Dear Users,
Thank you for purchasing our Bishamon Mucross lift. Before using the lift, read through
and be familiar with this manual. Fully understand the precautions, directions, and other
information contained in this manual to ensure correct use. Failure to do so may result
not only in insufficient performance of the lift but also in falling of the vehicle, serious
injury and death, and damage to properties.
Keep this manual in a safe place for future reference. In case of loss, immediately request
a new copy.
If the product is supplied with a wrong manual, contact your lift supplier for a correct copy.
Perform periodic maintenance inspection of the lift to ensure safe work
with the lift and keep the lift fully functional.
Sugiyasu Corporation
Jan. 2020
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bishamon MUL30
Summary of Contents for Bishamon MUL30
- Page 1 Dear Users, Thank you for purchasing our Bishamon Mucross lift. Before using the lift, read through and be familiar with this manual. Fully understand the precautions, directions, and other information contained in this manual to ensure correct use. Failure to do so may result not only in insufficient performance of the lift but also in falling of the vehicle, serious injury and death, and damage to properties.
- Page 2 Bishamon Multi & Mucross lift Thank you for purchasing our . Before using the lift, read through and be familiar with this manual. Fully understand the precautions, directions, and other information contained in this manual to ensure correct use. Failure to do so may result not only in insufficient performance of the lift but also in falling of the vehicle, serious injury and death, and damage to properties.
- Page 3 3) ～ 5) 7) ～ 9) 10) ～ 11) 14) ～ 15) 21) ～ 22) 24) ～ 26)
- Page 4 This product is a lift to be used for oil and parts replacement, general maintenance, motor vehicles inspection and maintenance etc. of mini-to ordinary sized passenger cars, small sized trucks, and the like. Caution for Safety As there are very important to protect operators from accidents which may result in injury and death,and damage to cars and properties, make sure to understand fully before operating lift.
- Page 5 Drive in vehicle straight Read the Operation Manual DO NOT lower the lift thoroughly before using while any stand or and parallel to the lift. Vehicle MUST BE positioned the lift. support is in position Important Warnings are under vehicle. evenly.
- Page 6 1. This lift is designed for motor vehicle servicing. DO NOT Use for other purpose. 2. If any of safety device does not work properly, DO NOT use lift. 3. Drive in and out vehicle slowly, and DO NOT start and stop suddenly. 4.
- Page 7 Serial Plate CG Label Foot Protection Label Capacity Label Lubrication Points Label Maintenance Label showing how to lubricate Air Cylinder (Unlock Cylinder) for releasing Lowering Stop Hook. Caution Label Caution Label E showing how to do Pre Operation Check of Filter Regulator.
- Page 8 Hyd. Unit Turning Radious Gauge (Option-Model MUL30H) Upper lift (Model MUL30 and MUL30H only) Lower lift (Drive On Plate) Drive (Model MUL30H only) Link (Scissors) Base Lowering Stop Device (Unlock Cylinder installed inside) Side Sill Block (Model MUL30 and MUL30H only) This switch adjust the height of right side and left side drive on plate of Lower Lift.
- Page 9 Air Filter Regulator reduce the air pressure of the air supplied to the Air Filter Regulator to appropriate pressure levels, and drain water in the air. Air pressure gauge shows the air pressure after depressurization. Air Filter Regulator Hydraulic Unit ①...
- Page 10 Use legs to stabilize the lift for accurate levelling when using the lift for alignment work. When using lift for alignment work, lower the legs by hands. Lower the legs when using the Alighnment Turning Radius Gauge is used for measuring the alignment.
- Page 11 Magnet Contactor Motor Lifting Push Button for Upper Lift Lowering Push Button for Upper Lift Lifting Push Button for Lower Lift Lowering Push Button for Lower Lift Push Buton for Rectification SOL0 SR Shut Off Valve SOL1 SL Shut Off Valve SOL2 MM Shut Off Valve SOL3...
- Page 12 Magnet Contactor Motor Lifting Push Button for Upper Lift Lowering Push Button for Upper Lift Lifting Push Button for Lower Lift SOL1 SL Shut Off Valve SOL2 MM Shut Off Valve SOL3 Lowering Valve SOL4 MS Shut Off Valve Pressure Switch for Lowering Stop Sensing Transformer Rectifying Bridge Electroysis Condensor...
- Page 13 Mucross Lift is operated by Electro Hydraulic. ・Upper Side Lift - through hydraulic valve ・Lower Side Lift - direct connection of both side cylinders When pushing "Up" button, motor runs and gear pump feed the oil to cylinder, and lift goes up. When releasing the button, oil flow stops at check valve and lift stops.
