damaged. Fittings (Top: 1, bottom: 1) Screws (Top: 3, bottom: 3) Cloth 6 - 47 6.7 Removing the GOT...

  • Page 218: Gt21

    6.7.2 GT21 ■1. GT21 Step 1. For GT2107 Remove the installation fitting on the GOT. For GT2105 Remove the installation fitting on the GOT. Enlarged view Installation fitting Mounting screw For GT2104, GT2103 Remove the mounting screws of the installation fitting on the GOT in the following order 1) to 3). Remove the installation fitting on the GOT.
  • Page 219 Step 2. Remove the GOT from the panel opening. Installation hole 6 - 49 6.7 Removing the GOT...

  • Page 220: Handling The Handy Got

    Handling the Handy GOT 6.8.1 Holding the Handy GOT in hand When operating the Handy GOT with holding it in hand, put a hand under the hand strap on the back. The hand strap length is adjustable. When you carry or operate the Handy GOT, hold its body. Carrying or operating the Handy GOT while holding its cable may damage the unit or cable.

  • Page 221: Hanging On A Wall

    6.8.2 Hanging on a wall ■1. Hanging the Handy GOT on a wall using the hook When operating the Handy GOT with hanging on a wall, use the hook for hanging on a wall on the back. Hook for hanging on walls Hook for hanging on walls GT2506HS-V GT2505HS-V...

  • Page 222: Placing On A Desk Or A Floor

    6.8.3 Placing on a desk or a floor When placing the Handy GOT on a desk or floor, pay attention to the following. Example) GT2506HS-V The cable should be fixed. You are recommended to keep the GOT horizontal to the desk to prevent falling, and to fix the connection cable to the desk or others.

  • Page 223: Installing To/Removing From Panel

    6.8.4 Installing to/removing from panel ■1. Installing a connector conversion box (1) Configuration The following shows the configuration for using the GOT that is connected to the connector conversion box on a control panel or operation panel. Handy GOT Control panel or operation panel 2）...
  • Page 224 ■2. Installing a relay cable connector (GT2505HS-V only) (1) Configuration The following shows the configuration for using the GOT connected to the connector that is attached on a control panel or operation panel. Control panel or operation panel Handy GOT For panel cutting dimensions, refer to the following page. ...
  • Page 225 (2) Panel cutting dimensions when using a relay cable To install the relay cable connector to the panel, make holes in the panel with the following dimensions. 63.5 (2.5) 2-3.2±0.1 59.1 (2.33) or more The part in gray indicates cut portions. Unit: mm (inch) (Panel thickness: 0.8 to 1.3 (0.031 to 0.051)) 10 °...

  • Page 226: Installing And Removing The Extension Unit

    Installing and Removing the Extension Unit For installing and removing a single extension unit, refer to the user's manual included in each extension unit. POINT POINT POINT Installing the extension interface relay board Installing any of the following communication units to the GOT does not require the extension interface relay board to be installed.
  • Page 227 Mounting a unit on another unit For precautions on mounting multiple units in stages, refer to the following. ➠ GOT2000 Series Connection Manual (Mitsubishi Electric Products) For GT Works3 Version1 6 - 57 6.9 Installing and Removing the Extension Unit...

  • Page 228: Removing The Extension Unit

    6.9.2 Removing the extension unit Step 1. Make sure that the GOT power is off. Step 2. Remove the accessory stickers from the mounted extension unit. Step 3. Loosen the screws of the unit. Step 4. Remove the extension unit. Step 5.

  • Page 229: Installing The Battery

    6.10 Installing the Battery Install a battery to the GOT before the first startup. The following shows the procedure for installing a battery.(Described with the GOT rear face facing up.) POINT POINT POINT (1) Battery • GT27, GT25 GT27 and GT25 come with a battery in the battery holder. Before using GT27 and GT25, connect the battery connector to the GOT connector.
  • Page 230 Step 3. To replace the battery, remove the old battery, and then disconnect the connector. For information on how to remove the battery, refer to the following. ➠ 6.11 Removing the Battery Step 4. The GOT-side connector depends on whether the GOT has a battery extension cable. •...

  • Page 231: Installing The Battery To Gt2708, Gt2705, Or Gt2508

    6.10.2 Installing the battery to GT2708, GT2705, or GT2508 The following shows the battery installation procedure, taking GT2708 as an example. Step 1. Make sure that the GOT power is off. Step 2. Install the battery inside the SD card cover on the side of the GOT. Open the SD card cover as shown in the following figure.

  • Page 232: Installing The Battery To Gt2510-Wx, Gt2507-W, Or Gt2507T-W

    Step 6. Turn on the GOT. Step 7. Check that the battery condition is normal with the utility. For the details of the battery condition display, refer to the following. ➠ GOT2000 Series User's Manual (Utility) 6.10.3 Installing the battery to GT2510-WX, GT2507-W, or GT2507T-W The following shows the battery installation procedure, taking GT2510-WX as an example.

  • Page 233: Installing The Battery To Gt2506Hs-V

    Step 5. After installing the battery to the battery holder of the GOT, close the battery cover until it clicks. Battery cover Battery Connector Step 6. Turn on the GOT. Step 7. Check that the battery condition is normal with the utility. For the details of the battery condition display, refer to the following.

  • Page 234: Gt2505Hs-V

    Step 4. Attach the environmental protection back cover and tighten the screws within the specified torque range (0.36 N•m to 0.48 N•m). Environmental protection back cover screw Step 5. Turn on the GOT. Step 6. Check that the battery condition is normal with the utility. For the details of the battery condition display, refer to the following.
  • Page 235 Battery Connector for battery connection Insertion direction Battery Lead (Red) Lead (Black) Circuit board Step 5. Attach the environmental protection back cover and tighten the screws within the specified torque range (0.36 N•m to 0.48 N•m). Step 6. Turn on the GOT. Step 7.

  • Page 236: Installing The Battery To Gt2310 Or Gt2308

    6.10.6 Installing the battery to GT2310 or GT2308 The following shows the battery installation procedure, taking GT2310 as an example. Step 1. Make sure that the GOT power is off. Step 2. Install the battery to the GOT rear face. Open the battery cover as shown below.
  • Page 237 Step 4. Insert the battery connector to the GOT connector. Battery Battery cover Red cable Black cable Connector Step 5. After installing the battery to the battery holder of the GOT, close the battery cover until it clicks. Battery Battery cover Connector Step 6.

  • Page 238: Installing The Battery To Gt2505, Gt2107, Gt2105, Gt2104-R, Gt2104-P

    6.10.7 Installing the battery to GT2505, GT2107, GT2105, GT2104-R, GT2104-P The following shows the battery installation procedure, taking GT2505, GT2107, GT2105, GT2104-R, GT2104-P as an example. Step 1. Make sure that the GOT power is off. Step 2. Open the battery cover as shown below. Battery cover Battery cover Connector...
  • Page 239 Step 5. After installing the battery to the battery holder of the GOT, close the battery cover until it clicks. Battery cover Battery cover Connector Connector For GT2107 For GT2505 and GT2105 Battery cover Battery cover Battery Battery For GT2104-R For GT2104-P Step 6.

  • Page 240: Removing The Battery

    6.11 Removing the Battery The battery removal procedure differs depending on the GOT models. ➠ 6.11.1 Removing the battery from GT2715, GT2712, GT2710, GT2512, GT2510-V, or GT2510F 6.11.2 Removing the battery from GT2708, GT2705, GT2710 or GT2508 6.11.3 Removing the battery from GT2510-WX, GT2507-W, or GT2507T-W 6.11.4 Removing the battery from GT2506HS-V 6.11.6 Removing the battery from GT2310 or GT2308 6.11.7 Removing the battery from GT2505, GT2107, GT2105, GT2104-R, GT2104-P...
  • Page 241 The GT25 models have no battery extension cable regardless of the hardware version. For how to check the hardware version, refer to the following. ➠ 13.8 Confirming of Versions and Conforming Standards Step 4. Push and close the battery cover until it clicks. Battery cover 6.11.2 Removing the battery from GT2708, GT2705, GT2710 or GT2508...

  • Page 242: Removing The Battery From Gt2510-Wx, Gt2507-W, Or Gt2507T-W

    Step 4. Close the SD card cover until it clicks. SD card cover 6.11.3 Removing the battery from GT2510-WX, GT2507-W, or GT2507T-W The following shows the battery removal procedure, taking GT2510-WX as an example. Step 1. Make sure that the GOT power is off. Step 2.

  • Page 243: Removing The Battery From Gt2506Hs-V

    Step 4. Push and close the battery cover until it clicks. Battery cover 6.11.4 Removing the battery from GT2506HS-V The following shows the battery removal procedure. Step 1. Make sure that the GOT power is off. Step 2. Loosen the environmental protection back cover screws at two points on GOT rear face to remove the cover.

  • Page 244: Gt2505Hs-V

    6.11.5 GT2505HS-V The following shows the battery removal procedure. Step 1. Make sure that the GOT power is off. Step 2. Loosen the environmental protection back cover screws at four points on GOT rear face to remove the cover. Environmental protection back cover screw...

