Fig. 3: Rear Of 2.762.0010 Ic Interface - Metrohm 762 IC Interface Instructions For Use Manual

Type 1.762.0020 Nr.
100 - 240 V
f = 50-60 Hz
P = 7 W
7 7 8 8
7 7 Earthing socket
8 8
Mains connection plug
Mains connection see section 2.2
9 9 Serial number
10 10 PC connection
RS232 interface
762 IC Interface
9 9 13 13 12 12
Made by Metrohm Herisau Switzerland
1 2 3 4 5 6 7
Dev. 1/5 Dev. 2/6
S
11 11

Fig. 3: Rear of 2.762.0010 IC Interface

10 10
PC
System 1
Events
Run
Start
Com
Dev. 3/7 Dev. 4/8
14 14
11 11 Analog signal connection
12 12
Remote input/output lines
connection (RUN)
13 13 Remote input/output lines
connection (COM)
14 14 RS232 interfaces
1.2 Parts and controls
3
