- Page 1 Cyclone 4 Compact Fidelity Starts Here U S E R G U I D E V 1 . 0...
- Page 2 For the latest online version, visit: www.voidacoustics.com Void Acoustics and the Void logo are registered trademarks of Void Acoustics Research Ltd. in the United Kingdom, USA and other countries; all other Void trademarks are the property of Void Acoustics Research Ltd.
-
Page 3: Table Of Contents
Phoenix Connector Polarity Cyclone Glanded connector wiring Cyclone 4 Wiring Diagram Bias D1/Q1/Q2 Phoenix Wiring Bias Q3/Q5 speakON™ Wiring Mounting Installations Safety Wall Mounting Ceiling Mounting Stud Mount Pole Mount Service Appendix UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 3... -
Page 4: Safety And Regulations
Void Acoustics Research Ltd for such as when the power-supply cord or plug is damaged, liquid reprocessing. -
Page 5: Unpacking And Checking
Cyclone 4 loudspeakers come double boxed and are stapled shut; take care when unboxing and removing the staples to avoid injury or damage to the loudspeaker • If you need to place the Cyclone 4 loudspeaker on a flat surface ensure you use a lint free product to protect the finish •... -
Page 6: About
0.75” soft dome HF tweeter. Supplied as standard with a conventional wall bracket, the Cyclone 4 can also make use of the wide range of brackets that are available for the larger models, allowing for a quick and easy installation. -
Page 7: Cyclone 4 Specifications
Width 179 mm (7.1”) Depth 175 mm (6.9”) Measured in free space, AES2 - 1984 compliant, Calculated, BS EN 60529:1992 +A2:2013 Figure 3.1: Horizontal directivity isobars Figure 3.2: Vertical directivity isobars UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 7... -
Page 8: Cyclone 4 Dimensions
3.5 Cyclone 4 dimensions 179 (7.1”) 150 (5.9”) 175 (6.9”) Figure 3.3: Dimensions UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 8... -
Page 9: Cable And Wiring
Figure 4.1 shows the rear panel of a Cyclone Series loudspeaker with the polarity of the Phoenix connector labelled. When viewed from the rear the connectors are negative, positive, negative, positive, from left to right. Figure 4.1: Phoenix connector diagram UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 9... -
Page 10: Cyclone Glanded Connector Wiring
4.1 5. Reconnect the terminal block, once it is fixed in place reconnect the glanded connector plate with the M4 bolts provided UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 10... -
Page 11: Cyclone 4 Wiring Diagram
4.6 Bias D1/Q1/Q2 Phoenix wiring Figure 4.3: Bias D1 Figure 4.4: Bias Q1/Q2 Bias D1/Q1/Q2 Out 1 Output LF (4”) and HF (0.75”) 8 (2 Ω load to amplifier) Max quantity per channel UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 11... -
Page 12: Bias Q3/Q5 Speakon™ Wiring
4.7 Bias Q3/Q5 speakON™ wiring Figure 4.6: Bias Q3 Figure 4.5: Bias Q5 Bias Q3/Q5 Out 1 Output LF (4”) and HF (0.75”) 8 (2 Ω load to amplifier) Max quantity per channel UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 12... -
Page 13: Mounting
• Use only Void-approved mounting equipment and accessories • Secondary safeties should be provided in all instances where cabinets are flying or fixing overhead and should conform to local regulations UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 13... -
Page 14: Wall Mounting
Remove all four M6 bolts from the rear of the loudspeaker. Figure 5.2: Cyclone 4 bolt removal Step 2: Remove the mounting plate from the wall bracket by removing the M6 countersink as shown. Figure 5.3: Mounting plate UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 14... - Page 15 Fix the bracket to the wall in compliance with local regulations. Once it is secure lift the Cyclone 4 with the mounting plate fixed to it into position and fix it to the bracket using the M6 countersink bolt that was removed in step 2.
- Page 16 5.2 Wall Mounting Step 6b: When adjusting the Cyclone 4 into position if the intention is to have maximum horizontal rotation then use adjust the bracket to the configuration shown in figure 5.6b. Max horizontal rotation: ±70° Max vertical rotation: +54°, -80°...
-
Page 17: Ceiling Mounting
Remove the mounting plate from the bracket by removing the M12 bolt as shown Figure 5.8: Mounting plate removal Step 2: Remove all four M6 bolts from the rear of the loudspeaker. Figure 5.9: Bolt removal UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 17... - Page 18 Step 4: Fix the bracket to the ceiling using all eight bolts. Once it is secure lift the Cyclone 4 with the mounting plate fixed to it into position and fix it to the bracket using the M12 nut that was removed in step 1.
-
Page 19: Stud Mount
Step 2: Attach the stud bracket using all four M6 bolts. The product can now be mounted to third party hardware using the M12 mounting position. Figure 5.14: Stud bracket attachment UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 19... -
Page 20: Pole Mount
Figure 5.16: Bolt removal Step 2: Attach the pole bracket kit using all four M6 bolts. Max horizontal rotation: 360° Max vertical rotation: +12°, -10° Figure 5.17: Pole mount kit attachment UG10567-1.0 - Cyclone 4 User Guide V1.0 Page 20... -
Page 21: Service
6.2 Shipping and packing considerations • When sending a Void Cyclone 4 loudspeaker to an authorised service centre, please write a detailed description of the fault and list any other equipment used in conjunction with the faulty product. -
Page 22: Appendix
The external dimensions of the cabinet shall be (H) 150 mm x (W) 179 mm x (D) 175 mm (5.9” x 7.1” x 6.9”). Weight shall be 1.3 kg (2.7 lbs). The loudspeaker shall be the Void Acoustics Cyclone 4. UG10567-1.0 - Cyclone 4 User Guide V1.0... - Page 23 H E A D O F F I C E Void Acoustics Research Ltd, Unit 15, Dawkins Road Industrial Estate, Poole, Dorset, BH15 4JY United Kingdom Call: +44(0) 1202 666006 Email: info@voidacoustics.com voidacoustics.com Void Acoustics Research Limited is a company registered in England and Wales registration number 07533536...
