Travis Industries 250-05727 Quick Start Manual

This kit is for replacement of the incorrect exhaust restrictor that was inadvertently packaged on some of
the 564 25K GSR2 and 564 25K GSR2 CF fireplaces. The included "flat" restrictor will not work correctly
and needs to be replaced with the exhaust restrictor included in this kit.

AFFECTED SKU NUMBERS:

98500277, 98500278

AFFECTED SERIAL NUMBER RANGE:

3409-043397 through 3409-044388
Appliances that are installed straight out the back or with a minimum rise that require the exhaust restrictor
to be removed according to the installation instructions need no action taken. The exhaust restrictor does
not need to be replaced - simply removed - on these types of installations.
All other installations need to have the "incorrect" exhaust restrictor changed out.

INSTRUCTIONS:

1. Remove the old "incorrect" exhaust restrictor by removing the (2) 1/4" hex head screws holding it in place.
2. Install the new "correct" exhaust restrictor in it's place using the (2) 1/4" hex head screws removed in step
#1.
Thank you for your attention to this issue. We apologize for any inconvenience this may have caused. Please
don't hesitate to contact us with any question.
IMPORTANT - be sure to set the exhaust restrictor in the proper position for your specific vent configuration
(refer to the installation manual for detailed information on configurations).
© Travis Industries, Inc.
564 25K Exhaust Restrictor Kit
250-05727
17602205 Page 1
