Overview
We have modified the 864 40K/31K exhaust restrictor to allow for full adjustment. This kit
includes the new restrictor. Make sure to check the 864 before installation to verify it has the
new restrictor.
Instructions
Remove and discard the old restrictor (see below).
Install the new restrictor as shown below (use the screws removed earlier).
Page 1 of 2
864 40K/31K New Restrictor Kit
sku# 250-04794
OLD
RESTRICTOR
(keep the screws)
(closed)# 4
# 3
# 2
(open) # 1
WHEN USING POSITION #4, BEND
THIS FLANGE DOWN FLAT
17602051 - 9/7/18
Loosen these 4 screws on
the exhaust restrictor.
Slide the restrictor to the correct
position (see illustration above).
The rear screw location indicates
restrictor position.
This restrictor is in position # 4.
Tighten the screws to secure the
restrictor.
© Travis Industries, Inc.
Advertisement
Table of Contents
Related Manuals for Travis Industries 864 40K
Summary of Contents for Travis Industries 864 40K
- Page 1 864 40K/31K New Restrictor Kit sku# 250-04794 Overview We have modified the 864 40K/31K exhaust restrictor to allow for full adjustment. This kit includes the new restrictor. Make sure to check the 864 before installation to verify it has the new restrictor.
- Page 2 250-04794 864 31K – Exhaust Restrictor Position See the installation manual for exhaust restrictor position and vent configurations. 864 40K – Exhaust Restrictor Position Vertical Terminations See the installation manual for exhaust restrictor position and vent configuration. Horizontal Terminations Use the illustration below to determine the correct exhaust restrictor position.
