Packing List

Rear Fireback
(2) Side Firebacks

Installation

STAINLESS STEEL WARNINGS

HANDLING THE FIREBACKS: The stainless steel firebacks are shipped in vinyl to prevent marring the surface
of the stainless steel. Before installation, peel back the corners 3" to 4". Install the firebacks, then
remove the vinyl by peeling away from the corners.
COLORATION AND CLEANING: These stainless steel firebacks will obtain a slight "patina" (brown tint) after
use. Do not clean the firebacks. This patina becomes consistent. Any cleaning may lead to unequal coloring.
If soot forms on the fireback, we recommend brushing it off with a soft cloth or brush.

CLEANING ENAMEL FIREBACKS

We recommend cleaning the enamel surface with glass cleaner and a soft cloth.
1
Access the firebox (see Owner's Manual).
2
Remove the two rear fireback clips from the firebox ceiling (1/4" nutdriver). The clips are located along the
upper rear edge of the firebox.
Page 1 of 4
3615, 4415, 6015 Firebacks
3615 – Black Enamel 96100942, Black Painted 96100943, Silver Painted 96100945
4415 – Black Enamel 96100972, Black Painted 96100973, Silver Painted 96100975
6015 – Black Enamel 96100982, Black Painted 96100983, Silver Painted 96100985
The fireback clip has a
keyhole slot. It can be
removed by loosening
the screw and sliding
the clip out.
17601804 - 5/19/15
Travis Industries, Inc.
