4 Cable and Wiring
•
Attach the cable to the phoenix connector.
•
Position the connector plate and insert the
two M6 bolts.
UG10582-2.0 - Cyclone 8 User Guide V2.0
Figure 4.5: Phoenix attachment
Figure 4.6: Connector plate connection
Page 10