- Page 14 Then contact your lift supplier immediately. If the lift is used with abnormality left unsolved, damage to the lift or serious accident may occur. Hyd. Unit Turning Radius Gauge (Option - MUL30H) Upper Lift (MUL30 、 MUL30H) Lower Lift (Drive-On Plate) Drive-On Plate Legs (MUL30H)
- Page 15 ・This lift is not weatherproof, and is not to be used outdoors or for vehicle washing. ・When use Upper Lift, make sure to lift up to max height to avoid unbalance. Lower the lift (including Upper Lift for Mdoel MUL30 and MUL30H) to the lowest, and remove everything such as tools and parts etc.
- Page 16 CG of the vehicle MUST STAY inside CG Range Label Upper Lift Park the vehicle so that Lifting Point stays within Upper Lift Top Plate ・When operating lift, DO NOT get under vehicle. ・Pay close attention to the tilting of the vehicle when operating lift. ・When operating lift, pay constant attention to the area around vehicle and the lift.
- Page 17 ・When operating lift, DO NOT get under vehicle. ・When operating lift, pay close attention to the tilting of the vehicle. ・Set the supporters on a flat spot with sufficient strength. ・When operating lift, pay constant attention to the area around vehicle and the lift. NEVER look aside during the operation.
- Page 18 If the vehicle starts to fall from lift, move away quickly. DO NOT ATTEMPT TO SUPPORT VEHICLE. ・Keep anyone but the operator out from around the lift area. ・Before start servicing vehicle, make sure Safety Hooks are "engaged". ・When not in use, the lift must be lowered to the lowest position. ・DO NOT leave a vehicle on the lift for a long time.
- Page 19 operating ・DO NOT get under vehicle when the lift ・DO NOT lower the lift while any stand or transmission jack etc. is in position under vehicle. ・Pay close attention to the tilting of the vehicle during operation. ・Keep feet clear of lift and wheel stop etc. when lowering the lift ・When operating lift, Pay close attention to the condition of the vehicle.
- Page 20 operating ・DO NOT get under vehicle when the lift ・Pay close attention to the tilting of the vehicle during operation of lifting and lowering. ・When operating lift, Pay close attention to the condition of the vehicle. Never look aside during the operation. Lift Up or Lower only this side lift Vehicle Entry Direction...
- Page 22 Suspend the use of the lift immediately and make sure it is repaired properly and verify safety before using the lift. Request the lift supplier where lift was purchased for repairs on abnormality. Make sure to use Bishamon genuine parts for repair. Hyd. Unit...
- Page 23 Roller Bearing Shaft, Slide Shoe Shaft, Shaft, Shaft Grease Fitting Grease Fitting Unlock Cylinder, Bearing Area Grease Fittings at both sides Shaft, Grease Fitting Shaft, Grease Roller Bearing...
- Page 24 If any abonormality occurs, carefully read this manual and make the following checks and actions. If abonormality can not be eliminated, contact your lift supplier for advice. ･ Investigate the casue and push ･ Thermal relay of magnet contactor is running the reset button ･...
- Page 25 Specification Model No. MUL30 3000 kgs. Lower Lift Capacity 2000 kgs. Upper Lift Drive in Pipe Cover Direction 1600mm Lower Lift Vertical Travel 350mm Upper Lift Pipe Cover Approx. 72 Seconds (50Hz) Lower Lift Approx. 60 Seconds (60Hz) Rising Speed Approx.
- Page 26 Specification Model No. MUL30P Lower Lift 3000 kgs. Capacity Pipe Cover Drive in 2000 kgs. Upper Lift Direction Hyd. Hose 1570mm Lower Lift Vertical Travel Upper Lift 350mm Approx. 72 Seconds (50Hz) Lower Lift Approx. 60 Seconds (60Hz) Rising Speed Approx.
- Page 27 Specification Model No. MUL30H Lower Lift 3000 kgs. Capacity Pipe Cover Drive in Upper Lift 2000 kgs. Directio Lower Lift 1596mm Vertical Travel Pipe Cover 350mm Upper Lift Approx. 72 Seconds (50Hz) Lower Lift Approx. 60 Seconds (60Hz) Rising Speed Approx.
- Page 28 Contact your lift supplier for the installation and relocation of the lift. Have your lift inspected by your lift supplier before relocation. When disposing of this lift, break it down into scrap and separate the scrap into steel, non-ferrous metals, plastics, hydraulic oil, etc. Disopose of these materials as industrial waste.
- Page 29 Something is wrong Check in accordance with this manual Something is still wrong Contact your lift supplier Repair under Warranty period will be repaired in accordance with Warranty rules Repair after Warranty period Contact your lift supplier The spare parts are available for 8 years after Availability of spare parts discontinuing manufacturing Contact your lift supplier for any information regarding after service.
- Page 30 3-21, 4-Chome, Hongo-Cho, Takahama City, Aichi, Japan 444-1394 Tel. 81-566-53-1126, Fax. 81-566-53-1844 http//www.bishamon.co.jp/...
