Summary of Contents for Breezesta FANBACK ADIRONDACK AD-0101
- Page 1 FANBACK ADIRONDACK AD-0101 REV01-8/19 AD-0101 Assembly...
- Page 2 PARTS PART DESCRIPTION PART NO. LEFT ARM ASSEMBLY SA-00405 RIGHT ARM ASSEMBLY SA-00406 FRONT LEG PRT-00006 UNDER ARM SUPPORT PRT-00007 ADIRONDACK SPREADER SS-22.187 BASE ASSEMBLY SA-00001 BACK ASSEMBLY SA-00008 HARDWARE PACK PART DESCRIPTION PART NO. 5/16" X 2-1/8" CHAIR BOLT H-0000-CB516218 5/16"...
- Page 3 Please read entire instructions before beginning Connect Part C to Part A Rotate Part C clockwise until using Hardware e as shown tight in the orientation shown Using Hardware C attach Part D Place Part D in pre-cut slot as shown.
- Page 4 Attach Part G to Part F Turn the back/seat assembly on using 4 of hardware b. it's side. Lay one arm/leg assembly from steps 1-5 on the back/seat assembly and bolt together using 1 each of hardware a & b as shown. Tip: If the seat back is a little Flip the chair to the opposite side...