  • Page 245: Removing The Battery From Gt2310 Or Gt2308

    6.11.6 Removing the battery from GT2310 or GT2308 The following shows the battery removal procedure, taking GT2310 as an example. Step 1. Make sure that the GOT power is off. Step 2. The battery is stored in the GOT rear face. Open the battery cover as shown below.

  • Page 246: Removing The Battery From Gt2505, Gt2107, Gt2105, Gt2104-R, Gt2104-P

    Step 4. Push and close the battery cover until it clicks. Battery cover 6.11.7 Removing the battery from GT2505, GT2107, GT2105, GT2104-R, GT2104-P The following shows the battery removal procedure, taking GT2505, GT2107, GT2105, GT2104-R, GT2104-P as an example. Step 1. Make sure that the GOT power is off.
  • Page 247 Step 3. After removing the battery from the battery holder of the GOT, unplug the connector. Battery cover Battery cover Connector Connector Battery Battery For GT2107 For GT2505 and GT2105 Battery Connector Connector Battery For GT2104-R For GT2104-P Step 4. Push and close the battery cover until it clicks.

  • Page 248: Installing The Sd Card

    6.12 Installing the SD Card CAUTION Turning off the GOT while it accesses the SD card results in damage to the SD card and files. When using the GOT with an SD card inserted, check the following items. GT27, GT25, GT23(Except for GT2505, GT25HS-V) •...

  • Page 249: Gt27, Gt25, And Gt23

    6.12.1 GT27, GT25, and GT23 ■1. GT27, GT25 (except GT25-W and GT2505-V), and GT23 Step 1. Open the SD card cover as shown below. Step 2. After making sure that SD card access LED is off with SD card cover 90 degrees or more open, insert an SD card with its front side facing up.
  • Page 250 ■2. GT25-W Step 1. Open the SD card cover as shown below. Step 2. Open the SD card cover completely, and check that the SD card access LED is off. Then, hold an SD card with its front side facing up, and insert the card into the SD card interface. Open the SD card cover completely.
  • Page 251 ■3. GT2505-V Step 1. Turn off the SD card access switch, and check that the SD card access LED turns off. Step 2. Open the SD card cover. Insert an SD card into the SD card interface with its front side (label side) facing toward the GOT rear face. Front side of the SD card Step 3.

  • Page 252: Gt25Hs-V

    6.12.2 GT25HS-V The following shows the installation procedure, taking GT2506HS-V as an example. Step 1. Open the interface environmental protection cover in the arrow-pointing direction. Front Step 2. Turn off the SD card access switch, and check that the SD card access LED turns off. Interface environmental protection cover MEMORY...

  • Page 253: Gt21

    6.12.3 GT21 Before inserting or removing an SD card, turn off the GOT or select [Access inhibit] in the SD card access setting of the GOT. Step 1. Touch [Utility main menu] → [Data control] → [SD card access] → [Permissions], and select [Access inhibit]. ➠...

  • Page 254: Removing The Sd Card

    6.13 Removing the SD Card WARNING If the SD card mounted on drive A of the GOT is removed while the GOT is accessed, processing for the GOT might be interrupted about for 20 seconds. The GOT cannot be operated during this period. The functions that run in the background including a screen updating, alarm, logging, scripts, and others are also interrupted.

  • Page 255: Gt27, Gt25, And Gt23

    6.13.1 GT27, GT25, and GT23 ■1. GT27, GT25 (except GT25-W and GT2505-V), and GT23 Step 1. Open the SD card cover as shown below. Step 2. After making sure that SD card access LED is off with SD card cover 90 degrees or more open, push in the SD card to remove it.
  • Page 256 ■2. GT25-W Step 1. Open the SD card cover as shown below. Step 2. Open the SD card cover completely, and check that the SD card access LED is off. Then, push in the SD card to remove it. Open the SD card cover completely.
  • Page 257 ■3. GT2505-V Step 1. Turn off the SD card access switch, and check that the SD card access LED turns off. Step 2. Open the SD card cover. Eject the SD card. Step 3. Close the SD card cover. 6 - 87 6.13 Removing the SD Card...

  • Page 258: Gt25Hs-V

    6.13.2 GT25HS-V The following shows the installation procedure, taking GT2506HS-V as an example. Step 1. Open the interface environmental protection cover in the arrow-pointing direction. Front Step 2. Set the SD card access switch of the GOT to OFF, and check that the SD card access LED turns off. Interface environmental protection cover MEMORY...

  • Page 259: Gt21

    6.13.3 GT21 Before inserting or removing an SD card, turn off the GOT or select [Access inhibit] in the SD card access setting of the GOT. Step 1. Touch [[Utility main menu] → [Data control] → [SD card access] → [Permissions], and select [Access inhibit].

  • Page 260: Installing And Removing The Usb Devices (Gt27, Gt25, Gt23, Gt2107)

    6.14 Installing and Removing the USB Devices (GT27, GT25, GT23, GT2107) The following shows the procedure for installing and removing a USB device. POINT POINT POINT The following shows the procedure for installing and removing a USB device When connecting the devices to the USB interface (Host) using USB hub with the GOT power on, drive assignment of connected USB devices may be changed.To use the USB hub devices, turn on the GOT with the devices connected.
  • Page 261 ■2. For GT27, GT25, GT23, and GT2107 equipped with the USB interface (Host) on the rear face Step 1. Insert the USB interface to the USB interface (Host) as shown below. Make sure to insert the USB interface connector in the correct direction. Example)GT2510-WX Example)GT2107 6 - 91...

  • Page 262: Removing The Usb Devices

    6.14.2 Removing the USB devices ■1. For GT27 and GT25 equipped with the USB interface (Host) on the front face Step 1. Place the USB device in removable mode.For the setting method, refer to the following. ➠ GOT2000 Series User's Manual (Utility) Step 2.
  • Page 263 ■2. For GT27, GT25, GT23, and GT2107 equipped with the USB interface (Host) on the rear face Step 1. Place the USB device in removable mode.For the setting method, refer to the following. ➠ GOT2000 Series User's Manual (Utility) Step 2. Remove the USB interface from the USB interface (Host) as shown below.

  • Page 264: Installing And Removing The Usb Cable (Gt27, Gt25, Gt23, Gt2107)

    6.15 Installing and Removing the USB cable (GT27, GT25, GT23, GT2107) The following shows the procedure for installing and removing a USB cable to the USB interface on the GOT rear face. The locations of the USB interface (Host) and the USB interface (Device) vary by model. 6.15.1 Installing the USB cable Install the USB cable to the GOT in the following procedure.
  • Page 265 ■2. For GT2107 Step 1. Install the USB cable to a USB interface (Host/device) on the GOT rear face. Step 2. Insert a cable clamp to the mounting hole for a cable clamp shown in the following figure and push it until you hear a clicking sound.

  • Page 266: Removing The Usb Cable

    6.15.2 Removing the USB cable When removing the mounted cable clamp and USB cable, refer to the following procedure. (Cable clamp used in this example: RSG-130-V0, KITAGAWA INDUSTRIES CO.,LTD.) Step 1. Remove the cable clamp band Draw out the band while pushing up the tab of the cable clamp with a screwdriver or other tools. Band Driver Step 2.
  • Page 267 POINT POINT POINT The USB cable can be removed from the unit with the cable clamp. Remove the cable with holding both sides of the cable clamp (Arrow A in the figure). 6 - 97 6.15 Installing and Removing the USB cable (GT27, GT25, GT23, GT2107)

  • Page 268: Installing And Removing The Panel-Mounted Usb Port Extension

    6.16 Installing and Removing the Panel-Mounted USB Port Extension The panel-mounted USB port extension is a waterproof USB extension cable. The cable is used to route the USB interface (Host) or USB interface (Device) of the GOT rear face to the front side of the control panel.
  • Page 269 • Tighten the waterproof cap properly when the cable is not used. ■2. Precautions on installing the panel-mounted USB port extension • Run power lines, servo amplifier drive wires, and panel-mounted USB port extensions so that they do not cross each other.
  • Page 270 6 - 100 6.16 Installing and Removing the Panel-Mounted USB Port Extension...
  • Page 271 7. OPTION AND COMMUNICATION CABLE FOR HANDY GOT Connector Conversion Box ......7 - 2 Emergency Stop Switch Guard Cover .

