864 TRV 31K
Framing Guide
12521 Harbour Reach Drive
Mukilteo, WA 98275-5458

Rear Vent Configuration

8" (203mm) Ø Vent
Scan for
Installation Manual

Top Vent Configuration

8" (203mm) Ø Vent
28-5/8"*
728mm*
20-3/4"*
528mm*
* See "Clearances" and "Framing Dimensions" for details.
30-3/4"
781mm
This document is for reference purposes
only.  Consult the installation manual
BEFORE making installation decisions.
7-1/4"
184mm
38-1/4"
972mm
Route the electrical line to
a position to the left rear
of the fireplace.

Minimum enclosure height = 38-1/2" (978mm)
17602150
Optional "CoolSmart TV" or
"Power Heat Duct" Connection
37"
940mm
41"
1041mm
38-1/2"
978mm
41-1/4"
1048mm
38-1/4"
972mm
36-3/4"
933mm
35-1/4"
895mm
1"
25mm
20-3/4" (528mm)
