Back Panel And Side Panel - TP-Link Archer AX73V User Manual

Chapter 1
Name
(2.4 GHz Wireless)
(5 GHz Wireless)
(Internet)
(LAN)
(Firmware Update)
(WPS)
1 2 2

Back Panel and Side Panel

Status
On The 2.4 GHz wireless band is enabled.
Off The 2.4 GHz wireless band is disabled.
On The 5 GHz wireless band is enabled.
Off The 5 GHz wireless band is disabled.
White On Internet service is available.
The router's WAN port is connected, but the internet service is
Orange On
not available.
Off The router's WAN port is unplugged.
At least one powered-on device is connected to the router's
On
Ethernet port.
Off No powered-on device is connected to the router's Ethernet port.
On The latest firmware is available for your router.
Blinking The router is upgrading.
Off The firmware version is up to date.
When a WPS connection is established, this light turns solid on,
On/Off
then turns off.
Blinking WPS connection is in progress. This may take up to 2 minutes.
Get to Know About Your Router
Indication
5