  • Page 272: Connector Conversion Box

    Connector Conversion Box The Handy GOT can monitor a PLC CPU or other controllers through the connector conversion box. For the PLC CPU that can be monitored, refer to the following. ➠ GOT2000 Series Handy GOT Connection Manual For GT Works3 Version1 The connector conversion box supplies power to the power supply input terminal of the Handy GOT, and relays signals from the emergency stop switch of the GOT.
  • Page 273 Item Contact rating Specifications Each contact coordinates the emergency stop switch status of Pushed (open)/Return (close). When the external cable is not connected, contacts are always open regardless of the emergency stop switch status. Causing a short circuit of the ES□B terminal which is close to the ES□A terminal by a short pin (prepared by user) enables to set each contact in the close status even if the external cable is not connected.
  • Page 274 Name Specifications Hole for the screw installation Used for fixing on the board, etc. For M4 screw Connects the GT16H-CNB-42S, the 24VDC power supply of Handy GOT and the emergency stop Terminal block 1 switch (ES1 to 3) with M3 terminal screw and the cover. Connects the operation switch of the Handy GOT (SW1 to 6), the grip switch (DSW-1, 2) and the Terminal block 2 keylock switch (KSW-1, 2) with M3 terminal and the cover...
  • Page 275 ■4. Installation (GT16H-CNB-42S) The Connector Conversion Box can be installed on the panel face directly or on the DIN rail. (1) Mounting on the panel face (When setting the connector for Handy GOT connection and the power supply switch on the panel surface) Step 1.
  • Page 276 (2) Mounting on the panel face (When setting the connector for Handy GOT connection and the power supply switch on the panel surface) Step 1. Drill a mounting slot of the following size on the panel face. 43±0.2 (1.69±0.01) Drill 4- 5±0.5 (0.2±0.02) Panel cut area Unit: mm (inch) Step 2.
  • Page 277 (3) Installation on the DIN rail. Install the Connector Conversion Box on the DIN rail with using its DIN rail hook. Applicable DIN rail DIN46277 (width: 35mm) The clearance between screws for installing the DIN rail should be 150mm or less. DIN rail depth more than 10mm (0.4 "inch ) Step 1.
  • Page 278 ■5. Connector conversion adapter installation Installing the connector conversion adapter and the flange is required to connect the RS-485 unfastened cable with the connector conversion adapter. (1) Installation of the connector conversion adapter GT10-9PT5S (sold separately) and the flange (packed together with the Connector Conversion Box) Install to the adapter and the flange with two screws which are packed together with the connector conversion adapter.
  • Page 279 ■6. Wiring to the connector and the terminal block (1) Pin assignment and signal names The 42-pin connector of the external cable is converted to the PLC connection connector (D-sub 9pin, module jack) and the following terminal block. Terminal block 1 #4-40UNC (Inch screw thread) External device...
  • Page 280 Terminal block 1, 2 Terminal block 1 (Terminal block for power supply and emergency stop switch) Terminal block 2 (Terminal block for Handy GOT operation switches, grip switch, keylock switch) • Terminal block 1 GT16H-CNB-42S Terminal block 1 Application Terminal No. Signal name 24VDC+ 24VDC power supply "+"...
  • Page 281 GT16H-CNB-42S Terminal block 2 Application Terminal No. Signal name DSW1 DSW1 For Grip switch DSW2 DSW2 (2) Wiring to the terminal block Terminal screws are M3. Wire as described below. Do not tighten the terminal screws with a torque outside the specified range. Doing so can cause a failure or malfunction.
  • Page 282 ■7. ID recognition function When the Handy GOT is connected to a PLC CPU or other controllers by Ethernet, the GOT can acquire the ID number (set by the rotary switch) from the connector conversion box. ID number can be used as information for switching the station number. When the ID number is stored to the station No.
  • Page 283 (2) Handy GOT side settings Set the RS-232 communication interface of the Handy GOT. Set the Ethernet interface according to the connected equipment to be monitored. Step 1. For GT2506HS-V, set the selection connector to the RS-232 interface. For GT2505HS-V, set the selection connector to the Ethernet interface. Step 2.
  • Page 284 Step 4. Make the controller settings of the project data to be transferred to the handy GOT. • Controller setting Configure the settings to connect the GOT by Ethernet. Set all PLCs which the GOT may be connected to via Ethernet. In this example, [Net No.] is fixed to 1.
  • Page 285 • Station No. switching device setting Tick the check box of [Use Station No. Switching] to set the device specifying the station No. of the connected PLC. Here, an example when the GOT internal device GD500 is set is explained. Step 5.
  • Page 286 Click the [Add] button in the [Project] tab. In the [Trigger] tab, set [ON] for [Trigger Type] of Trigger 1. Set [GB40] for [Trigger Device]. • Operation setting Store the value set by the rotary switch to the station No. switching device (GD500). The station No.
  • Page 287 • In the [Select CH No.] dialog, select [MODBUS Master] to display the device setting dialog. • Input 3-00001 to Device. Select [Host] for Network. Click the [OK] button when settings are completed. 3-00001 is a fixed register to access to the rotary switch of the connector conversion box by the MODBUS communication.
  • Page 288 Step 6. Set the project data to use the station No. switching. Select [Screen] → [Screen Property] from the menu to display the [Screen Property] dialog. Tick the check box of [Switch Station No.] in the [Basic] tab. Perform this operation in all screens where the station No. is switched. Step 7.

  • Page 289: Connector Conversion Box (Gt16H-Cnb-37S)

    7.1.3 Connector conversion box (GT16H-CNB-37S) ■1. Specifications (1) General specifications Other specifications are the same as Handy GOT. Item Specifications Operating ambient temperature 0 °C to 55 °C Storage ambient temperature -20°C to 70°C Frequency Acceleration Half-amplitude Sweep Count When installing DIN Vibration resistance 5 Hz to 8.4 Hz 1.75 mm...
  • Page 290 ■2. Part name When the terminal block cover is open Weight: Approx. 0.2 kg (0.4 lb) Name Specification Connector for Handy GOT connection Connects the Handy GOT through an external cable. (D-Sub 37pin (Female)) Supplies the power to the Handy GOT. Power switch When this switch is set to ON, the power is supplied. Turn off this switch when attaching or removing the Handy GOT.
  • Page 291 ■3. External dimensions 82 (3.22) 37.5 (1.47) When the terminal block cover is open Unit: mm (inch)  7 - 21 7.1 Connector Conversion Box...
  • Page 292 ■4. Installing a connector conversion box (GT16H-CNB-37S) Install a connector conversion box on the panel directly or with a mounting bracket. (1) Installing a connector conversion box on the panel (the Handy GOT connector accessible through the panel opening) Step 1. Open installation holes on the panel with the dimensions shown below.
  • Page 293 (2) Installation with the mounting bracket Step 1. Open installation holes on the panel with the dimensions shown below. +0.5 +0.02 (0.16      ) Drill 3-Φ4  0  0 Unit: mm (inch) Step 2. Install the supplied mounting bracket on the connector conversion box. Tighten the screws within the specified torque range (0.49 N·m to 0.68 N·m). Overtightening the screws may cause damage.
  • Page 294 Step 3. Install the connector conversion box on the panel. Tighten the screws within the specified torque range (0.69 N·m to 0.88 N·m). Overtightening the screws may cause damage. Connector conversion box 3-Φ4.5(0.18) M4 screw and nut x 3 sets (prepared by user) 10(0.39) Mounting bracket 20(0.79) Unit: mm (inch) 7 - 24 7.1 Connector Conversion Box...
  • Page 295 ■5. Pin layout and signal names of the connector and terminal blocks The D-sub 37-pin connector of the external cable is converted to the following terminal blocks and the PLC connection connector (modular jack). Terminal block 2 (For emargency stop switch  and selector switch) Terminal block 1 (For power supply and  Handy GOT operation switch) M2.6 (Metric screw thread) External connection device communication connector...
  • Page 296 (1) Terminal block 1 and 2 GT16H-CNB-37S GT11H-C□□-37P Application Connector for the Handy GOT connection Terminal block D-Sub 37pin Signal name 36, 37 DC24V+ 24VDC power supply "+" Frame ground 18, 19 DC24V- 24VDC power supply "-" Not used Terminal block 1 For Operation switch SW-COM For Emergency stop switch...

  • Page 297: Connector Conversion Box (Gt11H-Cnb-37S)

    7.1.4 Connector conversion box (GT11H-CNB-37S) ■1. Specifications (1) General specifications Other specifications are the same as Handy GOT. Item Specifications Operating ambient temperature 0 °C to 55 °C Storage ambient temperature -20°C to 70°C Frequency Acceleration Half-amplitude Sweep Count When installing DIN Vibration resistance 5 Hz to 8.4 Hz 1.75 mm...
  • Page 298 ■2. Part name When the terminal block cover is open Terminal name: ES3 *1 Weight: Approx. 0.17kg (0.4 lb) Name Specification Connector for Handy GOT connection Connects the Handy GOT through an external cable. (D-Sub 37pin (Female)) Supplies the power to the Handy GOT. Power switch When this switch is set to ON, the power is supplied. Turn off this switch when attaching or removing the Handy GOT.
  • Page 299 ■3. External dimensions When the terminal block cover is open 82(3.22) 37.5(1.47) Unit: mm (inch) 7 - 29 7.1 Connector Conversion Box...
  • Page 300 ■4. Installing a connector conversion box (GT11H-CNB-37S) Install a connector conversion box on the panel directly or with a mounting bracket. (1) Installing a connector conversion box on the panel (the Handy GOT connector accessible through the panel opening) Step 1. Open installation holes on the panel with the dimensions shown below.
  • Page 301 (2) Installation with the mounting bracket Step 1. Open installation holes on the panel with the dimensions shown below. +0.5 +0.02 (0.16      ) Drill 3-Φ4  0  0 Unit: mm (inch) Step 2. Install the supplied mounting bracket on the connector conversion box. Tighten the screws within the specified torque range (0.49 N·m to 0.68 N·m). Overtightening the screws may cause damage.
  • Page 302 Step 3. Install the connector conversion box on the panel. Tighten the screws within the specified torque range (0.69 Nom to 0.88 Nom). Overtightening the screws may cause damage. Connector conversion box 3-Φ4.5(0.18) M4 screw and nut x 3 sets (prepared by user) 10(0.39) Mounting bracket 20(0.79) Unit: mm (inch) 7 - 32 7.1 Connector Conversion Box...
  • Page 303 ■5. Pin layout and signal names of the connector and terminal blocks The D-sub 37-pin connector of the external cable is converted to the following terminal blocks and the PLC connection connector (modular jack). Terminal name: ES3 *1 Terminal block 2 Terminal block 1 (For power supply and  (For emargency stop switch Handy GOT operation switch)  and selector switch)
  • Page 304 (2) RS-232 connector (D-sub, 9 pins, and male) for connecting to a PLC GT11H-C□□-37P GT11H-CNB-37S Connector for Handy GOT Application Connector for PLC RS-232 D-sub 37pin Signal name RXD(RD) Signal line for PLC communication TXD(SD) (For wiring, refer to the chapter DTR(ER) corresponding to the connected controller.) ➠...
  • Page 305 (3) Terminal block 1) , 2) GT11H-CNB-37S GT11H-C□□-37P Application Connector for Handy GOT Terminal block D-Sub 37pin Signal name 36, 37 DC24V+ 24VDC power supply "+" Frame ground 18, 19 DC24V- 24VDC power supply "-" Not used Terminal block 1) For Operation switch SW-COM For Emergency stop switch...

