Summary of Contents for Wallbox EV PORTABLE

  • Page 1 WALLBOX EV PORTABLE USER MANUAL INSTALLATION MANUAL...
  • Page 2 EV Portable bears the CE mark. The corresponding Declarations of Conformity are located at WallboxOK This product meets the requirements of the ROHS Directive (2011/65/CE). The corresponding Declarations of Conformity are located at WallboxOK Disposal Information The crossed-out trash container symbol indicates that electric appliances and electronic devices including accessories are to be disposed of separately from general household trash.
  • Page 3: Table Of Contents

    WallboxOk Team wants to thank you for buying one of our Electric Vehicle Charging Box. Our passion in design and innovation makes our charging points leaders in technology. Do not hesitate to contact us at info@wallboxok.com if you have any suggestion. We hope you enjoy your product Best regard, The Wallbox Ok Team www.wallboxok.com...
  • Page 4: Important Information

    IMPORTANT INFORMATION Safety instructions Warning! Not observing the safety instructions can result in risk of death, injuries and damage to the device! WALLBOXOK assumes no liability for claims resulting from this!  Electrical hazard / fire hazard! Never use damaged worn or dirty charging plugs. ...
  • Page 5: Intended Used

    Entended use EV PORTABLE is a "charging station" for the indoor and outdoor area at which electrically operated vehicles can be charged (e.g. electric automobiles). It can be used portable and allow you to change the maximum Amps rate. The respective national regulations must be observed with regard to the installation and connection of the charging station.
  • Page 6: Overview

    OVERVIEW WALLBOX EV PORTABLE AMPS RATE BUTTONS LCD DISPLAY WALLBOX PORTABLE Cable IEC 62196 o SAE J1772 INDUSTRIAL CEE PLUG www.wallboxok.com...
  • Page 7: Versions

    VERSIONS Amps Range 6-32 Amps 6-32 Amps Phase 3F+N+TT 1F+N+TT Max Power 22 kW 7,6 kW CEE Plug www.wallboxok.com...
  • Page 8: Using The Charging Station

    USING THE CHARGING STATION 1. Plug CEE industrial conector. 2. Select the Amp rate with the buttons. PLEASE READ BEFORE SECTION 4.1 “AMPS RATE SELECTION”! 3. Plug the charging cable into Vehicle. Starting the charging procedure 1. When the car allows the EVSE start charging, the recharge station will begin to charge. In the LCD display will show the state of charge.
  • Page 9: Charge Amps Selection

    CHARGE AMPS SELECTION ATENTION, BEFORE USING THE EVSE, PLEASE REVISE THIS SECTION. THE WRONG USE OF THE EQUIPMENT CAN DAMAGE THE ELECTRICAL INSTALLATION. The Amp rate selection depends on the electrical installation and the adaptor used. It has to be selected with the front buttons.
  • Page 10: Troubleshooting

    All charging stations are supplied with power CETAC 32 Amp. (Single or three phase depending on the output connector). You can purchase as many adapters as needed. TROUBLESHOOTING. PROBLEM Possible cause - remedy  LCD Display does not light up No voltage supply –...
  • Page 11: Installation Guidelines

    INSTALLATION GUIDELINES. GENERAL CRITERIA FOR THE SITE SELECTION The charging station was constructed for the indoor and outdoor area. Accordingly, it is necessary to ensure the installation conditions and the protection of the device at the installation site.   Take into account the local electrical installation regulations, fire prevention measures and accident prevention regulations as well as emergency routes at this site.
  • Page 12: Specification For The Electrical Connection

    SPECIFICATION FOR THE ELECTRICAL CONNECTION EV Portable is designed for plug it in a CEE Industrial connector (female). You need to choose the amps rate depending on the place where it is installed and the adaptor selected. EV Portable needs to be connected to a main supply line and must be hardwired and correspond to the nationally applicable legal conditions.
