Technical data
3.2 Electrical system, Optical and Mechanical
Data
Spectral sensitivity
UV
UV1
IR
IR2
Angle of view
Self-monitoring
Operating voltage
Current consumption
Pre fuse
Design
Range of operating tem-
perature
Current output
Fault output
Range changeover
Flame relay
Sitching thresholds
Safety switch-off time
3-2
280 to 420 nm
190 to 550 nm
300 to 1050 nm
300 to 2700 nm
3° with SKL
Fully electronic,
1 x per 800 ms
24 V DC
approx. 200 mA
max. 1 A, slow
In accordance with protection
class III SELV
-20 °C to +70 °C
(-4 °F to 158 °F)
0(4) to 20 mA (Ra<250 Ohm)
Current window variable by soft-
ware
24 V DC, short circuit-proof
External selection via 24 VDC
signal
1 changeover contact, floating
wire break detection optional
VDE 0110, Class A
max. 48 V switching voltage
max. 1 A switching current (fused
with 0.5 A)
max. 30 W switching power
programmable by software
0.4 to 5 s, set to 1 s by factory