  • Page 306: Emergency Stop Switch Guard Cover

    Emergency Stop Switch Guard Cover The emergency stop SW guard cover is attached to prevent the emergency stop SW from being operated incorrectly. 7.2.1 Applicable emergency stop SW guard cover The following emergency stop SW guard cover is applicable for the Handy GOT. ○: Usable, -: Not usable Product name Model name...

  • Page 307: Wall-Mounting Attachment

    Wall-mounting Attachment The wall-mounting Attachment is available to fix the handy GOT on the wall, stand or panel. 7.3.1 Applicable wall-mounting attachment The following wall-mounting Attachment is applicable for Handy GOT. ○: Usable, -: Not usable Product name Model Contents GT2506HS-V GT2505HS-V Wall-mounting ...
  • Page 308 7 - 38 7.3 Wall-mounting Attachment...

  • Page 309: Attachment Of Handy Got

    7.3.3 Attachment of handy GOT The figure shows an image of attaching the handy GOT to the wall-hanging fixture. Post Post Panel surface Mounted image as viewed from the side 7 - 39 7.3 Wall-mounting Attachment...

  • Page 310: Overview Of Communication Cable

    Overview of Communication Cable The following communication cables are available. Connector  Conversion Box Handy GOT PLC  Controller External cable connection cable Relay cable External cable External cable • External cable: This cable connects Handy GOT and the Connector Conversion Box. This cable is required for using the Handy GOT. To use the external cables which include unfastened cables on one side (GT11H-C ), process the cables according to the application.
  • Page 311 ○: Usable, -: Not usable Name Model name Length GT2506HS-V GT2505HS-V Remark ○ GT16H-C30-42P ○ GT16H-C60-42P ○ GT16H-C100-42P Connector conversion connection side 42 pins ○ GT14H-C30-42P ○ GT14H-C60-42P ○ GT14H-C100-42P ○ GT16H-C30-37PE For connecting to a connector ○ External cable GT16H-C60-37PE conversion box (37 pins) ○...
  • Page 312 ■1. Selection of RS-232 connection and RS-422/485 connection(GT2506HS-V) GT2506HS-V can be connected to a controller with either of RS-232 or RS-422/485 connection. The selection of RS-232 connection and RS-422/485 connection is made using the cable connector for PLC communication in the environmental protection back cover. For the RS-232 connection, connect the cable connector for PLC communication to RS-232 connector.
  • Page 313 ■2. Selection of the RS-232 connection, RS-422 connection, or Ethernet connection GT2505HS-V can be connected to a controller in either of the RS-232 connection, RS-422 connection, or Ethernet connection. Select the RS-232 connection, RS-422 connection, or Ethernet connection by using the cable connector for the PLC communication in the environmental protection back cover.

  • Page 314: External Cable, Relay Cable

    External Cable, Relay Cable 7.5.1 Pin layout and signal names of the external cable ■1. GT11H-C□□□-37P, GT11H-C□□□ (Use C or later version.) GT11H-C□□□-37P GT11H-C□□□ Arrangement of color (color type) D-SUB 37pin (male) Untied wire (31-core type) ○/○ 1 ○/○1 Dot mark type Colored Dot mark color differently Insulation color ○/○2 (From the engagement face) Communication, power, External cable operation switch signal name GT11H-C□□□-37P GT11H-C□□□...
  • Page 315 Communication, power, External cable operation switch signal name GT11H-C□□□-37P GT11H-C□□□ Application RS-422 RS-232C Wire color D-SUB pin No. Core wire Wire diameter (color type) O/R (B) Core wire 2) AWG28 For Operation switch O/BK (B) N.C. Not used Core wire 4) AWG20 DC24V+ 24VDC power supply "+"...

  • Page 316: Pin Layout Of The Relay Cable

    7.5.2 Pin layout of the relay cable ■1. GT11H-C15R4-8P relay cable (Use C or later version.) This cable is usable for connecting the following controllers. • FX0 series • FX0S series • FX0N series • FX1S series • FX1N(C) series •...
  • Page 317 ■2. GT11H-C15R4-25P relay cable Use C or later version. This cable is usable for connecting the following controllers. • ACPU • QnACPU • FX1 series • FX2 series • FX2C series Ferrite core 1 Ferrite core 2 1500 (59.06) Label For power supply Connecting to For operation switches external cable To PLC D-Sub 25pin Ferrite core 3 For FG...
  • Page 318 ■3. GT11H-C15R2-6P relay cable (Use C or later version.) The cable is usable for connecting a QCPU. Ferrite core 1 Ferrite core 2 1500 (59.06) Label For power supply Connecting to For operation switches external cable To PLC MINI-DIN 6pin Ferrite core 3 For FG 500 (19.69) D-SUB 37pin Accessories female connector  Jack socket (panel face 2 for each  Nut mounting type) Unit: mm (inch) Connector for Q series connection Connector for external cable connection MINI-DIN 6pin, male...

  • Page 319: Connector Specifications

    7.5.3 Connector specifications ■1. Connector for GT11H-C□□□-37P The following connector is used as the connector for the relay cable of the external cable (GT11H-C□□□-37P). For the connector to be connected to GT11H-C□□□-37P and its cover, use products applicable to the GT11HC Connector model Connector type Manufacturer...
  • Page 320 ■2. Removal procedure of the external cable Step 1. Make sure that the GOT power is off. Step 2. Pull up the lock lever with inserting a flat-blade screwdriver into the release hole of the lock lever. Flat screwdriver Step 3. The external cable can be removed by pulling the whole plug connector while shifting the coupling of the plug connector to the cable side.
  • Page 321 ■5. Installation procedure of external cable (GT16H-CNB-42S) Step 1. Make sure that the GOT power is off. Step 2. Insert the connector adjusting the triangle marks of the main unit side connector and cable side connector. Step 3. After inserting the connector, push the lock lever. The connecters are locked after the lever is pushed into. ■6.
  • Page 322 Step 3. Hold the coupling and pull the connector toward the cable side to remove the cable. Coupling 7 - 52 7.5 External Cable, Relay Cable...

  • Page 323: Wirng Of Power Supply Section

    8. WIRNG OF POWER SUPPLY SECTION Wiring of External Power Supply ......8 - 3 Power Supply Wiring to the GOT ......8 - 4 Grounding .
  • Page 324 WARNING Be sure to shut off all phases of the external power supply used by the system before wiring. Failure to do so may result in an electric shock, product damage or malfunctions. When grounding the FG terminal and LG terminal of the GOT power supply section, note the following points.

  • Page 325: Wiring Of External Power Supply

    (3) Releasing noise to the ground (a) Make sure to connect the ground cable to the ground. (b) Use a short and thick cable to lower its ground resistance. (c) Ground the power system and the control system separately. Wiring of External Power Supply ■1.

  • Page 326: Power Supply Wiring To The Got

    Power Supply Wiring to the GOT The following shows the examples of wiring the power cable, ground cable and other cables to the GOT power supply terminal. GT27, GT25, GT23 For 100 V AC Fuse INPUT 100-240VAC For 24 V DC INPUT 24VDC For 24 V DC (GT2705, GT25-W)
  • Page 327 ■2. Precautions (GT2104-R, GT2104-P, GT2103-P) (1) Terminal processing of power cables Connect a stranded wire or a solid wire directly, or use a rod terminal with an insulation sleeve. Do not tighten the terminal screws in the specified torque range or more. Doing so can cause a failure or malfunction. When connecting a stranded wire or a solid wire directly Twist the end of the stranded wire to prevent the elemental wires from protruding.

  • Page 328: Grounding

    Grounding Each GOT has the following ground terminals. • GT27 (except GT2705-V), GT25 (except GT25-W), GT23: FG terminal and LG terminal • GT2705-V, GT25-W, GT21 : FG terminal 8.3.1 Grounding the GOT ■1. Grounding method Ground the GOT as shown below. (1) For GT27, GT25, GT23, GT2107, and GT2105-Q •...
  • Page 329 (2) Shared grounding (Good) Ground the system at one end. To prevent noise from entering the GOT, use a short and thick wire for grounding between the ground and the control panel to lower ground resistance. Power equipment (such as servo) Connection cable CN1A CN 1B CN2 CN3...

