Step Stringer Handrail Fitting Instructions
Step 7 Step 7
Equally space* the remaining spindles and secure again with 2 x 50mm screws. One through the handrail, and one through the underside Equally space* the remaining spindles and secure again with 2 x 50mm screws. One through the handrail, and one through the underside
of the base rail, as shown in diagram below. of the base rail, as shown in diagram below.
*Please note, you will need to keep the same spindle spacing for between all newel posts if assembling an 11/12 step kit. This will result in *Please note, you will need to keep the same spindle spacing for between all newel posts if assembling an 11/12 step kit. This will result in
a smaller spacing at the top, but it will make the spacing appear correct. a smaller spacing at the top, but it will make the spacing appear correct. a smaller spacing at the top, but it will make the spacing appear correct.
Don't forget to check your work with a level as you go! Don't forget to check your work with a level as you go!
1 x 50mm Screw 1 x 50mm Screw
through the underside of the through the underside of the
base rail into each spindle base rail into each spindle
All images are for illustration only, Please see individual item listings for actual item specifications All images are for illustration only, Please see individual item listings for actual item specifications
www.eDecks.co.uk www.eDecks.co.uk
1 x 50mm Screw 1 x 50mm Screw
through the top of the through the top of the
hand rail into each spindle hand rail into each spindle
