Fireplace Thermostat Fix Kit – 228-30035
Overview
This kit contains a remote that has been specially created to replace faulty modulating remotes
(SKU 99300652) It is intended as a fix for those remotes that are not working correctly.
This Remote is Non-Modulating
This remote does not have a modulating circuit. Therefore, you have two options for using this
remote:
• Option A Manually over-ride the regulator on the gas control valve. This will make the
heater operate with a high flame. If you do not insert the pin, the heater will operate at the
low flame height. Use the pin included with the modulating remote.
a
Twist and remove
the clear plastic
regulator cover
(be careful - it is
fragile).
• Option B Remove the modulating regulator and replace with a stock regulator (LP or NG).
Contact Travis Industries for this part if necessary.
Printed 12/23/02
Remove the pin held
b
in this hole.
c
Place the pin
into this hole.
Replace the plastic cover to
d
secure the pin in place.
Page 1 of 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 228-30035 and is the answer not in the manual?

Questions and answers

Related Manuals for Travis Industries 228-30035

Summary of Contents for Travis Industries 228-30035

  • Page 1 Replace the plastic cover to secure the pin in place. in this hole. • Option B Remove the modulating regulator and replace with a stock regulator (LP or NG). Contact Travis Industries for this part if necessary. Printed 12/23/02 Page 1 of 6...

  • Page 2: Installation Instructions

    Fireplace Thermostat Fix Kit – 228-30035 Installation Instructions FCC REQUIREMENTS Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Setting The Time

    Fireplace Thermostat Fix Kit – 228-30035 Transmitter Remote Receiver Calibration Slide the access AAA Battery cover off. Remove the cover from the back of the transmitter. Insert three "AAA" AAA Battery batteries into the transmitter as shown. Slide the code switches to a random position on the receiver.

  • Page 4: Modes Of Operation

    Fireplace Thermostat Fix Kit – 228-30035 OPERATING INSTRUCTIONS NOTE: This kit must be installed by a qualified technician to work correctly NOTE: On gas stoves the pilot flame must be lit, the gas control valve turned to "ON", and the on/off switch turned to "OFF"...

  • Page 5: Child Proof Feature

    Fireplace Thermostat Fix Kit – 228-30035 Timed Mode TIMED OPERATION: Timed mode allows you to turn °F °F the heater on for a pre-set period Use the arrow keys to adjust the SET TEMP TIMER target temperature to 90°. ROOM TEMP of time.

  • Page 6: Operation During Power Outages

    Fireplace Thermostat Fix Kit – 228-30035 OPERATION WITH DEAD BATTERIES If the heater is on (any mode) and the batteries go dead, the heater will turn off after 6 hours. To operate the heater, use the switch on the heater to turn the heater on and off.
