4. Option Programming

F. Programming Options
OPTION
Option Bank 0 - 3 Chirps (Learn Transmitters)
Option Bank One - 4 Chirps (Alarm Options)
1. Lite Touch Adj.
2. Full Shock Adj
3. Ignition Triggered Lock
4. Delayed Door Lock
5. Extended Locks
6. Ignition Triggered Unlock Doors Unlock when ignition is turned off
7. Double Pulse Unlock
8.Extended Horn Pul s e
Option Bank Two - 5 Chirps (Keyless & Alarm Options)
1. Passive Starter Kill
2. Passive Arming
3.Passive Locks
4. Confi r mati o n Chi r ps
5. Silent Choice
6. Horn/Si r en
7. Noise Control
8. Horn Output
Option Bank Three - 6 Chirps (Car Start Options)
1. Tach Mode
2. Blind Crank Time
3. Adjustable Crank Time
4. Run Ti m e
5. Diesel Mode
6. Doors Lock After Start
7. Door Trigger Delay
8. External Start Tri g ger
Option Bank Four - 7 Chirps (Polarity Select Options)
1. Door Trigger Polarity
2. External Start Tri g ger
3. Neutral Safety Input
4. Tach Learn
5. Aux 2
6. Aux 2
18
630.p65
DESCRIPTION
ARM raises sensitivity: DISARM lowers sensitivity
ARM raises sensitivity: DISARM lowers sensitivity
Doors lock when all doors are closed and
Ignition is turned on
3 sec delay locking for theatre dimming
Lock duration is (1)5 sec or (2) 0.6 sec
Unit provides 2 pulses when unlocked
Acti v ates Longer Horn Pul s e Output
Engages starter kill after one minute
Alarmautomatically arms 60 sec.
after ignition is turned off
Locks doors automatically after 60 seconds
(1) Yes (2) No confi r mati o n chi r ps
(1) By Pressing LOCK o r UNLOCK twice (manual) ON(1) OFF(2)
(1) Horn (2) Si r en
Alarm will (1) sound for five 30-sec. cycles,
then ignore trigger or (2) Sound continuously
when triggered if an entrance is left open
(1) Real Panic (2) Pulsed Output
(1) Use blind crank timing (2) Use tach input
(1) Avg of last 8 manual starts (2) 1 sec.
A R M increases crank, D I S ARM decreases crank
See Table 1.1
(1) 25 mi n utes (2) 12 mi n utes ON(1)
Start crank begins (1) 15 sec. or
(2) 2 sec. after ignition turns on
Relocks doors after start command
(1) Door trigger ignored 60 sec. after start
(2) Door trigger always active
(1) External start trigger requires 1 pulse
(2) External start trigger requires a double pulse
(1) Positive (2) Negative
(1) Positive (2) Negative
(1) Positive (2) Negative
With hood open key start vehicle
See table 1. 2
See table 1. 2
18
Default settings in BOLD
INDICATOR
ON OFF
ON OFF
ON OFF
ON OFF
ON OFF
ON OFF
O N OFF
O N OFF
ON OFF
ON(1) OFF(2)
ON(1) OFF(2)
ON(1) OFF(2)
ON (1) OFF (2)
ON(1) OFF(2)
ON(1) OFF(2)
OFF(2)
ON (1) OFF(2)
ON OFF
ON(1) OFF(2)
ON(1) OFF(2)
ON(1) OFF(2)
ON(1) OFF(2)
ON(1) OFF(2)
