3 Operation
26
Program
On the subpage, program steps including time, program in-
Program
struction and parameter can be entered.
First column
Second column
Third column
ENABLED
< >
Add
< >
Delete
< >
Verify
List of program instructions
The following program instructions can be added to the time program
on the subpage:
Program
Instruction Entry
Events 0, 1, p, *
Program END, RESET
Time at which program instruction is applied.
Entry range:
0.0 ... 999.9 min
If no time is entered, the program instruction is
applied together with the last instruction with
time entry.
Program instruction (see below).
In addition to these predefined instructions,
user-defined remote commands can be en-
tered if activated on the
Parameter for program instruction (see below).
Enable program start (a disabled program is
not started).
Add new program instruction.
Delete selected program instruction.
Test the time program (error messages are dis-
played if program is wrong).
Meaning
Set event output lines 1...7 to the desired
values. For entry of the first value, enter
, or . For entry of the other values, move
0 p *
the cursor in front of the value to be
changed and enter
The flag can be used to end a
END
program, especially if the program time
should be longer than the chromatogram
duration. Additional steps after this flag are
not allowed. The
RESET
reset the parameters to the system startup
values.
tab.
Events configuration
,
1
, , or .
1 0 p *
flag is used to
762 IC Interface
