- Page 1 ASSEMBLY INSTRUCTION HALCYON Dining Table ITEM CODE:68148 Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt...
- Page 2 PRE-ASSEMBLY PREPARATION Before you start: 1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may damage the product 2. Take care when lifting. Product should be assembled as near as possible to the point of use 3. Ensure that you have all required contents for complete assembly 4.
- Page 3 PARTS LIST ① TABLE TOP ② CONNECTIONG PLATE ③ TRUNK ④ BASE ① ③ ② ④...
- Page 4 STEP 1: • Insert bolt 3 x B into 3 x Washer A. Use Allen Key E to connect the Connecting plate ② with the trunk ③. ② ③...
- Page 5 STEP 2: • Place the table top ①, ontp a padded/protected surface, upside down. Insert 4 x bolt C into 4 x Washer A. Use Allen Key E to connect the Connecting plate ② to the table Top ①. ③ ②...
- Page 6 STEP 3: • Insert 3 x bolt D into the Base ④. Use Allen Key E to connect the Base ④ with the Frame ③. Stand the table the right way up when complete. ④ ③ ② ①...
- Page 7 ASSEMBLY IS COMPLETE...
- Page 8 PRODUCT CARE: Hi-gloss lacquered furniture is more sensitive to marks and scratching then some other furniture products. It is important to exercise caution and care to maximise the life and beauty of this product Following the below simple guidelines when using your hi-gloss product will protect your investment for years to come •...
