Garden Bench Fitting Instructions
Contents
PARTS INCLUDED IN YOUR KIT
3 x
1400mm
1 x
1400mm notched for legs
6 x
1210mm
2 x
915mm
2 x
560mm Chamfered Arm Rests
4 x
560mm
2 x
470mm
2 x
510mm Angled Cut Back Supports
60 x 80mm Screws
Don't forget to check your work with a level as you go!
All images are for illustration only, Please see individual item listings for actual item specifications
www.eDecks.co.uk
Page 1 of 8
