Back Panel - TP-Link Archer AX3000 User Manual

Chapter 1
Name Status
(5 GHz Wireless)
Orange On
(Internet)
(Ethernet)
(WPS)
1 2 2

Back Panel

Button and Port Explanation (from bottom to top)
Item
Power Port
WAN Port
LAN Port (1-4)
Reset Button
On The 5 GHz wireless band is enabled.
Off The 5 GHz wireless band is disabled.
Blue On Internet service is available.
The router's Internet port is connected, but the internet service
is not available.
Off The router's Internet port is unplugged.
At least one powered-on device is connected to the router's
On
Ethernet port.
Off No powered-on device is connected to the router's Ethernet port.
When a WPS connection is established, this light turns solid on,
On/Off
then turns off.
Blinking WPS connection is in progress. This may take up to 2 minutes.
For connecting the router to a power socket via the provided power adapter..
For connecting to a modem or an Ethernet outlet.
For connecting your PC or other wired devices to the router.
Press and hold the button until the LED blinks to reset the router to its factory
default settings.
Get to Know About Your Router
Indication
Description
5
