Summary of Contents for Void Cyclone 55
- Page 1 Cyclone 55 Compact styling, impressive sound U S E R G U I D E V 2 . 0...
- Page 2 For the latest online version, visit: www.voidacoustics.com Void Acoustics and the Void logo are registered trademarks of Void Acoustics Research Ltd. in the United Kingdom, USA and other countries; all other Void trademarks are the property of Void Acoustics Research Ltd.
-
Page 3: Table Of Contents
Cyclone 55 Wiring Diagram Bias D1/Q1/Q2 Phoenix wiring Bias Q3/Q5 speakON ™ wiring Mounting Installation Safety Wall Mounting Ceiling Mounting Stud Mount Pole Mount Service Return Authorisation Shipping and Packing Considerations Appendix UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 3... -
Page 4: Safety And Regulations
Void Acoustics Research Ltd for such as when the power-supply cord or plug is damaged, liquid reprocessing. -
Page 5: Unpacking And Checking
2 Unpacking and Checking All Void Acoustics products are carefully manufactured and thoroughly tested before being despatched. Your dealer will ensure that your Void products are in pristine condition before being forwarded to you but mistakes and accidents can happen. -
Page 6: About
In buying this product, you are now part of the Void family and we hope using it brings you years of satisfaction. This guide will help you both use this product safely and ensure it performs to its full capability. -
Page 7: Cyclone 55 Specifications
IP-55 (BS EN 60529:1992 +A2:2013) Rigging Wall bracket included, type 51 plate Finish Smooth cellulose Measured in half space AES2 - 1984 compliant Calculated Figure 3.1: Horizontal directivity isobars Figure 3.2: Vertical directivity isobars UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 7... -
Page 8: Cyclone 55 Dimensions
3 About 3.5 Cyclone 55 dimensions Figure 3.3: Dimensions UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 8... -
Page 9: Cable And Wiring
Figure 6.1 shows the rear panel of a Cyclone Series loudspeaker with the polarity of the Phoenix connector labelled. When viewed from the rear the connectors are negative, positive, negative, positive, from left to right. Figure 4.1: Phoenix connector diagram UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 9... -
Page 10: Cyclone Glanded Connector Wiring
Figure 4.3: Glanded connector removal • Insert the cable through the glanded connectors and tighten. Figure 4.4: Cable connection UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 10... - Page 11 4 Cable and Wiring • Attach the cable to the phoenix connector then position the connector plate and attach it using the M6 bolts. Figure 4.5: Phoenix attachment UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 11...
-
Page 12: Cyclone 55 Wiring Diagram
5” LF 1” HF Passive Crossover 5” LF 1” HF Passive Crossover Figure 4.7: Wiring diagram Phoenix pins 1-/1+ Phoenix pins 2-/2+ HF (2 x 1”) and LF (2 x 5”) Link/out UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 12... -
Page 13: Bias D1/Q1/Q2 Phoenix Wiring
Figure 4.10: Bias Q3 Figure 4.11: Bias Q5 Bias Q3/Q5 Out 1 Output LF (2 x 5”) and HF (2 x 1”) 4 (2 Ω load to amplifier) Max quantity per channel UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 13... -
Page 14: Mounting
• Use only Void-approved mounting equipment and accessories • Secondary safeties should be provided in all instances where cabinets are flying or fixing overhead and should conform to local regulations UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 14... -
Page 15: Wall Mounting
Remove all four M6 bolts from the rear of the loudspeaker. Figure 5.2: Bolt removal Step 2: Remove the mounting plate from the wall bracket by removing the M6 countersink as shown. Figure 5.3: Mounting plate UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 15... - Page 16 5.6a. Max horizontal rotation: ±25° Max vertical rotation: +28°, -0° Figure 5.6a: Vertical bracket mounting UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 16...
- Page 17 5.6b. Max horizontal rotation: ±54° Max vertical rotation: -70°, +60° Figure 5.6a: Vertical bracket mounting UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 17...
-
Page 18: Ceiling Mounting
Remove the mounting plate from the bracket by removing the M12 bolt as shown Figure 5.8: Mounting plate removal Step 2: Remove all four M6 bolts from the rear of the loudspeaker. Figure 5.9: Bolt removal UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 18... - Page 19 M12 nut that was removed in step 1. Max horizontal rotation: 360° Max vertical rotation: ±12° Figure 5.11: Ceiling mounting UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 19...
-
Page 20: Stud Mount
Step 2: Attach the stud bracket using all four M6 bolts. The product can now be mounted to third party hardware using the M12 mounting position. Figure 5.14: Stud bracket attachment UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 20... -
Page 21: Pole Mount
Figure 5.16: Bolt removal Step 2: Attach the pole bracket kit using all four M6 bolts. Max horizontal rotation: 360° Max vertical rotation: ±12° Figure 5.17: Pole mount kit attachment UG10583-2.0 - Cyclone 55 User Guide V2.0 Page 21... -
Page 22: Service
Before returning your faulty product for repair, please remember to get an R.A.N. (Return Authorisation Number) from the Void dealer who supplied the system to you. Your dealer will handle the necessary paperwork and repair. Failure to go through this return authorisation procedure could delay the repair of your product. -
Page 23: Appendix
(H) 192 mm x (W) 309 mm x (D) 207 mm (7.6” x 12.2” x 8.1”). Weight shall be 3.2 kg (7.1 lbs). The loudspeaker shall be the Void Acoustics Cyclone 55. UG10583-2.0 - Cyclone 55 User Guide V2.0... - Page 24 H E A D O F F I C E Void Acoustics Research Ltd, Unit 15, Dawkins Road Industrial Estate, Poole, Dorset, BH15 4JY United Kingdom Call: +44(0) 1202 666006 Email: info@voidacoustics.com voidacoustics.com Void Acoustics Research Limited is a company registered in England and Wales registration number 07533536...
