Atlas Gazebo Fitting Instructions 2.4M
CONTENTS
Apex Roof
A1
Featheredge Roofing 2400mm
A2
2x2 Roof Framing 2260mm
A3
2x2 Roof Framing 1115mm
A4a
4x1 Roof Fascia 1195mm
A4b
4x1 Roof Fascia 1195mm
A5
Roof Centre Support Wedge
A6
Diamond Centre Piece
A7
Roof Capping Rail 2400mm
A8
Roof Support Front 980mm
A9
Roof Support Centre 570mm
A10
Roof Braces 660mm
Side Panels
B1
2x2 Vertical Framing 1810mm
B2
Hand / Baserail 2170mm
B3
Handrail Spindle 900mm
B4
2x2 Horizontal Framing 2170mm
B5
2x2 Support Braces 380mm
Rear Panel
C1
2x2 Vertical Framing 1810mm
C2
Hand / Baserail 2170mm
C3
Handrail Spindle 900mm
C4
2x2 Horizontal Framing 2170mm
C5
2x2 Support Braces 815mm
C6
2x1 Decorative Framing 100mm
C7
2x1 Decorative Framing 240mm
C8
2x1 Decorative Framing 380mm
C9
2x1 Decorative Framing 520mm
C10
2x1 Decorative Framing 640mm
C11
Support Posts 2070mm or 2400mm
Wood Screws*
40mm 1 1/2g x 8g
50mm Deck Screws
75mm Deck Screws
*Please note that you may receive additional screws in your kit.
x260
x10
x120
All images are for illustration only, Please see individual item listings for actual item specifications
www.eDecks.co.uk
x26
x4
x10
x2
x2
x5
x1
x1
x1
x1
x2
x4
x6
x28
x2
Assembly will require
x4
x2
x3
x14
x1
x2
x2
x2
x2
Please read these instructions
x2
carefully and plan your build
x2
We recommend a minimum of two
x4
people to assemble this structure
Always check the diagrams as a
reference before each step
at least 2 people
Page 1 of 11
Advertisement
Related Manuals for eDecks Atlas
Summary of Contents for eDecks Atlas
- Page 1 Atlas Gazebo Fitting Instructions 2.4M CONTENTS Apex Roof Featheredge Roofing 2400mm 2x2 Roof Framing 2260mm 2x2 Roof Framing 1115mm 4x1 Roof Fascia 1195mm 4x1 Roof Fascia 1195mm Roof Centre Support Wedge Diamond Centre Piece Roof Capping Rail 2400mm Roof Support Front 980mm...
- Page 2 Atlas Gazebo Fitting Instructions 2.4M Step1 - Assembling the Apex Roof Start by evenly spacing five 2x2 Roof Framing 1115 (A3) and Now, to create the apex, join the two frames together using the boxing them in with two 2x2 Roof Framing 2260mm (A2) to Roof Centre Support Wedges (A5) attach the front and create a frame, repeat this for the opposing side.
-
Page 3: Step 2 - Assembling The Side Panels
Atlas Gazebo Fitting Instructions 2.4M Step 2 - Assembling the Side Panels Start by evenly spacing 14 Handrail Spindles (B3) and fixing on to two of the Hand / Baserail 2170mm (B2) screwing through the top and bottom into each spindle using 40mm screws. - Page 4 Atlas Gazebo Fitting Instructions 2.4M Step 2 Cont’d - Assembling the Side Panels 75mm Screw Fix one 2x2 Horizontal Framing 2170mm 75mm Screw (B4) in between the top of the vertical framing making a flush finish. Use 2 x 75mm screws at each end.
- Page 5 Atlas Gazebo Fitting Instructions 2.4M Step 3 - Assembling the Rear Panel Start by evenly spacing 14 Handrail Spindles (C3) and fixing on to two of the Hand / 2170mm (C2) screwing through the top and bottom into each spindle using 40mm screws.
- Page 6 Atlas Gazebo Fitting Instructions 2.4M 75mm Screw Step 3 Cont’d - Assembling the Rear Panel 75mm Screw Fix one 2x2 Horizontal Framing 2170mm (C4) in between the top of the vertical framing making a flush finish. Using the two 2x2 Braces 815mm (C5) screw these to each top corner of the panel using 75mm screws as shown below for each brace.
- Page 7 Atlas Gazebo Fitting Instructions 2.4M Step 4 - Support Posts When fitting Option A - the support posts 2400mm will be required to be bedded into the ground 480mm. For all options A, B & C make sure there is a...
- Page 8 Atlas Gazebo Fitting Instructions 2.4M Step 4 Cont’d - Support Posts Repeat the process for the rear panel and the remaining side panel. Front of Gazebo Back of Gazebo 24 x 75mm Screws required for this step Page 8 of 11 All images are for illustration only, Please see individual item listings for actual item specifications...
- Page 9 Atlas Gazebo Fitting Instructions 2.4M Step 5 - Fastening the Apex Roof Lift the roof above the gazebo and rest it in place in between the posts, on top of the horizontal framing and screw in place using 8 x 75mm screws as indicated in the diagram to secure.
- Page 10 Atlas Gazebo Fitting Instructions 2.4M Step 6 - Adding roof supports & front roof braces. Fix into position the front and centre roof Finally add the 2 front roof braces A10 again supports - A8 using 2 x 75mm screws at each end using 2 x 75mm screws at either end of the brace of the support from the inside of the Gazebo &...
- Page 11 Atlas Gazebo Fitting Instructions 2.4M Finish Page 11 of 11 All images are for illustration only, Please see individual item listings for actual item specifications www.eDecks.co.uk...
