The Back Panel - TP-Link Archer AX10 User Manual

Chapter 1
LED Explanation
(2.4GHz Wireless)
(5GHz Wireless)
1. 2. 2.
The following parts (view from right to left) are located on the back panel.
Button and Port Explanation
Power On/Off Button
Downloaded from ManualsNet.com
LED Status
On
Off
On
Off
Green On
Orange On
(Internet)
Off
On
(Ethernet)
Off
On/Off
(WPS)
Flashing

The Back Panel

Item
Power Port For connecting the router to a power socket via the provided power adapter.
Press this button to power on or off the router.
search engine
Indication
The 2.4GHz wireless band is enabled.
The 2.4GHz wireless band is disabled.
The 5GHz wireless band is enabled.
The 5GHz wireless band is disabled.
Internet service is available.
The router's Internet port is connected, but the internet service
is not available.
The router's Internet port is unplugged.
At least one powered-on device is connected to the router's LAN
port.
No powered-on device is connected to the router's LAN port.
This light remains on for 5 minutes when a WPS connection is
established, then turns off.
WPS connection is in progress. This may take up to 2 minutes.
Description
Get to Know About Your Router