  • Page 330: Causes Of Wiring-Related Malfunction And Countermeasure Examples

    8.3.2 Causes of wiring-related malfunction and countermeasure examples Causes of a malfunction due to grounding of the GOT include potential difference caused by grounding and noise. The following measures may reduce potential difference and noise. ■1. Wiring of the ground cable and power line of the GOT When the ground cable and power line of the GOT are installed together, the GOT may malfunction due to noise.
  • Page 331 (2) Countermeasure example 2 If the noise from the control panel having the GOT adversely affects the GOT even after Countermeasure example 1 is taken, attach the ferrite core (KITAGAWA INDUSTRIES CO.,LTD. RFC-H13 or equivalent). When attaching a ferrite core, insert the cable through the ferrite core several times (approximately three times). When Countermeasure example 2-1 is difficult to be taken, such as the wiring is impossible, carry out wiring as shown in Countermeasure example 2-2.

  • Page 332: Wiring Inside And Outside The Control Panel

    Wiring Inside and Outside the Control Panel 8.4.1 Control panel inside wiring As shown in the following figure, power lines, including power cables and servo amplifier driving cables, and communication cables, including bus connection cables and network cables, must not be mixed. Mixing the power lines and communication cables may cause a malfunction due to noise.

  • Page 333: Attaching A Surge Suppressor To Control Equipment

    Attaching a Surge Suppressor to Control Equipment When the GOT fails to work properly, for example a communication error occurs, in synchronization with the ON/OFF status of the specific control equipment, including a molded case circuit breaker, electromagnetic contactor, relay, solenoid valve, and induction motor (hereinafter described as load), the GOT may be affected by surge noise.

  • Page 334: Grounding The Extension Unit

    Grounding the Extension Unit 8.6.1 Wiring of the FG cable of a bus connection cable This section explains wiring of FG cables when a GOT is connected to a PLC CPU with bus connection cables. POINT POINT POINT Cables connected to the PLC CPU Do not install the connection cable together with or close to the main circuit lines (high voltage, large current) or I/O signal lines.

  • Page 335: Handy Got Power Wiring And Switch Handling

    9. HANDY GOT POWER WIRING AND SWITCH HANDLING Internal Wiring Diagram of Handy GOT ....9 - 4 Power Wiring......... 9 - 6 Wiring inside and outside the panel .
  • Page 336 WARNING Make sure to attach the back cover to the Handy GOT before turning on the power and starting operation after the installation or wiring work. Not doing so may cause an electrical shock. Be sure to shut off all phases of the external power supply used by the system before wiring. Failure to do so may result in an electric shock, product damage or malfunctions.
  • Page 337 ■1. General preventive measures against noise There are two kinds of noises: Radiated noise that is transmitted into the air and Conductive noise that is directly transmitted along connected lines. Countermeasures must be taken considering both kinds of noises and referring to the following 3 points. (1) Protecting against noise •...

  • Page 338: Internal Wiring Diagram Of Handy Got

    Internal Wiring Diagram of Handy GOT 9.1.1 GT2506HS-V The following shows the internal wiring diagram of GT2506HS-V. Display unit DC24V+ Power supply Display LED DC24G Display circuit SW1 LED Display section SW2 LED SW-COM Touch panel SW3 LED Operation SW4 LED switch SW5 LED Control and...

  • Page 339: Gt2505Hs-V

    9.1.2 GT2505HS-V The following shows the internal wiring diagram of GT2505HS-V. DC24V+ Power supply Display unit DC24G Displa y circuit Display se ction SW-COM Touch panel Operation switch Control and communication Display LED circuit GRIP SW communi memory PC connection -cation ES-1 Emergency...

  • Page 340: Power Wiring

    Power Wiring 9.2.1 Power wiring and grounding GOT power is supplied from the external power. In addition, the following table shows the input power supply voltage and the consumed current. Specifications Item GT2506HS-VTBD GT2505HS-VTBD Input power supply voltage 24VDC(+10% -15%) Power consumption 11.6W or less (480mA/24VDC) 8.4W or less (350mA/24VDC)
  • Page 341 ■2. Pin layout Terminal No. Cable 24VDC+ 24VDC- 36,37 18,19 GT11H-C□□□-37P (Short-circuit inside of the (Short-circuit inside of the External cable connector) connector) GT11H-C□□□ Red, (core wire 4)) Black, (core wire 4)) Shield Relay cable 24+ (label) 24G (label) FG (label) Terminal block 1) Terminal block 1) Terminal block 1)

  • Page 342: The Cause Of Malfunctions Related Wiring/Remedy

    9.2.2 The cause of malfunctions related wiring/Remedy Grounding of the GOT may cause electric potential difference and noise interference, which may result in GOT malfunctions. These problems may be resolved by taking the following measures. ■1. Wiring path of the GOT's ground cable and power line Bundling the GOT's ground cable and power line together can cause interference noise, which may result in malfunctions.
  • Page 343 • When using the external cable Connection cable Ground cable from the panel that houses control equipment If electric potential difference between the ground points created by it causes malfunctions, lowering the voltage as shown in Remedy 1 below may solve the problem. Remedy 1 (Refer to the figures Remedy 1-1 and 1-4 below.) If the electric potential difference between the ground cable and the panel that houses the GOT is creating problems, connect the ground cable to the panel also.
  • Page 344 Remedy 2 (Refer to the figures Remedy 2-1 and 2-2 below.) Attach a ferrite core to the cable if noise from the GOT panel has adverse effects on the GOT when Remedy 1 is taken. Wind the wire around the ferrite core several times (approx. 3 times), if a ferrite core is used. •...

  • Page 345: Wiring Inside And Outside The Panel

    Wiring inside and outside the panel 9.3.1 Wiring inside Run power lines, servo amplifier drive wires, and communication cables so that they do not cross each other. Noise interference that is generated by cables that cross each other may cause malfunctions. Surge suppressors are an effective way to filter out surge noise that is generated from no fuse breakers (NFB), electromagnetic contactors (MC), relays (RA), solenoid valves, and induction motors.

  • Page 346: Attaching Surge Killers To Control Equipment

    9.3.3 Attaching surge killers to control equipment If communication errors happen in synch with the on/off signals from certain control equipment (referred to as "load" hereafter) such as no fuse breakers, electromagnetic contactors, relays, solenoid valves, and induction motors, surge noise interference is suspected.

  • Page 347: Switch Wiring

    Switch Wiring 9.4.1 Overview for switch Example) GT2506HS-V Operation switch display LED Grip switch display LED Name Abbreviations Specifications Operation switch (6 switches) SW1 to SW6 Switch for external direct wiring (independent contact) Emergency stop switch ES-1, ES-2, ES-3 Switch for external direct wiring (independent contact) Grip switch DSW-1, DSW-2 Switch for external direct wiring (independent contact)

  • Page 348: Switch Wiring Example

    9.4.2 Switch wiring example ■1. When connecting general load (1) Connector conversion box GT16H-CNB-42S Connector Handy GOT conversion box Terminal External block 2 cable SW-COM KSW-C KSW-1 KSW-2 DSW-1 DSW-1 DSW-2 Terminal DSW-2 block 1 ES-1 ES1A ES1B ES1B Internal contact*1 ES-2 ES2A ES2B...
  • Page 349 (2) Connector conversion box GT11H-CNB-37S or GT16H-CNB-37S Connector Handy GOT conversion box External cable SW-COM Terminal block 2 KSW-C KSW-1 KSW-2 DSW-1 DSW-1 DSW-2 DSW-2 9 - 15 9.4 Switch Wiring...
  • Page 350 ■2. When connecting PLC input (1) Connector conversion box GT16H-CNB-42S Connector Handy GOT conversion box Terminal External block 2 (Example of FX series) cable SW-COM X000 X001 X002 X003 X004 X005 KSW-C X010 KSW-1 X011 KSW-2 X020 DSW-1 DSW-1 DSW-2 To the external load DSW-2 Terminal...
  • Page 351 (2) Connector conversion box GT11H-CNB-37S or GT16H-CNB-37S Connector Handy GOT conversion box External Terminal block 1 cable (Example of FX series) SW-COM X000 X001 X002 X003 X004 X005 Terminal block 2 KSW-C X010 KSW-1 X011 KSW-2 X020 DSW-1 DSW-1 DSW-2 To the external load DSW-2 9 - 17 9.4 Switch Wiring...

  • Page 352: Operation Switch Wiring

    9.4.3 Operation switch wiring The operation switch is connected to the PLC through an external cable and the Connector Conversion Box. ■1. Connection example (1) Connector conversion box GT16H-CNB-42S Connector Handy GOT conversion box Terminal block 2 SW-COM (2) Connector conversion box GT11H-CNB-37S or GT16H-CNB-37S Connector Handy GOT conversion box...

