Technical data
3.2

Electrical system, Optical and Mechanical Data

spectral sensitivity
CFC 200 UV1 (formerly 8.0) 190 bis 550 nm
CFC 200 UV (formerly 8.30) 280 bis 420 nm
CFC 200 IR (formerly 8.40) 300 bis 1050 nm
CFC 200 IR3 (formerly 8.70) 1050 bis 2700 nm
Sight view angle
Self monitoring
Operating voltage
Current consumption
Design
Ambient temperature
Current output
Flame relay
Thresholds
Adjustment
Safety switch-off time
Sight view connection
Purge air connection
Purge air volume
3-2
2,7 °
fully electronic
24 V DC
approx. 200 mA
according to class III SELV
-20 degrees to +70 degrees C
0/4...20 mA, Ra < 250 Ω
1 changeover contact, floating
VDE 0110, class A
max. 48 V switching voltage
max. 1 A switching current
(fused with 0.5 A)
max. 30 W switching power
„Flame ON" 5 (8) mA
„Flame OFF" < 5 (8) mA
with sensitivity potentiometer
set by factory to 1 s
1" inner thread ISO 228
½" inner thread ISO 228
10 m³/h
