- Page 1 Cyclone 8 Sculpted sound, compact styling U S E R G U I D E V 2 . 0...
- Page 2 For the latest online version, visit: www.voidacoustics.com Void Acoustics and the Void logo are registered trademarks of Void Acoustics Research Ltd. in the United Kingdom, USA and other countries; all other Void trademarks are the property of Void Acoustics Research Ltd.
-
Page 3: Table Of Contents
Cyclone Glanded Connector Wiring Cyclone 8 Wiring Diagram Bias D1/Q1/Q2 Phoenix Wiring Bias Q3/Q5 speakON™ Wiring Mounting Installation Safety Wall Mounting Ceiling Mounting Service Return Authorisation Shipping and Packing Considerations Appendix UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 3... -
Page 4: Safety And Regulations
Void Acoustics Research Ltd for such as when the power-supply cord or plug is damaged, liquid reprocessing. -
Page 5: Unpacking And Checking
If you need to place the loudspeaker on a flat surface ensure you use a lint free product to protect the finish • When you have removed the Cyclone 8 loudspeaker from the packaging inspect it to en- sure there is no damage and keep all original packaging in case it needs to be returned for any reason. -
Page 6: About
In buying this product, you are now part of the Void family and we hope using it brings you years of satisfaction. This guide will help you both use this product safely and ensure it performs to its full capability. -
Page 7: Cyclone 8 Specifications
Measured in half space AES2 - 1984 compliant Calculated 3.5 Cyclone 8 dimensions 450 (17.7”) 317 (12.5”) 80 (3”) 450 (17.7”) 293 (11.5”) 450 (17.7”) 177 (7”) 4xM8 Fixtures 450 (17.7”) Figure 3.1: Dimensions UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 7... -
Page 8: Cable And Wiring
Figure 4.1 shows the rear panel of a Cyclone Series loudspeaker with the polarity of the Phoenix connector labelled. When viewed from the rear the connectors are negative, positive, negative, positive, from left to right. Figure 4.1: Phoenix connector diagram UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 8... -
Page 9: Cyclone Glanded Connector Wiring
• Undo the glanded connectors from the rear of the connector plate. Figure 4.3: Glanded connector removal • Insert the cable through the glanded connectors and tighten. Figure 4.4: Cable connection UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 9... - Page 10 4 Cable and Wiring • Attach the cable to the phoenix connector. Figure 4.5: Phoenix attachment • Position the connector plate and insert the two M6 bolts. Figure 4.6: Connector plate connection UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 10...
-
Page 11: Cyclone 8 Wiring Diagram
Figure 4.8: Bias D1 output connection Figure 4.9: Bias Q1/Q2 output connection Bias D1/Q1/Q2 Out 1 Output LF (8”) and HF (1”) 4 (2 Ω load to amplifier) Max parallel units UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 11... -
Page 12: Bias Q3/Q5 Speakon™ Wiring
4.7 Bias Q3/Q5 speakON wiring Figure 4.10: Bias Q3 Figure 4.11: Bias Q5 Bias Q3/Q5 Out 1 Output LF (8”) and HF (1”) 4 (2 Ω load to amplifier) Max quantity per channel UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 12... -
Page 13: Mounting
• Use only Void-approved mounting equipment and accessories • Secondary safeties should be provided in all instances where cabinets are flying or fixing overhead and should conform to local regulations UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 13... -
Page 14: Wall Mounting
Figure 5.3: Deconstructing the bracket assembly UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 14... - Page 15 (figure 5.6a) and in the vertical axis by adjusting the bolt on the base of the assembly (figure 5.6b). Figure 5.6a: Bracket adjustment Figure 5.6b: Bracket adjustment UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 15...
-
Page 16: Ceiling Mounting
Take care when mounting the bracket to the ceiling, making sure to use the correct fixing and that the ceiling can take the load. Figure 5.9: Deconstruction the bracket UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 16... - Page 17 Fix the connector plate to the bracket using the M10 nut and washer. Figure 5.11: Bracket fixing Step 6: Use the bolt shown to adjust the vertical orientation. Max horizontal rotation: 360° Max vertical rotation: ±12° Figure 5.12: Rotation UG10582-2.0 - Cyclone 8 User Guide V2.0 Page 17...
-
Page 18: Service
Before returning your faulty product for repair, please remember to get an R.A.N. (Return Authorisation Number) from the Void dealer who supplied the system to you. Your dealer will handle the necessary paperwork and repair. Failure to go through this return authorisation procedure could delay the repair of your product. -
Page 19: Appendix
7 Appendix Application Note: Loudspeakers in Corrosive Environments Void Acoustics’ weather protected and IP rated products are suitable for outdoor use, however installations in highly corrosive environments, such as high salinity or in the presence of corrosive chemicals such as chlorine, require additional care and maintenance. The following guide will help to prevent corrosion and prolong both the product aesthetics and sonic performance. - Page 20 RAL colour with external dimensions of (H) 281 mm x (W) 450 mm x (D) 293 mm (11” x 17.7” x 11.5”). Weight shall be 14 kg (31 lbs). The loudspeaker shall be the Void Acoustics Cyclone 8. UG10582-2.0 - Cyclone 8 User Guide V2.0...
- Page 21 H E A D O F F I C E Void Acoustics Research Ltd, Unit 15, Dawkins Road Industrial Estate, Poole, Dorset, BH15 4JY United Kingdom Call: +44(0) 1202 666006 Email: info@voidacoustics.com voidacoustics.com Void Acoustics Research Limited is a company registered in England and Wales registration number 07533536...
