- Page 1 Cyclone 10 Dynamic sound, visionary form U S E R G U I D E V 2 . 0...
- Page 2 For the latest online version, visit: www.voidacoustics.com Void Acoustics and the Void logo are registered trademarks of Void Acoustics Research Ltd. in the United Kingdom, USA and other countries; all other Void trademarks are the property of Void Acoustics Research Ltd.
-
Page 3: Table Of Contents
Cyclone 10 Wiring Diagram Bias D1/Q1/Q2 Phoenix Wiring Bias Q3/Q5 speakON™ wiring Mounting Installation Safety Wall Mounting Ceiling Mounting Horn Rotation Pole Mounting Service Return Authorisation Shipping and Packing Considerations Appendix UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 3... -
Page 4: Safety And Regulations
Void Acoustics Research Ltd for such as when the power-supply cord or plug is damaged, liquid reprocessing. -
Page 5: Unpacking And Checking
2 Unpacking and Checking All Void Acoustics products are carefully manufactured and thoroughly tested before being despatched. Your dealer will ensure that your Void products are in pristine condition before being forwarded to you but mistakes and accidents can happen. -
Page 6: About
In buying this product, you are now part of the Void family and we hope using it brings you years of satisfaction. This guide will help you both use this product safely and ensure it performs to its full capability. -
Page 7: Cyclone 10 Specifications
IP-55 (BS EN 60529:1992 +A2:2013) Rigging Optional Easy Hang XL wall bracket Finish Smooth cellulose Measured in half space AES2 - 1984 compliant Calculated Figure 3.1: Horizontal directivity isobars Figure 3.2: Vertical directivity isobars UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 7... -
Page 8: Cyclone 10 Dimensions
3 About 3.5 Cyclone 10 dimensions Figure 3.3: Dimensions UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 8... -
Page 9: Cable And Wiring
Figure 4.1 shows the rear panel of a Cyclone Series loudspeaker with the polarity of the Phoenix connector labelled. When viewed from the rear the connectors are negative, positive, negative, positive, from left to right. Figure 4.1: Phoenix connector diagram UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 9... -
Page 10: Cyclone Glanded Connector Wiring
Figure 4.3: Glanded connector removal • Insert the cable through the glanded connectors and tighten. Figure 4.4: Cable connection UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 10... -
Page 11: Cyclone 10 Wiring Diagram
Figure 4.5: Phoenix attachment 4.5 Cyclone 10 wiring diagram 1” HF Passive Crossover 10” LF Figure 4.7: Wiring diagram Phoenix pins 1-/1+ Phoenix pins 2-/2+ HF (1”) and LF (10”) Link/out UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 11... -
Page 12: Bias D1/Q1/Q2 Phoenix Wiring
Figure 4.10: Bias Q3 Figure 4.11: Bias Q5 Bias Q3/Q5 Out 1 Output LF (1 x 10”) and HF (1 x 1”) 4 (2 Ω load to amplifier) Max quantity per channel UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 12... -
Page 13: Mounting
• Use only Void-approved mounting equipment and accessories • Secondary safeties should be provided in all instances where cabinets are flying or fixing overhead and should conform to local regulations UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 13... -
Page 14: Wall Mounting
Figure 5.3: Mounting plate UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 14... - Page 15 (figure 5.6a) and in the vertical axis by adjusting the bolt on the base of the assembly (figure 5.6b). Figure 5.6a: Bracket adjustment Max horizontal rotation: ±70° Max vertical rotation: +28°, -0° Figure 5.6b: Bracket adjustment UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 15...
-
Page 16: Ceiling Mounting
Take care when mounting the bracket to the ceiling, making sure to use the correct fixing and that the ceiling can take the load. Figure 5.9: Deconstruction the bracket UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 16... - Page 17 Figure 5.10: Plate attachment Step 4: Fix the connector plate to the bracket using the M10 nut and washer. Max horizontal rotation: 360° Max vertical rotation: ±12° Figure 5.11: Bracket fixing UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 17...
-
Page 18: Horn Rotation
Figure 5.13: Grill removal Step 3: With the grill removed undo all four screws from the horn. Figure 5.14: Removing horn screws UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 18... - Page 19 Pull the cable ties toward the opposite edge of the loudspeaker and then lower the grill into position. Figure 5.16: Refitting the grill Step 5: Remove the cable ties. Figure 5.17: Removing cable ties UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 19...
-
Page 20: Pole Mounting
Figure 5.19: Top hat casting bolt removal Step 2: Attach the stud mount bracket to the top hat casting using the M12 bolt and washer Figure 5.20: Bracket assembly UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 20... - Page 21 Figure 5.22: Attaching the bracket Step 6: Adjust the angle of the speaker using the bolt at the base of the pole mount bracket. Figure 5.23: Bracket angle adjustment UG10588-2.0 - Cyclone 10 User Guide V2.0 Page 21...
-
Page 22: Service
Before returning your faulty product for repair, please remember to get an R.A.N. (Return Authorisation Number) from the Void dealer who supplied the system to you. Your dealer will handle the necessary paperwork and repair. Failure to go through this return authorisation procedure could delay the repair of your product. -
Page 23: Appendix
(H) 493 mm x (W) 320 mm x (D) 230 mm (19.4” x 12.6” x 9.1”). Weight shall be 14.5 kg (32 lbs). The loudspeaker system shall be a Void Acoustics Cyclone 10. UG10588-2.0 - Cyclone 10 User Guide V2.0... - Page 24 H E A D O F F I C E Void Acoustics Research Ltd, Unit 15, Dawkins Road Industrial Estate, Poole, Dorset, BH15 4JY United Kingdom Call: +44(0) 1202 666006 Email: info@voidacoustics.com voidacoustics.com Void Acoustics Research Limited is a company registered in England and Wales registration number 07533536...