  • Page 353: Led Setting Of Operation Switch (Gt2506Hs-V)

    9.4.5 LED setting of operation switch (GT2506HS-V) For operation check, the green LED is attached to the six operation switches (SW1 to SW6). Each LED is related to the bit 0 to bit 5 of the word device. The LED is lit when the bit value is 1, and not lit when it is 0. ■1.
  • Page 354 Step 7. Once the settings are configured, click the [OK] button to close the [Environmental Setting] window. ■3. Program example The following shows a sequence program example. • System information: Set the read device to D101 (using the drawing software) •...

  • Page 355: Operation Switch Name Sheet Creation (Gt2506Hs-V)

    9.4.6 Operation switch name sheet creation (GT2506HS-V) This section describes the operation switch name sheet creation. ■1. Creating the name sheet Step 1. Prepare the name sheet board and OHP sheet (clear and colorless) included with the Handy GOT. Step 2. Write a original switch name for the user on the name sheet board.

  • Page 356: Emergency Stop Switch Wiring

    9.4.7 Emergency stop switch wiring The emergency stop switch is connected to the PLC with an external cable and the Connector Conversion Box. • Use the emergency stop switch signal as control signals of external device power ON/OFF. Do not use it as the input signal of external device. When turning ON/OFF the external device power, set the load up to 24VDC/1A (contact specification).
  • Page 357 (2) When avoiding to set the Connector Conversion Box to the emergency stop state while Handy GOT is removed Connector conversion box Handy GOT Terminal block 1 Used as control signals of external ES-1 ES1A device power ON/OFF ES1B Internal contact ES-2 ES2A ES2B...
  • Page 358 (2) When avoiding to set the Connector conversion box not to the emergency stop state while Handy GOT is removed Connector  Terminal Handy GOT conversion box block 2 Used as control signals of external device power ON/OFF Parallel circuit ■3. Pin layout Terminal No. Product name Model ES2A or ES- ES3A or ES- ES1A or ES1 ES1B...

  • Page 359: Grip Switch

    9.4.8 Grip switch The grip switch is on the side surface of the Handy GOT and wired to the input of PLC, etc. Grip switch Grip switch GT2506HS-V GT2505HS-V The grip switch is the 3-position system switch and makes the ON/OFF state of Handy GOT as shown below. Side surface of grip switch When released When half-pressed...
  • Page 360 (2) When using the connector conversion box (GT11H-CNB-37S or GT16H-CNB-37S) Connector  Handy GOT conversion box Terminal block 2 Used as input signals of PLC DSW-1 Used as control DSW-2 signals of external device power ON/OFF Set the load up to 24VDC/1A (contact specification) for each contact. ■2. Pin layout Terminal No. Model name DSW-1 DSW-1 DSW-2...

  • Page 361: Led Settings Of Grip Switch

    9.4.10 LED settings of grip switch Grip switches (DSW1, DSW2) contain green LED for checking operation. The grip switch LED coordinates with b6 of the external input and output function/output information (read device +1) and operates the LED ON/OFF display. ■1.
  • Page 362 (2) When using the connector conversion box (GT11H-CNB-37S or GT16H-CNB-37S) Connector conversion box Terminal Handy GOT block 2 KSW-C KSW-1 KSW-2 ■2. Pin layout Terminal No. Model name KSW-C KSW-1 KSW-2 Terminal block 2 Terminal block 2 Terminal block 2 GT16H-CNB-42S Connector Conversion GT11H-CNB-37S...

  • Page 363: Operating The Got

    10. OPERATING THE GOT 10.1 Outline Procedure to Start the GOT ..... 10 - 2 10.2 Creating Project Data ....... . . 10 - 4 10 - 1...

  • Page 364: Outline Procedure To Start The Got

    10.1 Outline Procedure to Start the GOT This section explains the outline procedure to operate the GOT. Start Preparing project data Installing an extension unit and option Installing the GOT, and power supply wiring Writing package data Connecting the GOT and the controller Starting monitoring ■1.
  • Page 365 ■4. Writing package data Write package data with GT Designer3 Version1. The writing procedure differs depending on the data writing method. POINT POINT POINT Terms (1) Basic software The basic software is equivalent to an operating system of the GOT. A GOT in which no basic software is written cannot be started.

  • Page 366: Creating Project Data

    Step 4. Turn on the GOT. To start the GOT with the built-in flash memory (Drive C), write the package data to the built-in flash memory (Drive C) of the GOT. For how to write the package data, refer to the following. ➠...

  • Page 367: Maintenance And Inspection

    11. MAINTENANCE AND INSPECTION 11.1 Daily Inspection ........11 - 3 11.2 Periodic Inspection.
  • Page 368 WARNING When power is on, do not touch the terminals. Doing so can cause an electric shock or malfunction. Correctly connect the battery connector. Do not charge, disassemble, heat, short-circuit, solder, or throw the battery into the fire. Doing so will cause the battery to produce heat, explode, or ignite, resulting in injury and fire. Before starting cleaning or terminal screw retightening, always switch off the power externally in all phases.

  • Page 369: Daily Inspection

    However, the battery and liquid crystal display have limited life. The periodical replacement of the battery is recommended. For replacing the liquid crystal display, consult Mitsubishi Electric System & Service Co., Ltd. For the battery and the liquid crystal display, refer to the following.

  • Page 370: Periodic Inspection

    11.2 Periodic Inspection ■1. Half-yearly or yearly inspection items Inspect the following items when moving or modifying equipment, or changing wiring. Item Inspection item Inspection method Criterion Corrective action Display section 0 °C to 40 °C Ambient temperature For use in a control panel, the Other sections Surrounding Measure corrosive gas with a...

  • Page 371: Screen Cleaning Method

    11.3 Screen Cleaning Method Use the GOT always in a clean condition. To clean the GOT, wipe the dirty part with a soft cloth using neutral detergent or ethanol. Clean POINT POINT POINT Precautions for screen cleaning Do not use solvents such as acetone, benzene, toluene, and alcohol. Solvents may deform the protective sheet or peel the dissolvable paint on the surface.

  • Page 372: Low-Voltage Battery Detection And Battery Replacement

    11.4 Low-voltage Battery Detection and Battery Replacement ■1. Low-voltage battery detection and battery replacement The battery is used to hold the SRAM data, clock data, and backup data of the system status log data. The periodical replacement of the battery is recommended. For the battery replacement procedure, refer to the following.
  • Page 373 ■2. Handling of batteries and devices with built-in batteries in EU member states This section explains the precautions for disposing of waste batteries in EU member states and for exporting batteries and devices with built-in batteries to EU member states. (1) Precautions for disposal EU member states have a separate collection system for waste batteries.
  • Page 374 11 - 8 11.4 Low-voltage Battery Detection and Battery Replacement...

  • Page 375: Troubleshooting

    12. TROUBLESHOOTING 12.1 GOT Restoration Sheets ......12 - 2 12.2 Troubleshooting for the Bus Connection.

  • Page 376: Got Restoration Sheets

    If a malfunction or others still occurs even after the above checks, fill out the system configuration check sheet with details about your system, and consult your local Mitsubishi Electric System & Service Co., Ltd. When sending a faulty product, attach the GOT restoration sheets (GOT status check sheet, GOT installation status check sheet, and the system configuration check sheet) checked in this section.
  • Page 377 (4) Check of the screen display Check Symptom Cause/status Corrective action Perform the following in order. 1) Write the package data again. The screen is completely 2) Install the basic software again. □ The LCD or basic software may be faulty. black.
  • Page 378 (3) Check of the objects that are not displayed on the monitor screen Check Symptom Cause/status Corrective action □ Found • Details: Proceed to ■3. PLC status. □ Not found Example: The numerical display object is not displayed. ■3. PLC status (1) PLC failure Check Symptom...
  • Page 379 CC-Link connection (intelligent device station). ■5. Faulty product investigation If you cannot restore the GOT, consult your local Mitsubishi Electric System & Service Co., Ltd. Depending on the problem details, we may ask you to send the faulty product to us.

  • Page 380: Got Installation Status Check Sheet

    12.1.2 GOT installation status check sheet Check the current installation status of your GOT as shown in ■1. to ■7. According to the status of the GOT found after a check, take measures described below if necessary. If the measure is taken, mark the effect, "Effective" or "Ineffective". Each GOT has the following ground terminals.
  • Page 381 Separating the communication cable from the power line or using a separator (made of metal) in the duct, as shown below, reduces the influence of noise. Power Wiring duct Separator line □ Effective 100 mm or more □ Ineffective Signal Power Communication wire...
  • Page 382 (2) Measure for the equipment without a surge suppressor Attaching a surge suppressor close to the load reduces the influence of surge on the GOT. Output □ Effective □ Ineffective The surge suppressor must be attached close to the load. ■5.
  • Page 383 ■6. Grounding status of the control panel having the GOT (1) Current status Check if a single ground cable is led from the control panel having the control equipment such as a PLC to the control panel having the GOT. Connection cable Ground cable led from...
  • Page 384 Measure 2 By attaching a ferrite core (KITAGAWA INDUSTRIES CO.,LTD. RFC-H13 or equivalent) to the ground cable connected to the control panel having the GOT as shown in Figure C, the influence of noise is reduced. If wiring as shown in Figure C is unavailable, perform wiring as shown in Figure D. Figure C Connection cable...

