Teltonika GH5200 User Manual page 25

configured movement source) is detected. It allows filtering GPS jumps when the object is parked
(not moving) and GPS position is still traced.
GNSS Source settings allows user to configure which GNSS system(s) to use. User has a
choice to use one system between GPS, GLONASS, Galileo or BeiDou and it is possible to choose
two or three systems together. One exception is that you cannot combine BeiDou and GLONASS
systems together. Below you will find GNSS source combination examples:
List of configurable GNSS sources:
BeiDou only
GLONASS only
Galileo only
Galileo+BeiDou
Galileo+GLONASS
GPS only
GPS+BeiDou
GPS+Glonass
GPS+Galileo
GPS+Galileo+BeiDou
GPS+Galileo+GLONASS
List of NON–configurable GNSS sources:
GLONASS+BeiDou
Figure 8 System settings configuration
ID:01
ID:02
ID:04
ID:05
ID:06
ID:08
ID:09
ID:10
ID:12
ID:13
ID:14
25
Example of good configuration
