Cecilware sells value...
Worldwide
43-05 20th Avenue, Long Island City, 11105
JAVA2-LP MANUAL
718-932-1414
Fax: 718-932-7860
OPERATIONAL MANUAL
• Specifications............................................
• Installation & Start Up
Procedure...............
• Programming..............................................
• Adjustments...............................................
• Cleaning & Sanitizing.................................
• Parts Identification....................................
• Wiring Diagrams.........................................
LECTRICAL SPECIFICATIONS:
120 Volts
15 Amp Circuit
60 Hz
1 Heater
1,700 Watts
5-15R Receptacle
MECHANICAL SPECIFICATIONS:
Width: 8.5"
Depth: 20"+2" Clearance For Waterline.
Height: 21"+2.5" Legs.
Cup Clearance: 4.5"
Hopper Capacity: 1 Lb Dry Coffee.
Tank Capacity: 1 Us Gal.
Burst Rate: 120 Cups/Hr.
Recovery Time: 5 Min.
FACTORY SETTINGS:
Gram Throw Dial: 2.4
Coffee Gram Throw: 2.2 gr. Coffee /8 oz. Cup.
Water Flow Rate: 1 to 1.3 oz./sec.
1
2
3
3
5
10
11
NJ15A 3/18/2002
Advertisement
Related Manuals for Cecilware JAVA2-LP
Summary of Contents for Cecilware JAVA2-LP
- Page 1 Cecilware sells value... Worldwide 43-05 20th Avenue, Long Island City, 11105 JAVA2-LP MANUAL OPERATIONAL MANUAL • Specifications...…………….. • Installation & Start Up Procedure…………… • Programming...…………... • Adjustments...…………... • Cleaning & Sanitizing...……………… • Parts Identification...……………… • Wiring Diagrams...……………….. LECTRICAL SPECIFICATIONS: 120 Volts...
-
Page 2: Installation
2. An approved back flow prevention device, such as a double check valve to be installed between the machine and the water supply. The JAVA2-LP is equipped with a 1/4" Flare Water Inlet Fitting, located on the lower left side in the back of the base. HIGHLY RECOMMENDED: A WATER SHUT-OFF VALVE and A WATER FILTER, preferably a combination Charcoal/Phosphate Filter, to remove odors and inhibit lime and scale build up in the machine. - Page 3 Drink or Product Strength can be changed by adjusting the Gram Throw Dial on inside door panel. The Gram Throw is factory preset at approx. 2.4 (2.2 gr. per 8 oz. cup) for the JAVA2-LP machines. The water flow rate adjustment for the dispense valve should remain fixed bet. 1 - 1.3.
- Page 4 JAVA2-LP HOPPER ASS'Y CD313 & DISPENSE ASS'Y CAPACITY- 1 LB COFFEE, 7.875"H w/cover x 3"W, W/NYLON AUGER HOPPER COVER CD106 AGITATOR GEAR CD117 HOPPER CD313 AUGER BUSHING FRONT CD277 NYLON AUGER CD130 (22.5Øx18mmPT) W/"O" RING CD139 PRODUCT GUIDE CD70A DISPENSE CAP BLK - CD272 MIXING CHAM.
-
Page 5: Cleaning And Sanitizing
CLEANING AND SANITIZING: SANITIZING: All food dispensing units should be sanitized periodically. All parts to be sanitized must be cleaned first. To prepare a sanitizing solution: ADD 2 TSP. OF LIQUID CLOROX BLEACH (5.25% CONCENTRATION) TO 1 GALLON OF WATER AT ROOM TEMPERATURE (70° - 90°F). Soak all parts for a minimum of 3 min. -
Page 6: Front Open View
FRONT OPEN VIEW... - Page 7 RIGHT SIDE OPEN VIEW...
- Page 8 LEFT SIDE OPEN VIEW...
- Page 9 TANK TOP ASS’Y...
- Page 10 FRONT OPEN VIEW ITEM P/N QTY DESCRIPTION RX67A 1 TOP COVER, CABINET SF79A 2 SIDE PANELS CD313 1 HOPPER ASS'Y M705A 1 DOOR LATCH RV57Q 1 TROUGHT DRAWER ASS'Y CD272 1 STEAM DEFLECTOR CD67A 1 SOCKET F/ MIXING BOWL L299A 1 RINSE SWITCH CD275 1 DISPENSE CHAMBER [8mm dia.]...
- Page 11 TANK TOP ASS’Y SG08A ITEM DESCRIPTION L573A HI-LIMIT, SURFACE MOUNT P465A SCREW, TANK TOP 1/4-20x5/8 M461A GROMMET [.446 ID] L681A THERMOSTAT K402Q LEVEL CONTROL PROBE K525A ELBOW TUBE, SS OR M787A ELBOW SILICON TUBE, BREATHER HOSE, BREATHER TUBE G296A HEATER 120V, 1500W 03051 NUT F/ HEATER 07059...
- Page 12 TEACH-ME TIMER COFFEE SPEED CONTROL D.C. AUGER MOTOR WATER LEVEL PROBE - IN TANK WATER INLET VALVE HEATER LIGHT HI-LIMIT TEACH-ME TEACH-ME TIMER TIMER STOP HOT WATER SPEED CONTROL COFFEE & HOT WATER DECAFF DISPENSE DISPENSE VALVE VALVE 1 PROBE LEVEL CONTROL 2 L1...