  • Page 385: System Configuration Check Sheet

    12.1.3 System configuration check sheet Fill in the following table with the details of the system configuration, such as the GOT type and unit model. ■1. System configuration for the GOT System configuration Item Usage Model GOT (Example: GT2710-STBA) Communication unit Used, Not used Communication interface GOT built-in interface...

  • Page 386: Troubleshooting For The Bus Connection

    12.2 Troubleshooting for the Bus Connection If an error occurs in the bus connection between the GOT and the PLC CPU and the cause is not clear with the system alarm, perform the troubleshooting described in this section. For the details of the system alarm, refer to the following. ➠...

  • Page 387: Narrowing The Possible Error Positions

    12.2.2 Narrowing the possible error positions If the system cannot be restored even though the module with an error is replaced, another module may cause the error. Disconnect the extension cables and bus connection cables in order, starting from the module at the end of the system, and check for the error.

  • Page 388: Specific Example Of Troubleshooting

    12.2.3 Specific example of troubleshooting With the following system as an example, this section shows a troubleshooting when an error occurs in the PLC CPU. (When QnASCPU and an extension base unit are used) (main base unit) GOT 1) GOT 2) Extension cable (extension base unit)

  • Page 389: Error Messages And System Alarms

    12.3 Error Messages and System Alarms This section explains the error messages and system alarms displayed on the GOT. The system alarm function displays the error code and error message when an error occurs in the GOT, controller, or network. For the details of the system alarm, refer to the following.
  • Page 390 Error code of the following controllers Manual of the controller connected to the Controller GS263 FXCPU 100 to 299 Non-Mitsubishi Electric PLC Deal with errors according to the error Temperature controller (OMRON messages. temperature controller only) Error code of the GOT main unit...

  • Page 391: Error Messages And System Alarms

    For error handling, refer to the manual of the motion controller. The GOT displays the error code corresponding to an error occurring in the multiple CPU system. Check the error details with the CNC monitor. For error handling, refer to the manual of the CNC. The GOT displays the error code corresponding to an error occurring in a robot controller in the multiple CPU system or a stand- alone robot controller.
  • Page 392 12 - 18 12.3 Error Messages and System Alarms...

  • Page 393: Appendices

    13. APPENDICES 13.1 External Dimension Diagrams......13 - 2 13.2 Depth Dimensions and Cable Bend Radius for GT27 with an Extension Unit.

  • Page 394: External Dimension Diagrams

    13.1 External Dimension Diagrams 13.1.1 GT27 ■1. GT2715-X 322(12.68) 322(12.68) 397(15.63) 10(0.39) 10(0.39) 382(15.04) Unit: mm (inch) 13 - 2 13.1 External Dimension Diagrams...
  • Page 395 ■2. GT2712-S 241 (9.49) 241 (9.49) 316 (12.44) 301 (11.85) Unit: mm (inch) 13 - 3 13.1 External Dimension Diagrams...
  • Page 396 ■3. GT2710-S, GT2710-V 208 (8.19) 228 (8.98) 303 (11.93) 288 (11.34) Unit: mm (inch) 13 - 4 13.1 External Dimension Diagrams...
  • Page 397 ■4. GT2708-S, GT2708-V 37.5 166 (6.54) (1.48) 171.6 (6.76) 37.5 (1.48) 241 (9.49) 226 (8.90) Unit: mm (inch) 13 - 5 13.1 External Dimension Diagrams...
  • Page 398 ■5. GT2705-V 117(4.61) 89(3.50) 167(6.57) 152(5.98) Unit: mm (inch) 13 - 6 13.1 External Dimension Diagrams...

  • Page 399: Gt2510-Wx, Gt2507-W

    13.1.2 GT2510-WX, GT2507-W ■1. GT2510-WX 24.5 203(7.99) (0.96) 24.5 203(7.99) (0.96) 252(9.92) 243(9.57) Unit: mm (inch) 13 - 7 13.1 External Dimension Diagrams...
  • Page 400 ■2. GT2507-W 145(5.71) 142(5.59) 189(7.44) 180(7.09) Unit: mm (inch) 13 - 8 13.1 External Dimension Diagrams...

  • Page 401: Gt2507T-W

    13.1.3 GT2507T-W ■1. GT2507T-W 148(5.83) 33(1.3) 33(1.3) 148(5.83) 214(8.43) 196(7.72) Unit: mm (inch) 13 - 9 13.1 External Dimension Diagrams...

  • Page 402: Gt25-S, Gt25-V

    13.1.4 GT25-S, GT25-V ■1. GT2512-S 241 (9.49) 241 (9.49) 316 (12.44) 301 (11.85) Unit: mm (inch) 13 - 10 13.1 External Dimension Diagrams...
  • Page 403 ■2. GT2512F-S 347(13.66) 54(2.13) 311(12.24) 301(11.85) Unit: mm (inch) The values indicate the dimensions when all the fittings are installed to the GOT. Install the fittings on the top and bottom, or the right and left of the GOT. 13 - 11 13.1 External Dimension Diagrams...
  • Page 404 ■3. GT2510-V 208 (8.19) 228 (8.98) 303 (11.93) 288 (11.34) Unit: mm (inch) 13 - 12 13.1 External Dimension Diagrams...
  • Page 405 ■4. GT2510F-V 334(13.15) 54(2.13) 298(11.73) 288(11.34) Unit: mm (inch) The values indicate the dimensions when all the fittings are installed to the GOT. Install the fittings on the top and bottom, or the right and left of the GOT. 13 - 13 13.1 External Dimension Diagrams...
  • Page 406 ■5. GT2508-V 37.5 166 (6.54) (1.48) 37.5 171.6 (6.76) (1.48) 241 (9.49) 226 (8.90) Unit: mm (inch) 13 - 14 13.1 External Dimension Diagrams...
  • Page 407 ■6. GT2508F-V 272(10.71) 54(2.13) 236(9.29) 226(8.90) Unit: mm (inch) The values indicate the dimensions when all the fittings are installed to the GOT. Install the fittings on the top and bottom, or the right and left of the GOT. 13 - 15 13.1 External Dimension Diagrams...
  • Page 408 ■7. GT2505-V 164(6.46) 122(4.80) 22(0.87) 122(4.80) 22(0.87) 152(5.98) Unit: mm (inch) 13 - 16 13.1 External Dimension Diagrams...

  • Page 409: Gt25Hs-V

    13.1.5 GT25HS-V ■1. GT2506HS-V 201(7.91) 21(0.83) 50(1.97) 47(1.85) Unit: mm (inch) 13 - 17 13.1 External Dimension Diagrams...
  • Page 410 ■2. GT2505HS-V 145 (5.71) 20.5 33.8 45.5 (1.79) (0.81) (1.33) Unit: mm (inch) 13 - 18 13.1 External Dimension Diagrams...

  • Page 411: Gt23

    13.1.6 GT23 ■1. GT2310-V 208 (8.19) 228 (8.98) 303 (11.93) 288 (11.34) Unit: mm (inch) 13 - 19 13.1 External Dimension Diagrams...
  • Page 412 ■2. GT2308-V 166 (6.54) 166 (6.54) 241 (9.49) 226 (8.90) Unit: mm (inch) 13 - 20 13.1 External Dimension Diagrams...

  • Page 413: Gt21

    13.1.7 GT21 ■1. GT2107-WTBD, GT2107-WTSD (0.87) 145 (5.71) 142 (5.59) 23.5 (0.93) 189 (7.44) 180 (7.09) Unit: mm (inch) 13 - 21 13.1 External Dimension Diagrams...
  • Page 414 ■2. GT2105-QTBDS, GT2105-QMBDS (0.63) 122 (4.80) 122 (4.80) (0.63) 164 (6.46) 152 (5.98) Unit: mm (inch) 13 - 22 13.1 External Dimension Diagrams...
  • Page 415 ■3. GT2104-RTBD 18.5 (0.37) (0.73) 78(3.07) 78(3.07) 20.5 (0.81) 128(5.04) 117(4.61) Unit: mm (inch) 13 - 23 13.1 External Dimension Diagrams...
  • Page 416 ■4. GT2104-PMBD 20.5 (0.81) (3.70) (0.37) 21.5 (0.85) (3.70) (5.71) (5.35) Unit: mm (inch) ■5. GT2104-PMBDS 20.5 (0.81) (3.70) (0.37) 21.5 (0.85) (3.70) (5.71) (5.35) Unit: mm (inch) 13 - 24 13.1 External Dimension Diagrams...
  • Page 417 ■6. GT2104-PMBDS2 20.5 (0.37) (0.81) (3.70) 21.5 94 (3.70) (0.85) 145 (5.71) 136 (5.35) Unit: mm (inch) ■7. GT2104-PMBLS 20.5 (0.81) (0.37) (3.70) 21.5 94 (3.70) (0.85) 145 (5.71) 136 (5.35) Unit: mm (inch) 13 - 25 13.1 External Dimension Diagrams...
  • Page 418 ■8. GT2103-PMBD (0.75) (2.52) (0.37) (0.83) (2.52) (4.45) (4.09) Unit: mm (inch) ■9. GT2103-PMBDS (0.75) (2.52) (0.37) (0.83) (2.52) (4.45) (4.09) Unit: mm (inch) 13 - 26 13.1 External Dimension Diagrams...
  • Page 419 ■10. GT2103-PMBDS2 (0.75) (2.52) (0.37) (0.83) (2.52) (4.45) (4.09) Unit: mm (inch) ■11. GT2103-PMBLS (0.75) (2.52) (0.37) (0.83) (2.52) (4.45) (4.09) Unit: mm (inch) 13 - 27 13.1 External Dimension Diagrams...

  • Page 420: Depth Dimensions And Cable Bend Radius For Gt27 With An Extension Unit

    13.2 Depth Dimensions and Cable Bend Radius for GT27 with an Extension Unit The following table shows the depth dimensions and the cable bend dimensions for the GOT with one extension unit. For the dimensions for the GOT with several extension units mounted in multiple stages, refer to the following. ➠...

  • Page 421: Gt2715-X

    0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.

  • Page 422: Gt2712-S

    0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.

  • Page 423: Gt2710-S, Gt2710-V

    0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.

  • Page 424: Gt2708-S, Gt2708-V

    0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.

  • Page 425: Gt2705-V

    0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.

  • Page 426: Depth Dimensions And Cable Bend Radius For Gt25 With An Extension Unit

    13.3 Depth Dimensions and Cable Bend Radius for GT25 with an Extension Unit The following table shows the depth dimensions and the cable bend dimensions for the GOT with one extension unit. For the dimensions for the GOT with several extension units mounted in multiple stages, refer to the following. ➠...
  • Page 427 0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.
  • Page 428 0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.
  • Page 429 0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.

  • Page 430: Gt2512F-S, Gt2510F-V, Gt2508F-V

    13.3.2 GT2512F-S, GT2510F-V, GT2508F-V Rear face Side face 100 or more Extension unit Other device unit: mm (inch) GOT model Dimension of X GT2512F-S 54(2.13) GT2510F-V 54(2.13) GT2508F-V 54(2.13) 13 - 38 13.3 Depth Dimensions and Cable Bend Radius for GT25 with an Extension Unit...
  • Page 431 0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.
  • Page 432 0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.
  • Page 433 0;however, it is written as "0" in the table. For details of the cable for GT15-J71LP23-25 (optical loop unit), contact your local Mitsubishi Electric System & Service Co., Ltd. The bend radius depends on the Ethernet cable to be used.

  • Page 434: Depth Dimensions For The Got With An Sd Card Unit (Gt2103-P)

    13.4 Depth dimensions for the GOT with an SD card unit (GT2103-P) The following table shows the depth dimensions for the GOT with an SD card unit. GT2103-PMBDS, GT2103-PMBD GT2103-PMBDS2 Rear face Side face Side face 80(3.15) or more 80(3.15) or more SD card unit Other device Other device...

  • Page 435: Depth Dimensions For The Got With Several Extension Units Mounted In Multiple Stages (Gt27, Gt25)

    13.5 Depth dimensions for the GOT with several extension units mounted in multiple stages (GT27, GT25) The following shows how to calculate the depth dimensions for the GOT with several extension units mounted in multiple stages. 13.2 For the dimensions for the GOT with one extension unit, refer to the dimension D in Depth Dimensions and Cable Bend Radius for GT27 with an Extension Unit.

  • Page 436: External Dimension Diagrams Of The Communication Cable

    13.6 External dimension diagrams of the communication cable ■1. External dimension diagrams of the bus connection cable connector External dimension Cable model Cable length (m(ft.)) diagram GT15-QC□B 0.6(2.0), 1.2(3.9), 3(10), 5(16), 10(33) GT15-QC□BS 15(49), 20(66), 25(82), 30(98), 35(115) (1) GT15-QC□B, GT15-QC□BS 34.5 (1.36) 10(0.39)
  • Page 437 ■3. External dimension diagrams of the RS-422 connection cable connector Cable model Cable length (m(ft.)) External dimensions GT16-C02R4-9S 0.2(0.7) GT01-C30R4-25P 3(10) GT01-C□R4-25P 10(33), 20(66), 30(98) GT01-C□R4-8P 1(3), 3(10), 10(33), 20(66), 30(98) GT10-C□R4-8P 1(3), 3(10), 10(33), 20(66), 30(98) GT10-C□R4-25P 3(10), 10(33), 20(66), 30(98) GT21-C□R4-8P5 1(3), 3(10), 10(33), 20(66), 30(98) GT21-C□R4-25P5...
  • Page 438 (7) GT10-C10R4-8PL 1000 (1.18) (39.4) (1.50) (9.84) Unit: mm (inch) (8) GT10-C□R4-8PC (2.05) (1.57) (9.84) Φ 13(0.51) Φ 25(0.98)×33(1.30) Φ 7(0.28) Unit: mm (inch) (9) GT10-C02H4-9SC 15(0.59) 45.5 (2.05) (7.87) (1.79) Φ 7(0.28) Unit: mm (inch) ■4. External dimension diagrams of RS-485 terminal block conversion unit Cable model Cable length (m(ft.)) External dimensions...

  • Page 439: External Dimensions Of The Connection Cable For Handy Got

    13.7 External Dimensions of the Connection Cable for Handy GOT ■1. External dimensions of external cables Cable model Cable length (m(ft.)) External dimension diagram GT16H-C□□□-42P 3(10), 6(20), 10(33) GT16H-C□□□-37PE 3(10), 6(20), 10(33) GT14H-C□□□-42P 3(10), 6(20), 10(33) GT11H-C□□□-37P 3(10), 6(20), 10(33) GT11H-C□□□...
  • Page 440 (3) GT14H-C□□□-42P About 70 (2.76) About 50 (1.97) Label 9.4 (0.38) 28 (1.11) Handy GOT side Connector conversion box side Unit: mm (inch) (4) GT11H-C□□□-37P About 70 (2.76) (0.63) 45 (1.78) Label 9.4 (0.38) 28 (1.11) M2.6 Handy GOT side Connector conversion box side Unit: mm (inch) (5) GT11H-C□□□...
  • Page 441 (7) GT11H-C15R4-25P 1500 (59.06) Label 16 (0.63) M2.6 53 (2.09) 200 (7.88) (0.32) (1.42) (0.63) Lead wire Label for grounding 500 (19.69) Unit: mm (inch) (8) GT11H-C15R2-6P 1500 (59.06) Label About48 40 (1.58) 200 (7.88) (1.89) (0.24) (0.63) Lead wire Label for grounding 500 (19.69)

  • Page 442: Confirming Of Versions And Conforming Standards

    13.8 Confirming of Versions and Conforming Standards 13.8.1 GT27, GT25, GT23 ■1. Rating plate The GOT hardware version, BootOS version at factory default, function version, and conforming standards can be checked with the rating plate on the GOT rear face. QR code MAC address GOT serial number...

  • Page 443: Gt21

    13.8.2 GT21 ■1. Rating plate The GOT hardware version, BootOS version at factory default, function version, and conforming standards can be checked with the rating plate on the GOT rear face. QR code GOT serial number 1 4 4 0 0 0 1 A A BootOS version at factory default Hardware version Manufacture month...

  • Page 444: Calculating Consumed Current Of Gt2705-V

    13.10 Calculating consumed current of GT2705-V For using multiple extension units, a bar code reader, or a RFID controller, the total current for the extension units, bar code reader, or RFID controller must be within the current that the GT2705-V can supply. GOT other than GT2705-V, the calculation of the current value is not required.

  • Page 445: Revisions

    REVISIONS * The manual number is given on the bottom left of the back cover. Print Date * Manual Number Revision Sep. 2013 SH(NA)-081194ENG-A First printing: GT Designer3 Version1.100E Nov. 2013 SH(NA)-081194ENG-B Compatible with GT Works3 Version1.104J • Description of SAFETY PRECAUTIONS changed •...
  • Page 446 • Partial corrections. This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 447: Warranty

    If requested by the customer, Mitsubishi Electric Corporation or its representative firm may carry out the primary failure diagnosis at the customer’s expense. The primary failure diagnosis will, however, be free of charge should the cause of failure be attributable to Mitsubishi Electric Corporation.
  • Page 448 MELDAS, MELSEC, iQ Platform, MELSOFT, GOT, CC-Link, CC-Link/LT, and CC-Link IE are trademarks or registered trademarks of Mitsubishi Electric Corporation in Japan and other countries. Microsoft, Windows, Windows Vista, Windows NT, Windows Server, SQL Server, Visual C++, Visual C#, Visual Basic, Excel, and Access are trademarks or registered trademarks of Microsoft Corporation in the United States and other countries.
  • Page 450 GOT2000 Series User's Manual (Hardware) GOT2000-U-HW-E MODEL MODEL 1D7MJ5 CODE When exported from Japan, this manual does not require application to the Ministry of Economy, SH(NA)-081194ENG-Y(1807)MEE Trade and Industry for service transaction permission. HEAD OFFICE : TOKYO BUILDING, 2-7-3 MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN NAGOYA WORKS : 1-14 , YADA-MINAMI 5-CHOME , HIGASHI-KU, NAGOYA , JAPAN Specifications subject to change without notice.

This manual is also suitable for:

Vicpas got2000 seriesVicpas gt2105-qtbdsVicpas gt2105-qmbdsVicpas gt2105-qtbds-k

Table of Contents

Save PDF
